Summary of Contents for Swank Cinelink
- Page 1 User Guide...
-
Page 2: Table Of Contents
Cinelink™ One-Time Activation 11-12 Cinelink™ Diagram Time Zone 13-14 Cinelink™ Specifications PLAY MOVIES Downloading Movies and TV Shows The Cinelink™ User Interface Overview The Carousel Movie Playback and Show Dates Audio Language Closed Captions Power Off CONFIGURE PLAYBACK SETTINGS System Settings... -
Page 3: Welcome
Movie purchases are automatically downloaded with Cinelink™ up to two weeks before your show date - No more shipping discs back and forth! The Cinelink™ player is small and compact, requiring little space to operate and enables easy transport to and from your movie event/venue. -
Page 4: What's Included
*Adapters not included. Please note, 1080p output is only possible if HDCP is maintained between the Cinelink™ player and the display device - otherwise, video quality will be reduced to SD. Chapter 1 - Getting Started... -
Page 5: Cinelink™ Player Connection Diagram
BACK Optional VIEW HDMI 2 2nd display HDMI 1 Note: Once installed, please main display leave the USB remote receiver in the Cinelink player’s™ USB port to prevent misplacing it. ENTER Network cable MENU remote HOME receiver Power adapter Chapter 1 - Getting Started... -
Page 6: Cinelink™ Remote Control
Cinelink™ Remote Control chapter 2 Remote control functions are listed below. For best reliability, operate the remote within a 10 foot radius of the Cinelink™ player. chapter Enter: Functions the same as the OK button ENTER Escape: Returns to previous screen;... -
Page 7: Cinelink™ Startup
Cinelink™ One-Time Activation Power on the Cinelink™ player by pressing the power button on The first time you power on your Cinelink™ player, you will need to activate the device. Press OK on your remote to bring up the the front of the device. -
Page 8: Time Zone
Time Zone Please note: The Cinelink™ player will need to have access to the internet during the activation process. By default, Cinelink™ is Once you have successfully activated your device, you will be configured to use DHCP to obtain the correct IP address, gateway brought to the Initial Settings screen. -
Page 9: Play Movies
Repeat this process for the Select Nearest City field. When you have made your selections, click Next at the bottom of the Initial Settings screen, then press OK. You are now ready to use Cinelink™! Chapter 2 - Activate Cinelink™ Chapter 3 - Play Movies... -
Page 10: Downloading Movies And Tv Shows
The Cinelink™ User Interface Overview Once Cinelink™ has connected to the internet and has been Cinelink’s™ user interface is very simple to use. In the middle of successfully activated, it will automatically begin downloading the screen is the carousel. This is where your purchased movies any movies you have ordered from Swank. -
Page 11: The Carousel
The Carousel Movie Playback and Show Dates The carousel is where you select and play your movies. Movies and TV shows are available for playback only during Downloaded movies, as well as those in the process of being the licensed show date(s). These dates are listed in the movie downloaded, are displayed here. -
Page 12: Audio Language
Audio Language Closed Captions A movie may have multiple audio language tracks from which A movie may include closed captions. To turn closed captions on, to select. Select the movie in the carousel, arrow down to select select the movie in the carousel, arrow down to select Captions Audio, then press OK. -
Page 13: Power Off
OK. You will be prompted to confirm this action on the following screen. chapter Choose OK to shut the Cinelink™ player off, or choose Cancel to return to the previous screen. CONFIGURE PLAYBACK... -
Page 14: System Settings
You may access the Cinelink™ player's Settings by selecting the You may select between HDMI (digital multi-channel) and Analog gear icon near the top right corner of the Cinelink™ interface and (stereo) audio output. If using an HDMI cable to carry audio, use pressing OK - or - by pressing the Menu button on the remote the HDMI setting (default). -
Page 15: Control Output (Hdmi 2)
Cinelink's™ HDMI 2 port. When using dual-display mode, the choose from a list of supported resolutions. To do so, select the Cinelink™ user interface is displayed on HDMI 2, while the movie is desired resolution from the list and press OK. On the Settings displayed on HDMI 1. -
Page 16: Diagnostics
4 The Diagnostics screen will provide you with important troubleshooting information in the event you encounter technical issues with your Cinelink™ player. The Send to Swank button can chapter be used to transmit this information directly to Swank for faster technical support. -
Page 17: Access Network Settings
Access Network Settings IP Mode (Automatic/Manual) At the bottom of the Settings screen, select Network Settings. By default, Cinelink is set to Automatic IP Mode (DHCP). then press OK. You may find that you need to adjust Cinelink™’s network settings manually if your network does not use DHCP, or if your network administrator requires specific settings. -
Page 18: Manual Ip Mode Settings
Manual IP Mode Settings Test Network Settings If manual IP setup is needed, work with your network Once you have entered all required values, test your settings administrator to set the proper values for IP address, Subnet by selecting Test at the bottom right corner of the screen. If Mask, Default Gateway, Primary DNS Server and Secondary successful, you will receive the message, Network settings DNS Server. -
Page 19: Tcp/Udp Port Settings
TCP/UDP Port Settings chapter 5 Your network administrator will need to ensure that the following ports are open on your network in order for proper communication between Cinelink™ and Swank’s servers. chapter PORTS IP ADDRESS / URL TCP: 443 cinelink-apt.swankmp.net... -
Page 20: Cinelink™ Software Updates
Periodically, Swank will release software updates for Cinelink™. the update or skipping the update. Skipping the update may be The Cinelink™ player must be connected to an active internet desirable if you don’t have time to apply and/or test the update connection to check for and receive these updates. -
Page 21: Cinelink™ Diagram
Cinelink™ Diagram Cinelink™ Specifications FRONT BACK Model Name Cinelink™ Front Panel I/O 2 USB 2.0 ports 1 SD card slot (not active) 2 Audio jacks: Line-out and Mic-in 1 Power on/off switch Power Button Back Panel I/O 2 Micro USB 2.0 ports Micro USB 2.0... - Page 22 Notes Notes ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________...
- Page 23 For Technical Support: 1-800-876-5577 Copyright 2015 Swank Motion Pictures. All rights reserved. Cinelink™ is a trademark of Swank Motion Pictures, Inc. Visit us at swank.com Chapter 6 - Additional Information...
