Summary of Contents for 1byone 436NA-0006
- Page 1 436NA-0006 436UK-0006 436DE-0006 USER MANUAL SOUND BASE SYSTEM...
-
Page 2: Table Of Contents
Contents Features ........................2 Contents For your Attention.....................3-4 Panel........................5-6 Wall-mounting......................7-8 Connections......................9-10 Remote Control.....................11-12 Basic Playback......................13 Trouble shooting......................14 Specifications......................15... -
Page 3: Features
Features Thanks for your purchase of our product. Please read through this manual before making connections and operating this product. Retain this manual for future reference. Line input AUX input Optical input USB slot ARC function Bluetooth playback Package Contents: User manual Remote control Wall plug(2x) and screw(2x) and bracket screw(4x) -
Page 4: For Your Attention
For Your Attention IMPORTANT NOTES Please read through this manual before making connections and operating this product. Retain this manual for future reference. Don't open the cabinet of this unit. No user-serviceable parts inside. Refer servicing to qualified personnel only. Switch off the unit when you don't use it. -
Page 5: For Your Attention
For Your Attention FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 6: Panel
Panel FRONT PANEL: 1 DISPLAY SCREEN 2 REMOTE SENSOR... - Page 7 Panel REAR PANEL: 1 HDMI 2 AUX INPUT 3 OPTICAL DIGITAL AUDIO INPUT 4 AC INPUT SIDE PANEL: 1 STANDBY 2 SOURCE 3 USB SLOT 4 VOLUME- 5 VOLUME+ 6 LINE IN...
-
Page 8: Wall-Mounting
Wall-mounting Mounting soundbar on a wall 500mm In order to prevent injuries,the sound base device must be securely fasten to the wall in accordance with the below Diagram 1 installation instructions. 1.Drill the two holes(about 6mm diameter ) in the wall and keep the distance between drill holes of the sound base is 500mm.As shown in the picture on the right(diagram 1). - Page 9 Wall-mounting Mounting soundbar on a wall 4.Insert the wall-mounting bracket supplied into the pedestal of the sound base.As shown in the picture on the right(diagram 4). Diagram 4 5.Use the bracket screws supplied to insert the wall-mounting bracket hole and tighten.As shown in the picture on the right(diagram 5).
-
Page 10: Connections
Connections Connections Connections Connections LINE IN/AUX IN LINE IN/AUX IN LINE IN/AUX IN LINE IN/AUX IN AUDIO INPUT This sound base have two extra groups of This sound base have two extra groups of This sound base have two extra groups of This sound base have two extra groups of audio input terminals. -
Page 11: Connections
Disconnected the bluetooth on the smart phone to switched off the bluetooth connection. Model:1byone BS015 Note: Bluetooth connection range in 10 meters. The bluetooth pairing model 1byone BS015 in your device was not deleted. In bluetooth mode,[PLAY/PAUSE],[NEXT], [PREVIOUS], [VOLUME+/-] etc. are also active. -10-... -
Page 12: Remote Control
Remote control Remote Control Operation Insert the batteries into the remote control. Point the remote control at the remote sensor on the front panel. The remote control works within a distance of about 8 metres from the sensor and within an angle of about 30 degrees from the left and right side. -
Page 13: Remote Control
Remote Control 1 STANDBY 2 VOLUME+ 3 PREVIOUS 4 PLAY/PAUSE 5 VOLUME- 6 LINE/AUX 7 BT(BLUETOOTH) 8 ARC 9 MUTE 10 NEXT 11 USB 12 OPTICAL -12-... -
Page 14: Basic Playback
Basic Playback Operation STANDBY Press to switch on the unit. Press it again to put the unit in standby mode. Press to enter to USB mode. Press to enter to BT(BLUETOOTH) mode. Press to enter to OPTICAL IN mode. Press to enter to ARC mode. LINE/AUX Press repeatedly to switch between LINEand AUX IN mode. -
Page 15: Troubleshooting
Troubleshooting Before resorting to maintenance service, please kindly check by yourself with the following chart. Symptom Cause(s) Remedy No Power Please check that the AC power cord The AC power cord is not connected to the power supply or is not connected to a power supply is connected securely. -
Page 16: Specifications
Specifications Power supply AC ~100-240V,50/60Hz Temperature -10~+35 Working 5%~90% environment Relative humidity Power output (Max) 20WX2 Frequency response 3dB(20Hz~20kHz) -15-...
