Page 1: Table Of Contents
Step 2: center and secure the Android Box Step 3: connect to HDMI and power Step 4: connect the WAVE Arm and align the infrared wall Step 5: Pairing the WAVE with your phone or tablet Step 6: Adjust your screen size...
Page 2: Introduction
Watch our FAQ Videos for help with setting up your Touchjet WAVE™ Turorial videos User Manual http://bit.ly/TJFAQ http://bit.ly/TJGuide Download the free Touchjet App to your smartphone or tablet to use as a smart remote during setup. Need Help or Have Questions? cs@touchjet.com © 2018 Touchjet™ All Rights Reserved...
Page 3: Health And Safety Information
Important Safety Information - Read the following warnings before setup or use of the Touchjet WAVE. If this product will be used by young children, this manual should be read and explained to them by an adult. Failing to do so may cause injury.
Page 4 WARNING - Electric Shock To avoid electric shock when you use this system: • Do not use the WAVE during a lightning storm. There may be a risk of electric shock from lightning. • Use only the AC Adapter that comes with your system.
Page 5: Wave Usage Precautions
• Do not expose the WAVE, components or accessories to extreme heat or cold. • Do not spill any liquids on the WAVE, components or accessories. To clean, use a soft slightly damp cloth. Use water only. Allow to dry completely before using.
Page 6: Components
Note: HDMI cable is not included. Use any existing HDMI cable or purchase it at an electronic store. Remote control is not included. Download the Touchjet App to your phone or tablet to use as a smart remote. © 2018 Touchjet™ All Rights Reserved...
Page 7: Step 1: Before You Begin
The Touchjet WAVE adds a virtual touchscreen to your flatscreen TV. Three lasers project a thin wall of infrared light from the bottom of your WAVE over your TV screen. When you touch the screen, your finger breaks the light wall, sending a reflection to the infrared camera. The WAVE sees this reflection as a touch input.
Page 8: Step 2: Center And Secure The Android Box
. Slide the Alignment Tool underneath one side of the Android Box with its foot flat against your screen. A snug fit means that the laser projectors in the WAVE unit are correctly aligned with the screen of your TV.
Page 9 . Remove the Protective Film from the Velcro Tape attached to the Velcro Pad and keeping the Android Box in place. Press it firmly onto the back of your TV. . Slide the Alignment Tool out from underneath the box to remove it. © 2018 Touchjet™ All Rights Reserved...
Page 10: Step 3: Connect To Hdmi And Power
Power Adapter WAVE AC Adapter . Insert the DC plug on the WAVE AC Adapter cord into the DC Input connector on the back of the Android Box. . Insert the AC plug into a 120V AC power outlet. Note: we recommend plugging your WAVE into a power strip so that you can easily turn the device on and off.
Page 11: Step 4: Connect The Wave Arm And Align The Infrared Wall
Connect the WAVE Arm and align the infrared wall . Connect the WAVE Arm to the top of the Android Box by carefully place the lip at the base of the arm into the rectangular opening atop the box. The WAVE Arm should snap into place so that there is no gap between the arm and the box.
Page 12 . Yellow Light - can indicate that you have adjusted too far. Twist the Angle Adjustment Knob clockwise until the light turns green. . No Light - ensure that the WAVE arm is snapped into place tightly and that the Alignment Tool can still fit between the box and the TV.
Page 13: Step 5: Pairing The Wave With Your Phone Or Tablet
WAVE. . Turn on your TV and set its input source to the HDMI channel connected to the WAVE. . Go to your phone or tablet’s WiFi settings menu and connect to the WiFi hotspot broadcast by your WAVE (see left and center images below).
Page 14: Step 6: Adjust Your Screen Size
If the screen size appears bigger or smaller than your TV display, you can adjust the size by following the steps below: . Using the app menu within the Touchjet App on your phone or tablet, launch the WAVE’s Display Settings app.
Page 15: Step 7: Touchscreen Calibration
TV screen using touch. You are about to teach your WAVE where it will find the borders of your screen and what to perceive as touch. As such, it is important to avoid sending the WAVE unwanted IR signals during calibration.
Page 16 Press to Finish to complete calibration. Press to Finish Once the calibration process is completed, you can fully use the touch functionality of the WAVE, or continue to use the Touchjet App on your smartphone/tablet as a smart remote. © 2018 Touchjet™ All Rights Reserved...
Page 17: Step 8: Setting Up Wi-Fi
Step 8 Setting up Wi-Fi There are two ways to set up Wi-Fi on your WAVE. You can set up the Wi-Fi directly on the WAVE using finger touch, or use the Touchjet App on your smartphone or tablet. Setup Via the WAVE .
Page 18 . In the Touchjet App, tap on Settings. . Select your Wi-Fi network and enter the password. Tap on Save Wi-Fi Settings. Note: The app will lose connection to the WAVE and reconnect after both the WAVE and your smartphone has connected to the Wi-Fi network.
Page 19: Step 9: How To Add Or Remove Apps From The Home Screen
You can access this by tapping the All Apps button in the bottom right hand corner of your WAVE and swiping left or right to see more of the list. You can also see the full list of apps within the app menu of the Touchjet App on your phone or tablet.
Page 20 +1 415.579.3399 Email: cs@touchjet.com Touchjet warrants the Touchjet WAVE™ to be free from defects in materials and workmanship under normal use for a period of 1 year from the date of original direct or retail purchase. You may also have other rights that vary from state to state and country to country.
Page 21 One-Year Limited Warranty Touchjet, Inc. (“Company”) offers the following commercial warranty to “you”, the first user of the Touchjet WAVE™ Projector (“Product”). This warranty is in addition to any legal rights you have against the Company or any other person.These rights vary by jurisdiction and are not affected in any way by this warranty. If you transfer the Product to another person they will also have the benefit of this warranty.
Page 22 Some jurisdictions disallow the exclusion or limitation of implied warranties, so the above exclusions or limitations may not apply to you. This warranty gives you specific legal rights and you may also have other rights, which vary from jurisdiction to jurisdiction. © 2018 Touchjet™ All Rights Reserved...
