DIGITAL VOICE RECORDER & AUDIO PLAYER
& AM/FM RADIO
MODEL : Voice Bank
User's Guide manual
Thank you for purchasing PORTABLE DIGITAL AUDIO PLAYER from DIASONIC.
Please carefully Read the Instruction manual for safe use of the product. We
recommend you to keep this instruction manual for future reference.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Diasonic Voice Bank
Summary of Contents for Diasonic Voice Bank
- Page 1 MODEL : Voice Bank User’s Guide manual Thank you for purchasing PORTABLE DIGITAL AUDIO PLAYER from DIASONIC. Please carefully Read the Instruction manual for safe use of the product. We recommend you to keep this instruction manual for future reference.
-
Page 2: Safety Precautions
● We are not responsible for any loss of files caused by any reason. ● Do not repair, disassemble or make modifications to Voice Bank. ● Do not use Voice Bank in any area designated No Electronic Devices like airports or medical facilities. ● Do not operate while driving. ● If... -
Page 3: Functions And Features
Functions and Features Voice Bank is manufactured under strict quality control procedures to ensure the best performance and customer experience. ● Elegant Design and Exterior Finishing Voice Bank is designed with the customer in mind. Using a wide LCD Screen and half miller window to eliminate the closeness of a small display and show off a high class image to enhance the user’s experience. - Page 4 ● Real time or reserved FM RADIO RECORDING function ● Real time or reserved AM RADIO RECORDING function ● AM/FM PRESET CH function ● AM Region setting EUROPE (9) or USA (10) ● Setting up to 10 reserved recordings is possible ●...
-
Page 5: Parts And Components
Parts and Components 1) MAIN SET Internal Microphone LED Lamp External Display Microphone Jack Vol +/- Ear phone Mode File Up Hold On/Off Externa Timer Memory Inlet Menu Erase Rewind Forward Reset Speed A↔B/Repeat File Down Paly/Stop Usb Jack 2) LCD Battery Strength Date Mode Selection... - Page 6 Check the polarities of the batteries if the LCD Display doesn’t turn ON after inserting new batteries. ※ Note If you do not use Voice Bank for a long time, the batteries may be run down naturally. Take out the batteries if you do not plan on using Voice Bank...
- Page 7 ④ Battery Life Playback via Speaker Battery Type Recording Playback via Ear phone (Volume: Middle) Alkaline “AAA” LR-03 Approx 10hr Approx 8hr Approx 15hr ⑤ Caution when Using the Battery ● Do not use other battery. ● If you do not use this recorder & player for a long time, take the batteries out of the body.
-
Page 8: Voice/Am/Fm/Mp3 Buttons
VOICE/AM/FM/MP3 Buttons ● VOICE MODE (VOICE) Upon operating the keys, ㅡ means a short press and ㅡㅡ means pressing and holding (longer than 1 sec). Buttons Stopped Upon Recording Playing Operations ㅡ Plays the beginning of file /Stop status /Stops recording ㅡㅡ... - Page 9 ● AM/FM Radio Domain (RADIO/KEY Operation) Buttons Receiving Upon Recording Operations ㅡ PRESET the station /Stop X/ Stops recording ㅡㅡ Power off Power OFF ㅡ Changes to the next preset ㅡ Changes to the previous preset ㅡ, SEEK TUNNING ㅡㅡ AUTO TUNNING ㅡ...
- Page 10 Selects from the ㅡ Repeats playing section between A-B external/internal memory REPEAT ㅡ Changes repeat setting Changes repeat setting ㅡ Deletes the current file ERASE ㅡㅡ Deletes all files ROCK/CLASSIC/NORMAL ㅡ ROCK/CLASSIC/NORMAL/POP/LIVE /POP/LIVE VOL+ VOLUME+ VOLUME+ VOL- VOLUME- VOLUME- HOLD ON/OFF ON/OFF...
-
Page 11: Timer And Recording
Timer and recording You need to set the current date and time prior to initiating a recording. ① Press and hold the TIMER Button while the player is stopped. ② When you hold the TIMER Button, the day will be flickering and then if you press you can change the day. - Page 12 ※ Note - Do not take the battery out during a recording because it may cause the recording to be lost or a malfunction Take out the battery only when the player is stopped. - If the corresponding file exceeds the recording capacity or there is not enough room for a recording, the recording will not be available.
