TANGO F3B/F3F
Unpacking
•
Please unpack the plane carefully making sure that you have retrieved all
of the small parts.
Don't throw the box out until you are 100% sure it's empty!
•
Check that all the parts are supplied.
•
If any are missing please contact your vendor immediately.
•
- Instruction Manual
Advertisement
Summary of Contents for RCRCM TANGO F3B
- Page 1 TANGO F3B/F3F - Instruction Manual Unpacking • Please unpack the plane carefully making sure that you have retrieved all of the small parts. Don’t throw the box out until you are 100% sure it’s empty! • Check that all the parts are supplied.
- Page 2 Wings Control horns for ailerons and flaps Make up control rods and clevises using the parts supplied. • Zero the servos by using your R/C unit. • Remember! Aileron servo arms can be set to 90 degrees, but the flaps •...
- Page 3 When the wiring harness is positioned inside the wing and accessible, • servos can be installed. First, check the position of the servos to make sure they are all • symmetrical (In the same place) in each wing. • Install the control rods on to the servos and check that they do not bind, are snug but not too loose or to tight.
- Page 4 Fuselaje...
- Page 5 F3B/F3F designed by carlos pisarello Specifications: Wing span: 2.90 m Length: 1.44 m Wing aerofoil: RC series Wing area: 54.1 dm2 Control surface: ailerons, flaps, elevator, rudder Fly weight: 2100g Elevator: Up 4mm Down 3mm Ailerons : Up 10 mm Down 5mm V tail /Rudder: 6 mm left/right...
