SMI440 v3_Layout 1 6/21/13 9:43 AM Page 1
SMI44 BT
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
Distributed by SMC Global®
SMC Global® is a registered trademark or The Singing Machine Co., Inc.
SMC Global® es marca registrada de The Singing Machine Co., Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMI440BT and is the answer not in the manual?

Questions and answers

Summary of Contents for SoundX Blast SMI440BT

  • Page 1 SMI440 v3_Layout 1 6/21/13 9:43 AM Page 1 SMI44 BT INSTRUCTION MANUAL MANUAL DE INSTRUCCIONES Distributed by SMC Global® SMC Global® is a registered trademark or The Singing Machine Co., Inc. SMC Global® es marca registrada de The Singing Machine Co., Inc.

  • Page 2: Important Safety Information

    SMI440 v3_Layout 1 6/21/13 9:43 AM Page 2 Warnings CAUTION WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT AND FULLY INSERT.

  • Page 3: Location Of Controls

    SMI440 v3_Layout 1 6/21/13 9:43 AM Page 3 Location of Controls 1. Main Speakers 2. Microphone for calls 3. Bluetooth Indicator 4. Bluetooth Pairing/ Play/Pause ;Button Receive Call/Transfer Call/Redial Call/End Call Volume (For Bluetooth Mode) Buttons 7. Power On/Off Button 8.

  • Page 4: Installation

    SMI440 v3_Layout 1 6/21/13 9:43 AM Page 4 Installation Plugging the Unit In/Recharging the Battery Insert the small end of the AC adapter into the DC IN jack on the rear of the unit. Insert the other end (with the 2 blades) into a conveniently located AC outlet having 110-240V AC, 50/60Hz.

  • Page 5: Operation

    SMI440 v3_Layout 1 6/21/13 9:43 AM Page 5 Operation Pairing a Bluetooth Device Press the Power On/Off button to turn the unit on; the Bluetooth indicator will blink yellow. After four seconds, it will slowly blink blue, and then after six seconds, it will start blinking rapidly to indicate it is in Pairing mode.
  • Page 6 SMI440 v3_Layout 1 6/21/13 9:43 AM Page 6 Operation Using a Bluetooth Device Press the Power On/Off button to turn the SMI440BT on. With a unit paired (see previous section), operate your Bluetooth device and its sound will be heard through the SMI440BT’s speakers.
  • Page 7 SMI440 v3_Layout 1 6/21/13 9:43 AM Page 7 Operation Receiving/Dialing a Phone Call This unit is equipped with a built-in microphone (located below the brand plate on front panel), which allows you to make or end calls of a connected mobile phone through this unit.
  • Page 8 Headphone jack on your external audio unit and the other end into the LINE IN jack on the rear of the SMI440BT; the unit will automatically switch to Line In mode. The Bluetooth indicator’s color will change to yellow, indicating that the unit is in Line In mode.

  • Page 9: Troubleshooting Guide

    No Sound – General • External device’s volume is set to minimum; raise volume. • The SMI440BT’s volume is set to minimum; raise volume. • The audio cable is plugged in. Unplug cable if not using Line In function. The Bluetooth device cannot pair or connect with the unit.

  • Page 10: Specifications

    SMI440 v3_Layout 1 6/21/13 9:43 AM Page 10 Specifications GENERAL Power ......................110-240V AC, 50/60Hz Power Output ........................DC 15V 2A Max. Output Power.............. 2x5 W (Main) + 20W (Subwoofer) Dimensions ..........13.11 x 8.46 x 9.88 inches (33 x 21.5 x 25.1 cm) Weight........................
  • Page 11 SMI440 v3_Layout 1 6/21/13 9:43 AM Page 11...

  • Page 12: Notes Importantes

    NOTES IMPORTANTES Évitez d'installer cette unité dans les endroits exposés à la lumière du soleil directe ou près de la chaleur rayonnant des appareils tels que les radiateurs électriques, sur l'autre matériel stéréo qui rayonne trop de chaleur, des endroits manquant de la ventilation ou des zones poussiéreuses, des endroits sujet à...
