- Page 1 Serial to Ethernet Converter User’s Manual Version 1.1 2004 Infosystem Technology Corporation...
- Page 2 No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form of or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Infosystem Automation Corporation. © Copyright 2004, by Infosystem Technology Corporation. Version 1.1 All rights reserved.
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION........................1 1.1 F ..........................2 EATURES AND PECIFICATIONS 1.2 LED I ......................4 NDICATOR AND WITCH ESCRIPTION 2. RS232/422 SPECIFICATIONS AND WIRING................5 3. I/O SPECIFICATIONS AND WIRING* ..................7 3.1 2 , 24V DC ............................8 POINTS INPUT 3.2 2 , DC 0.5A D ........................ -
Page 4: Introduction
1. Introduction Infosystem WS-100 and WS-1000 Serial to Ethernet converters are ideal products for any RS-232/422/485 device to connect to an existing Ethernet network. With WS-100 and WS-1000 and related products, the controlling and monitoring of serial devices can be easily accomplished. -
Page 5: Features And Specifications
1.1 Features and Specifications RJ-45 Ethernet Port RS232/485/422 Size: 100*68*25(mm LED Indicator DC 24V Power Input RS232/485/422 Features: Allows RS-232/422/485 serial devices to be connected to Ethernet network via transparent data conversion and operates as an Ethernet node. Serial communication speed is up to 115.2 kbps. Supports ARP, ICMP, TCP, UDP, IP, DHCP, HTTP, Modbus/TCP, and 10Base-T Ethernet standard. -
Page 6: Specifications
Specifications: Model WS-1100 WS-1200 WS-1300 WS-1400 Items Network Interface 10/100BaseT, RJ-45 Protocol ARP, ICMP, TCP, UDP, IP, DHCP Client, HTTP Reset Built-in reset key to restore the defaults Watch Dog Timer Built-in hardware auto reset function 2 points, DC 24V 2 points, DC 24V 2 points, DC 24V Discrete I/O... -
Page 7: Led Indicator And Switch Description
1.2 LED Indicator and Switch Description LINK LED Indicator: Description The SYS LED blinks at a rate around 1 Hz, when CPU is working normally with the module. LINK If ON, the Ethernet connection is activated. If ON, the converter is transmitting data to the Ethernet. If ON, the converter is receiving data from Ethernet. -
Page 8: Rs232/422 Specifications And Wiring
2. RS232/422 Specifications and Wiring a. With “UART + 2 Digital Output + 2 Digital Input” Converter There are two terminal blocks at each side of the Gateway, one is 9 Pin terminal block and another is 13 Pin terminal block. The 1 pin of the 9 Pin terminal block is neighbor the RJ-45 Ethernet connector and the 1 of the 13 Pin terminal block is neighbor the 2PIN DIP Switch. - Page 9 Digital Input, 24V Signal Input DI-1 Digital Input, 24V Signal Input DI-2 Digital I/O Power Ground Power EGND Digital I/O 24V Power Power E24V Gateway Power Ground In Power +24GND POWER Gateway Power +24V In Power 2 Pin DIP Switch DIP Switch Normal Operation, This PIN define the Normal Operation Mode or Enter the Firmware update mode, when ON enter the Normal Operation Mode, when...
-
Page 10: I/O Specifications And Wiring
RS-232 Data Input /RS-422/RS-485/DX+ In/- RXD-2/DX+ RS-232 Data Output /RS-422/RS-485/DX- Out/- TXD-2/DX- COM2 RS-232 Request to Send /RS-422/TX+ Out/- RTS-2/TX+ RS-232 Clear to Send, /RS-422/Tx- In/- CTS-2/Tx- 13 Pin Terminal Block 13 Pin TB RS-232 Data Input /RS-422/RS-485/DX+ In/- RXD-23DX+ RS-232 Data Output /RS-422/RS-485/DX- Out/- TXD-23DX-... -
Page 11: Points, 24V Dc Input
The specifications and wiring diagrams of DI and DO modules are listed here. 4 Port Converter do not support the I/O feature. 3.1 2 points, 24V DC input a. Specification: Model DIGITAL INPUT Specification Number of input points 2 points Insulation method Photo Coupler Rated input voltage... -
Page 12: Points, Dc 0.5A Digital Output
3.2 2 points, DC 0.5A Digital Output a. Specification: DIGITAL OUTPUT Model Specification Number of input points 2 points Insulation method Photo coupler Rated load voltage 24VDC 21.6VDC ～ 26.4VDC Operating voltage range Type NPN/Sink Max. load current 0.5A/pt Leakage current at OFF circuit 0.1 mA or less Max. -
Page 13: Modbus Address Mapping
4.Modbus Address Mapping* *(Only the Model WS-1122, WS-1222, WS-1322 offer Modbus Read/Write) The discrete I/O points of the Ethernet Converter can be easily control and monitor through Modbus/TCP protocol. The Modbus address mapping with discrete I/O is described below. 4.1 Modbus Holding Register 40001 The 2-point digital output of the Ethernet Converter is mapped with the Modbus holding register “40001”. -
Page 14: Software Installation
5. Software Installation 5.1 Insert the software CD that came with Ethernet Converter into the CD-ROM drive, refer to the path D: \Tool\Install\ (D:\ stands for the CD-ROM drive) and double click on setup.exe to install the Ethernet I/O Utility Program. The following screen is displayed. - Page 15 5.3 You can change or use the default folder name displayed on the screen and then click on Continue to start copying files. 5.4 The following screen shows the copying progress.
