Summary of Contents for Estarling Impact V
-
Page 2: Table Of Contents
CONTENTS： ………………………………………………………………………………………… User notes……………………………………………………………………………………….1 1. Preparation before using…………………………………………………………………….2 2. Pay attention…………………………………………………………………………………3 Product Specification…………………………………………………………………………...4 Appearance Reference …………………………………………………………………………5 1. On-board buttons…………………………………………………………………………….5 2. Buttons of Remote Control…………………………………………………………………..6 Frame Set-up…………………………………………………………………………………….7 1. Before set-up…………………………………………………………………………………7 2. Setting up your wireless network and your connected WI-FI digital frame………………….7 Operation Instruction………... -
Page 3: User Notes
User Notes ………………………………………………………………………………………………………………………… In order to avoid the consuming of battery for the first-time use of this album, there is a plastic paper of insulation which separates the battery on the cover of control remote of the packing box; please pull the plastic paper down before using. The method of installing and changing the battery: it needs to change the battery when the album is used for a long time or the remote control is not sensitive or the distance of remote control is very close. -
Page 4: Pay Attention
Pay attention Only working in the defined range of AC/DC power supply. AC adapter inputs 100-240V~50/60Hz and outputs DC of 9V, 1.5A. Do not use power adapter which does not meet the requirement. If not using the album for a long time, please cut off the AC power of the adapter to ensure safety. -
Page 5: Product Specification
Product Specification ……………………………………………………………………………………………………..• LCD Display: 8-Inch LCD screen (800 X 600 pixels) • Communications: Internal 802.11b/g (WEP64, WEP128, WPA1, WPA2) • Interface: MMC/SD/MS card slot; USB 2.0 client port • Memory Size: On-board FLASH memory 256M • Remote Control for PC-less easy setup •... -
Page 6: Appearance Reference
Appearance Reference ……………………………………………………………………………………………………….. On board buttons Esc button: Go back to the upper menu Up button: Press it going upwards Down button: Press it going downwards Left button: Press it going to the left direction Right button: Press it going to the right direction Enter button: It functions as the OK button under the menu and the settings -05-... -
Page 7: Buttons Of Remote Control
Buttons of Remote control Power button: Press it to turn on the power and then turn off the power Play/Pause button: it functions as the play and pause switch when playing pictures, videos; it can use as the selective play under the status of picture browsing. Esc button: Go back to the upper menu Del button: Delete files you don’t like Menu button: The return function can be implemented when processing this button while... -
Page 8: Frame Set-Up
Frame set up Before set-up Please have the following items ready before you begin the setup of your Connected Wi-Fi Digital Frame: Your Connected Wi-Fi Digital Frame, along with the power supply, USB cable. Internet connected Wi-Fi network with known SSID (network name), authentication type and the corre. - Page 9 STEP2: If your frame cannot locate a Wi-Fi signal, it will show a message indicating that no Wi-Fi network is connected. Please press the Enter button on your Remote Control with Scan again. STEP3: The frame will scan for any available Wi-Fi networks automatically. Press to highlight your specified Wi-Fi network, and then press Enter: -08-...
- Page 10 Step4: Please enter your password by pressing the virtual keyboard buttons displayed on the screen by pressing to highlight your entries and then press Enter. Step5: Once the Wireless Network has been completed, the following message will be displayed on the frame: You have now completed the set-up process and are ready to start enjoying your Connected Wi-Fi Digital Frame.
-
Page 11: Operation Instruction
Operation Instruction ……………………………………………………………………………………………………..Menu Place the frame well and connect it into the power adapter and the network, the main menu of power-on picture will appear when pressing the ESC button on the board.: Use the direction key to select the function icon and enter into it by pressing the Enter button. Connected Play: Select the picture and video icon at the menu of function selection and press Enter button to enter into picture and video playing. -
Page 12: Settings
Settings: Wi-Fi Networking: Press it to check the network status; scan for wireless networks and then exit wireless networks. Time and clock: On/off schedule: Select the Enable button; press up/down button to set the time of power on; press the left/right button to move the cursor; press up and down button to set the time of power off and press Enter after setting. - Page 13 Set time: Set the time by pressing up/down button, press the left/right button to move the cursor and press Enter after setting. Slideshow Speed: Adjust the slideshow speed by pressing the up/down button. . -12-...
- Page 14 Slideshow Effect: There are 5 effects of slide playing; press the up and down to select needed effects and press Enter to confirm. Brightness: Adjust the brightness by pressing the left/right button. -13-...
-
Page 15: Performance Parameters Of The Album
Performance Parameters of the Frame ……………………………………………………………………………………………………….. 1) LCD Display: 8-Inch LCD screen 2) Resolution: 800 X 600 pixels contrast: 4:3 3) Communications: Internal 802.11b/g (WEP64, WEP128, WPA1, WPA2) 4) Picture format supported: JPEG. 5) Video formats supported: MPEG1, MPEG2, MPEG 4 file (AVI, WAV, and WMA). 6) Interface: MMC/SD/MS card slot;... - Page 16 PF Digital Inc. 6819 Elm St, Suite 16 Mclean, Virginia 22101, USA Customer Care: support@estarling.com Comments about our products: info@estarling.com Privacy questions: privacy@estarling.com Press inquires: press@estarling.com...
- Page 17 FCC warning statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