-
Page 13: External Memory
External Memory A-B Mode Conversion Display ① If you press the A-B Button in the stop status after inserting an external memory card, the display screen of INT/CARD will be converted and the internal and external memory domains will be separated. ②... - Page 14 SD/MMC Card Recording 1. Push the A-B button on Voice Bank to switch to the SD/MMC card and next press the TIMER Button twice and the reserved recording screen appears. The minute needle clock indicator and setting channel should be flickering. Press FW or RW to select the file number and then push PLAY.
-
Page 15: Playback Mode
Playback mode ● Playing a VOICE file ① Select the message you want to listen to. (Select the file you want 01-99 using Button.) ② You may play by pressing the PLAY ( ) Button. ③ Adjust the volume with the DIGITAL VOLUME button. Listen to music in quiet areas using the micro speaker. - Page 16 ● Resume Function While listening to a file, press and hold the STOP ( ) Button (this will turn the unit off) when you power on the unit again (pressing PLAY ), the file will continue (resume) to play from the section you left off. ●...
-
Page 17: Erasing Files
Erasing files ※ Deleting is only available when the player is stopped. ● Deleting a Message One by One ① Select the file to delete using the Button. ② If you press ERASE, “ERASE” will be flickering on the LCD and the message to be deleted is displayed for confirmation. -
Page 18: Reserved Recording
Reserved Recording ※ To set a reserved (future) recording, the TIME Setting must be set. If you press the TIMER Button, the time (Hour/Minute/Day) displays. If the time setting is done, the correct Day/Hour/Minute/Second will appear on the display screen. To change it: ①... - Page 19 ⑤ 1) The reserved recording is initiated at every Nth time of every day 2) The reserved recording is initiated at every Nth time on Monday - Saturday 3) The reserved recording is initiated on a certain day of every week You select using and confirming is done using .
-
Page 20: Connecting External Device
Connecting External Device ● Connecting an External Microphone - Plug a pre-amplified microphone in the line in terminal of the body. ※ When an external microphone is connected to the line in, the built-in microphone is not operational. ● Connecting to External Devices You may record from almost any device using the line in and audio cable. - Page 21 AM/FM Radio When listening to the FM Radio, use earphones. They act as the antenna. You can also plug an antenna in the headphone jack of the player and use the speaker. * It is very convenient for you to listen to a broadcast using the AUTO SEEK Function. After selecting the radio mode, if you press and hold for about 1 second, it will stop at an audible broadcast channel.
- Page 22 You may set up to 10 reserved recordings for all the sections in AM/FM/VOICE. ● AM Region Setting You can change Voice Bank’s AM region setting from EUROPE (9) to USA (10) or USA (10) to EUROPE (9). 1. In VOICE or MP3 mode, press and hold the MODE button.
-
Page 23: General Specification
General Specification Voice Bank MODEL RECORD TIME 256M byte : 1086Min / 2173Min MODE ADPCM 32Kbps / 16Kbps FILE VOICE : 99個 / MP3 FM Record Stereo (76MHz~108MHz) AM Record 522 ~ 1659KHz Timer Record Dat / Daily/ Weekly VOICE... - Page 24 Repeat play NOR/ NOR1/ 1ALL/ ALL communication USB 1.1 System CPU200MHz more than , RAM 64MB more than, 20MB of free space windows98SE , windows2000 , windows ME , windows XP interface Sound card Sound blaster 16 compatible Display 640X480 more than Ext mic/line in ∮3.5 plug-in power microphone(mini plug / stereo) IMP less than 3KΩ...
- Page 25 Warranty ● If any defect or error occurs, stop using the product and contact the shop you purchased or Pogo Products Inc. General Directory Number: (714) 671-1854 ● Warranty (Warranty Regulation) Pogo! Products guarantees a free repair or service for a period of one year from the original date of purchase only.
- Page 26 ● If any defect occurs during the use of this product, contact the shop you purchased or Pogo Products Inc. ● Replacement, repairs (charge/free) or refunds must be in accordance with our policy and can be found at: http://www.pogoproducts.com/support.html ● If you have any further questions about this product, please contact Pogo Products Inc. PoGo! Products Inc.
- Page 27 --- Additional User information --- Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
