Netween Router User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C140T and is the answer not in the manual?

Questions and answers

Related Manuals for NETWEEN C140T

Summary of Contents for NETWEEN C140T

  • Page 1 Netween Router User Manual...

  • Page 2: Table Of Contents

    Table of Contents Components Product Feature Installation Precautions Product & Explainations 1. Front of the Netween 2. Back of the Netween Netween Default Connection 1. General Internet Network 2. Environment using a Modem Netween Default Set 1. Internet Connection Settings...

  • Page 3: Components

    Netween Router Components Netween Router 1M LAN cable User Manual Power Adapter Netween Router Product Features C140T Wireless Network Protocol -. 802.11n(draft 2.0), 802.11b/g -. PPPoE -. 1T1R -. DHCP -. Up to 300Mbps -. MAC cloning -. Multiple SSID -.

  • Page 4: Installation Precautions

    If the exterior adapter devices of the Netween are cleaned with alcohol, benzene, acetone, etc. or any flammable liquids, this alteration to the surface will cause chemical changes. In case of contact with other material please wipe the area with a dry cloth.

  • Page 5: Product & Explainations

    Product & Explaination Front of the Netween Power / ON Shows the power supply is normal WLAN / Flicker Shows wireless is in operating conditions WPS / only flickers when activated WPS supported devices and confirmation process is in progress...

  • Page 6: Back Of The Netween

    Back of the Netween Reset ON/OFF Power Switch...

  • Page 7: Netween Default Connection

    Netween Default Connection General internet environment Environment using a Modem...

  • Page 8: Netween Default Set

    Netween default set Internet connection set If internet is automatically connected, internet can be used without additional connection settings 1. Dynamic IP(DHCP) Netween router is set to automatically receive IP method in default. Enter address http://192.168.1.1- Expert Setting- WAN Interface Setting...

  • Page 9: Static Ip Set

    2. Static IP Set when router is connected 1) After accessing to 192.168.1.1 on the internet address bar, change the internet to (Static IP) from (Expert Setting) (Network Setting) (WAN Interface Setting) and enter the given Static IP and click SAVE 2) Savings are completed when the screen turns white and back to its original form.

  • Page 10: Pppoe Set

    3. PPPoE (ADSL User) Set when router is connected 1) After inserting internet access address 192.168.1.1 go to [Expert Setting] [Network Sertting] [WAN Interface Setting] and change the internet connection form to [PPPoE] and insert the user ID and password of the telecommunication company that you have signed up, click SAVE 2) Savings are completed when the screen turns white and back to its original form.

  • Page 11: Wireless Default Setting And Security Setting

    Wireless default setting and security setting You can choose type of encryption (Not Certification, WEP, WPA-PSK, WPA-PSK2, etc. ) 1. How to setting wireless security Available change Subsystem Identification 2. How to check wireless security 1) You can choose type of encryption (Not Certification, WEP, WPA-PSK, WPA-PSK2, etc ).

  • Page 12: Firmware Upgrade

    Firmware Upgrade - It is better to upgrade to the latest version periodically to increase function of Netween products. 1. Manual upgrade 1) Download the right firmware file as the router model through the homepage (http://www.netween.co.kr) 2) Click the left menu shown in the picture below...

  • Page 13: Load Default Setting

    Load Default Setting(RESET) - Product will return to its initial settings as when was first manufactured. After resetting, all settings will return to load default settings so user must set the settings again. 1. Connect the adapter to the router and check the status of the LED 2.
  • Page 14 FCC ID: N7SC340T FCC ID: N7SC140T This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
