Instruction Manual
IDM 61/62T
Digital Multimeter
EN
DE
ES
IT
FR
IDM 62T

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDM 61 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RS IDM 61

Summary of Contents for RS IDM 61

  • Page 1 Instruction Manual IDM 61/62T Digital Multimeter IDM 62T ...

  • Page 2: Safety Information

     Safety Information Read and understand this Instruction Manual completely before using this instrument. Failure to observe the warnings and cautions in this Instruc- tion Manual may result in injury or death, or damage to the instrument and other equipment or property. If this instrument is used in a manner not specified in these instructions, the protection provided by the instrument may be impaired.

  • Page 3: Maintenance

    This instrument should be calibrated yearly, or more frequently if used in harsh conditions or if it is suspected of being inaccurate. For calibration and repair contact RS Components - the address is given at the end of these instructions.

  • Page 4: Measuring Ac/Dc Voltage And Frequency

    Measuring AC/DC Voltage and Frequency Continuity and Diode Test Bad Diode Black Black Good Diode Black Black EN - 3...
  • Page 5 Resistance Capacitance Measurement (Capacitance for 62T only) Note – To improve the measurement accuracy of a small value capacitor, record the reading with the test leads open circuit, then substrate the residual capacitance of the Instrument and leads from the final measurement.
  • Page 6 Measuring DC / AC Current (For 62T only) Disconnect Temperature °C , °F EN - 5...

  • Page 7: Display Hold

    Hold Display Manual Ranging and Auto Ranging Auto Power-off (Battery Saver) 10 min EN - 6...

  • Page 8: Disable Auto Power-Off

    Disable Auto Power-off Non-Contact Voltage Sensing (VoltSense) 1. The VoltSense function will operate irrespective of the position of the function rotary switch, including the OFF position. 2. Remove the test leads from the instrument as they are not used for the VoltSense test.

  • Page 9: Fuse Replacement

    Fuse Replacement (For 62T only)  WARNING Disconnect the test leads from the circuit and the instrument before removing the rear cover.  Caution Use only a replacement fuse of the type and rating given in the specifications. Refer to the following figure to replace the fuse : Battery Replacement When the low battery indicator "<"...

  • Page 10: Specifications

    Specifications General Specifications Display : 2000 counts. Polarity Indication : Automatic, positive implied, negative indicated. Overrange Indication : “OL” or “-OL”. Batteries Life : 250 hours approx with Alkaline cells. Low Batteries Indication : drops below the minimum operating voltage. Auto Power Off : Approx 10 minutes after last operaton.

  • Page 11: Electrical Specifications

    Temperature Coefficient : 0.27 x Spec. Accy / C <18C or >28C; (0.15 x Spec.Accy / F,< 64.4F or > 82.4F). Power Requirements : Qty. 2 x 1.5V Alkaline type AA batteries. Fuse (For 62T only) : 10mmx38 mm 10Amp 600V ac/dc HBC, Little fuse KLKD10 or equivalent.
  • Page 12 DC / AC Current (For 62T only) Range DC Accuracy AC Accuracy Voltage Burden 2.000A ±(1.5% + 5 dgt) ±(1.0% + 3 dgt) 2V max 50Hz ~ 500Hz * 10.00A ** Overload Protection : A input : 10A (600V) fast blow fuse * AC Conversion Type : Conversion type and additional specification are same as DC/AC Voltage.
  • Page 13 Diode Check and Continuity Range Resolution Accuracy  10 mV ±(1.5% + 5 dgt)* * For 0.4V ~ 0.8V Max.Test Current : 1.5mA Max. Open Circuit Voltage : 2V Overload Protection : 600V rms. Frequency (For 62T only) Range Sensitivity Accuracy 2000Hz ~200.0KHz >1.5 Vac rms, <5 Vac rms...

  • Page 14: Limited Warranty

    Some states or countries laws vary, so the above limitations or exclusions may not apply to you. For full terms and conditions, refer to the current RS Catalogue. EN - 13...
  • Page 15 P.O. Box 12182, Vorna Valley, 1686 20 Indianapolis Street, Kyalami Business Park, Kyalami, Midrand South Africa www.rs-components.com Asia RS Components Pte Ltd. 31 Tech Park Crescent Singapore 638040 www.rs-components.com China RS Components Ltd. Suite 23 A-C , East Sea Business Centre Phase 2 , No.

This manual is also suitable for:

Idm 62t
