User's Guide
Dissolved Oxygen/Temp
Battery
Compartment Cap
Main Display
Hold/Max/Min
Button
Protective
Cap
Waterproof Tester
Lanyard Connection
Function
Mode Button
Power /
Calibration Button
Probe Coller
Probe Module
Probe Cap
AM-DO-01
Advertisement
Table of Contents
Summary of Contents for Aquasol Digital AM-DO-01
- Page 1 AM-DO-01 User's Guide Dissolved Oxygen/Temp Waterproof Tester Lanyard Connection Battery Compartment Cap Main Display Function Hold/Max/Min Mode Button Button Power / Calibration Button Probe Coller Probe Module Protective Probe Cap...
- Page 2 Index Introduction Features Specifications Accessories Device Description Probe Description Display Description Preparation Calibration Advanced Setting Membrane Cap Replacement...
- Page 3 Introduction : Thank you for purchasing/ buying our product, the microprocessor- based waterproof DO/O2/Temp tester. You can now measure a wide range of Dissolved Oxygen and temperature, with a replaceable probe. Please read the manual carefully before using the tester. Features : A large LCD, which displays simultaneously DO or O2 and temperature...
- Page 4 Probe Description DO Probe Anode Membrane Cap Cathode Display Description mg/l% uS mS ppt PPM mV pH Unit Measuring Value Calibration Mode DO O COND SALT TDS ORP PH Function Mode Maximum value °C Temperature MAX CAL Battery Indicator °F Consumption MIN CAL Automatic...
- Page 5 Functions of Keyboard : Power/calibration 1. Press Button to switch power On or Off. 2. Press and hold button to enter calibration mode. Function Mode 1. Press to switch DO (mg/l), DO (ppm) and O2 (%) MODE 2. Press and hold button to change degree oC or oF Hold/Max and Min 1.
- Page 6 Measurement <DO> 1. Remove the probe cap and turn on the power. Wait for 10 minutes to 30 minutes for probe to polarize. The reading should be approx. 101.7% (saturation) after the probe has completely polarized. 2. Select the desired units of measure by pressing until they are MODE shown in the display.
- Page 7 Membrane Cap Replacement 1. Do not touch the membrane as skin oils will interfere with the oxygen permeability rate of the membrane. Replace the cap carefully. 2. It is recommended that the probe remains attached to the meter during this replacement process. 3.
- Page 8 Dissolved Oxygen/Temp Waterproof Tester...