- Page 16 5.5 When the installation is completed successfully, the following screen came, and presses the OK button will terminate the installation program.
-
Page 17: Configuring The Ethernet Converter
6. Configuring The Ethernet Converter 6.1 Configuring With Ethernet Converter Setup Program 6.11 To start Ethernet Converter Setup program, click on Start Programs Ethernet Converter Utility Ethernet_Converter_Setup 6.12 The Ethernet I/O Setup window is shown as below. 6.13 Click on the button to search all the Ethernet Converter connected in the same subnet using the UDP broadcast protocol. - Page 18 6.14 Double click on the desired Ethernet Converters whose configuration is to be modified, as shown below. Double click on the desired Ethernet Converter...
- Page 19 6.15 The following window is displayed after double click on the desired Ethernet Converter which allow user to modify the configuration of the selected Ethernet Converter. Please refer to the following description for setting up the parameters of the Ethernet Converter.
- Page 20 Gateway IP: The IP address of the router. The default Gateway IP address is: 192.168.192.254. Ask your network administrator for assistance, if in doubt. DHCP client: If this option is enabled, that means the IP address, Subnet mask and Gateway IP address of the Ethernet Converter are set dynamically by the DHCP Server.
- Page 21 Converter, otherwise the data transfer request will not be accepted by the Ethernet Converter. To erase an existing password, just leave the Access password text box blank. 6.16 User must ensure the command port number that the Ethernet I/O Setup program used is the same as the Command Port parameter which has been configured in the Ethernet I/O setup window.
- Page 22 6.17 User needs to use the right password to enter the Ethernet I/O Setup window if password protection is enabled. Click on Option Password as shown below. When the Password window opens, input the correct password that is the same as the one which has been set in the setup window, and then click on OK .
- Page 23 6.18 To exit the Ethernet I/O Setup program, click on Option Exit as shown below. 6.19 To show the information about Ethernet I/O Setup program, click on Help About Ethernet I/O Setup as shown below.
-
Page 24: Configuring With Web Browser
And the “About Ethernet I/O Setup” window opens, view the description shown on the screen, and then click on OK . 6.2 Configuring With Web Browser 6.21 Start web browser and search the web site using the address:... - Page 25 http://192.168.192.250, which is the default IP address of the Ethernet Converter. The web page is shown as below. Click button to go into the configuration web page. Remember to key-in the password if authorized entry is required before you click button.
- Page 27 6.23 Now the Ethernet Converter has been updated and the browser refresh to the login web page again.
-
Page 28: Appendix 1: Command Mode Support
Appendix 1: Command Mode Support Use the command mode to set up the Ethernet Converter, it needs an application software to handle these actions. Command ‘X’ for Broadcast ‘X’ or ‘x’ Command Syntax : ‘X’<magic code> ‧Magic code = 99.130.83.99 Return : ‘AX’<MAC Address>’/’<IP Address>’/’<Device ID>... - Page 29 Command ‘M’ for MAC address Setting ‘M’ Command, not for the User Purpose: Set the MAC address of the Web Server Format: ‘M’ <Old MAC Address>/<New MAC Address>/ <Factory Password> Return: ‘AM’ for accept or ‘CM’ for cancel Command ‘I’ for IP setting ‘I’...
