KidKraft 53198A Assembly Instructions Manual

Home Cookin' Kitchen
© 2011 KidKraft, LP
Please retain this information
for future reference
PARTS LIST
1
2
10
9
15
16
24
23
HARDWARE:
A. Screw x 4
3/8 in, 8 mm
B. Light Pink Bolt x 10
5/8 in, 16 mm
C. Latch x 2
D. Nut x 12
E. Pink Screw x 6
1 in, 25 mm
CAUTION:
ADULT ASSEMBLY REQUIRED. Hardware contains
small screws with sharp points. Keep unassembled
parts out of the reach of small children.
WARNING:
CHOKING HAZARD. Small parts and sharp points, not suitable for children under 3 years.
WARNING:
If used improperly, your kitchen may be pulled over or fall, creating risk of injury or damage. To minimize this risk,
we recommend that you use the enclosed wall anchor kit, which gives you the option of attaching the kitchen to a wall.
In addition, children should not be permitted to climb or pull on the kitchen.
Assembly Instructions
3
17
19
25
F. White Screw x 2
1 in, 25 mm
G. Screw x 14
1 in, 25 mm
H. Cross Dowel Nut x 20
I. Light Pink Cross Dowel
Bolt x 4
1 1/2 in, 38 mm
J. Dark Pink Cross Dowel
Bolt x 6
1 1/2 in, 38 mm
USE AND MAINTENANCE:
-Use on level surfaces only
-Please check assembly at regular intervals, and frequently
tighten hardware if necessary. If maintenance is not carried
out, the product could cease to function properly.
4
5
11
12
13
x4
18
20
x2
27
26
K. Cross Dowel Bolt x 10
1 1/2 in, 38 mm
L. Washer x 2
M. Cross Dowel Bolt x 2
1 in, 25 mm
N. Cross Dowel Bolt x 4
1 1/4 in, 32 mm
O. Screw x 4
9/16 in, 14 mm
P. Pink Screw x 8
3/4 in, 20 mm
Item #53198A
To order replacement parts,
please visit www.kidkraft.com
6
14
21
x2 22
28
Q. Latch x 2
R. Dark Pink Bolt x 2
5/8 in, 16 mm
S. Dark Pink Screw x 2
1 in, 25 mm
Allen Wrench x 2 pc
The following tool
(not included) is
required for assembly:
®
Phillips screwdriver
Customer Service
1-800-933-0771
www.kidkraft.com
