Summary of Contents for Defenstar DS007

  • Page 1: User Manual

    DS007 User Manual DS007 GPS Tracker User Manual Version: V1.5 Copyright by Shenzhen Defenstar Technology Co., Ltd Contents Website:...
  • Page 2: Table Of Contents

    DS007 User Manual 1. Product Overview..................................3 2. Main Functions And Features ..............................3 2.1 Real time tracking and positioning ..........................3 2.2 SMS get location and parameters ..........................3 2.3 Support AGPS fast positioning ............................. 3 2.4 Historical route checking............................... 3 2.5 Long time battery life ..............................
  • Page 3: Product Overview

    DS007 User Manual 1. Product Overview This device is an innovative miniature size and pet remote positioning device with built-in GPS and GSM/GPRS technology. It’s for monitoring and protecting your pets. You can find your pets very soon when they got lost.
  • Page 4: Device Status And Button Operating Manual

    DS007 User Manual 4.2 Device Status and Button Operating Manual 4.2.1 Device LED indicator introduction Flash 1 time per second GPS fixed. Blue LED●GPS Solid(keep on) GPS not fixed. Flash 1 time per second GSM SIM card read successful. Flash 4 times per second(1 Green LED●GSM...
  • Page 5: Button Operating Introduction

    DS007 User Manual 4.2.2 Button operating introduction Press & hold for 3s when Power on. device is power off Press & hold for 3-7s when Power button Power off. device is power on Press 1 time when there is Hang up the incoming calling.
  • Page 6: Set Authorized Number

    DS007 User Manual Note: If APN without user name and password, no need to fill in, however the “,” need to retain. E.g. 1(APN with user name and password): S1,orange.fr,orange,orange Orange.fr is Orange France SIM card’s APN. After set successful, APN will be Orange.fr, device will reply SMS: Set APN OK:APN:orange.fr,user name:orange,password:orange.
  • Page 7: Functions Setting

    DS007 User Manual E.g.: Set timezone OK:E02,2016.05.06 12.11.30 ※ Default time zone is UTC+08:00 6.2 Functions Setting 6.2.1 Three Working Modes There are 3 working mode which are live tracking mode, fixed upload interval mode, and smart awaken mode. Device default working mode is fixed upload interval mode.
  • Page 8: Get Device Status

    DS007 User Manual ※ Put coordinates to Google earth or Google maps. Click on search button, then you will find the position fixed. ※ Click on the link then the location can be shown directly on Google Map on your mobile phone.
  • Page 9: Set Ip & Port

    DS007 User Manual The password will be modified to 1111 After set successful, device will reply : Set password OK: 1111. ※ Even the user change a SIM card, the device’s password won’t be deleted. ※ Please remember your new password, or you need to contact your agent to resume the device’s initial password.
