Summary of Contents for Konig KN-SCOPE60
- Page 1 KN-SCOPE60 REFLECTOR TELESCOPE MANUAL ANLEITUNG MODE D’EMPLOI GEBRUIKSAANWIJZING MANUALE MANUAL DE USO HASZNÁLATI ÚTMUTATÓ KÄYTTÖOHJE BRUKSANVISNING NÁVOD K POUŽITÍ...
- Page 2 CAUTION! Under NO circumstances should be looked directly into the sun. Direct observation of the sun is very dangerous for the eyes. Description: Figure 1...
- Page 3 1. Open End of Tube Right Ascension Clamp Screw 2. Diagonal Mirror (inside) Clock Drive Gear 3. Nuts for Sight Scope Bracket Horizontal Axis Clamp Screw 4. Sight scope Clamp Screw for Tripod Leg 5. Sight Scope Bracket Rubber Tips 6.
- Page 4 22. Main Mirror 23. Polar Axis Auxiliary Screw 24. Polar Axis Clamp Screw 25. Aligning Screw for Sight Scope 26. Clamp Handle 27. Declination Attachment 28. Hour Circle 29. Declination Circle 30. Right Ascension Flexible Cable Control 31. Right Ascension Attachment 32.
- Page 5 Internal hexagonal bolt Body belt Equatorial mount Base mount Umbrella screw Figure 4...
- Page 6 Purpose: A telescope is an optical system designed to magnify from a distant. A refl ector telescope consists of an open tube with a curved mirror at the bottom. The open end of the tube is pointed at the object in the sky and the entering light rays strike the mirror at bottom. The rays, refl ected from this mirror, strike a second diagonal mirror.
- Page 7 Aligning the sighting scope 1. Look through the sighting scope after focusing the telescope (4). If the sighting scope is not in focus, turn the eyepiece (6) around on until the view is sharp and clear. 2. If the object you see in the telescope is not in the center of the sighting scope crosshairs, do the following: tighten and loose the four screws (25, fi...
- Page 8 Using the telescope Before learning the technical details of this telescope, the telescope is ready for observing stars, planets and the moon. Turn the declination axis clamp screw (11), the right ascension clamp screw (12) and the polar axis clamp screw (24) to adjust the position of the telescope. Turn the horizontal axis clamp screw (14) so the telescope can swing in a circle.
