Installation Guide
RE656 CryptiX™-Compatible Helipad™
Features
• Secure, 4 to 10 digit code to disarm
• 1-button arming
• 2-way RF, Shows system status
• Mounts on wall via VHB® tape, or screws
• Low Battery indication
• 1-2 year battery life
Enrollment
• Place panel into Bluetooth enrollment mode.
• Hold the pair button on the side of Helix for 3 seconds (until it
beeps).
• Place Helipad into Bluetooth enrollment mode by following the below
steps.
An unenrolled HeliPAD
screen will appear as
such.
• To configure the Helipad, log into the web based dealer portal
Installation
• Place Helipad near exit or entry doors. Use either the VHB tape or a
mounting screw (#4 or #6) to mount the Helipad in place
RE656_Helix-Compatible_HeliPAD_Instructions.doc
Press the Helipad menu
button to enter the
settings menu.
VHB tape
24-Hour Tech Support Line: (715)808-0164
www.ResolutionProducts.com
Arming LED will flash
green and red.
Press the select button
to enroll the Helipad.
Helix with beep once it
accepts enrollment.
Mounting hole
Page 1 of 4
26-Feb-15
Advertisement
Summary of Contents for Resolution RE656 CryptiX
- Page 1 Installation Guide RE656 CryptiX™-Compatible Helipad™ Features • Secure, 4 to 10 digit code to disarm • 1-button arming • 2-way RF, Shows system status • Mounts on wall via VHB® tape, or screws • Low Battery indication • 1-2 year battery life Enrollment •...
- Page 2 Operation • Arm Stay or Arm Away Activated by Activated by Arm Stay: Arm while Arm Away: Arm while pressing Arm pressing Arm home is occupied home is unoccupied Stay button Away button • Panic Alarm Activated when Arm Panic Alarm: Authorities Stay &...
- Page 3 • Checking System Status System AC Power System AC Power Use the “Menu” Connected Trouble Removed button to see exactly what is causing any System Trouble. • Panel will disarm upon receiving a proper disarm number sequence. • A disarm number sequence can be setup to a 4-10 digit number. •...
-
Page 4: Specifications
Specifications subject to change without notice. Notices Warranty Resolution Products, Inc. will replace products that are defective in their first five (5) years. FCC Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference.
