4 Microphone Wireless Systems
Sistema de 4 micrófonos inalámbricos
USERS MANUAL
for Professional Series Models:
(AVT-4BP1 and AVT-4BP2 Beltpack Transmitters)
Please read and keep for future reference.
Distributed by: www.avtronicsworld.com
›
AVT-QUAD1
›
AVT-QUAD2
›
AVT-QUAD2B
Advertisement
Table of Contents
Summary of Contents for AVTronics AVT-QUAD1
- Page 1 4 Microphone Wireless Systems Sistema de 4 micrófonos inalámbricos USERS MANUAL for Professional Series Models: › AVT-QUAD1 › AVT-QUAD2 › AVT-QUAD2B (AVT-4BP1 and AVT-4BP2 Beltpack Transmitters) Please read and keep for future reference. Distributed by: www.avtronicsworld.com...
- Page 2 FCC INFORMATION AVT-QUAD1R and AVT-QUAD2R Receiver: TRANSMITTER SPECIFICS AVT-QUAD1 and AVT-4BP1 Handheld Transmitters: Channel A (Purple) 696.65 MHz FCC ID: Y3I-AVTQUADHH8 Channel B (Yellow) 693.65 MHz FCC ID: Y3I-AVTQUADHH7 Channel C (Pink) 631.75 MHz FCC ID: Y3I-AVTQUADHH6 Channel D (Gray) 625.15 MHz...
- Page 3 FEATURES AND SPECIFICATIONS LIST › Use up to 4 wireless microphones at once (8 with an additional system – to use 2 systems use separate frequency groups such as AVT-QUAD1 and AVT-QUAD2 or AVT-QUAD2B) › Far reaching working distance: 200 feet ›...
- Page 4 HELPFUL DIAGRAMS FRONT Power Channel A Channel B Channel C Channel D Switch Volume Volume Volume Volume Control Control Control Control Botón de Control de Control de Control de Control de Encendido Volumén Volumén Volumén Volumén BACK (Actual frequencies will vary by model) (Actual frequencies will vary by model) Channel D Channel C...
- Page 5 RECEIVER BELTPACK On/Off Switch Botón de Encendido On/Off Switch Botón de Encendido color coded by frequency codigo de color de frecuencia color coded by frequency codigo de color de frecuencia CAUTION! To lower the risk of potentially harmful electric shocks please do not perform any of the following procedures: ›...
- Page 6 GETTING STARTED Step 1 Verify that all equipment including the sound system is turned off. Step 2 Attach power supply cord to receiver. Step 3 Make sure you have batteries in each transmitter that you plan to use. Step 4 Plug power supply cord from receiver into the wall.
- Page 7 CÓMO CONECTAR EL EQUIPO Paso 1 Verifique que todo el equipo incluyendo el sistema de sonido este apagado. Paso 2 Conecte el cable del suplidor de energía al recibidor. Paso 3 Asegurese que tiene baterías para cada transmisor que usted se proponga usar.
- Page 8 www.avtronicsworld.com Made in China...
