Summary of Contents for TeleAdapt TA-8330 iDock
-
Page 2: Table Of Contents
Table of Contents Product Introduction ..............3 Compatible MediaHub Models...........3 Safety Precaution Information............ 4 Definitions .................. 6 Electrical Requirements............. 7 Care and Maintenance .............. 7 Features and Usage ..............9 Standard Auto-Switching Feature..........9 Packing List(s) ................. 10 Installation Instructions ............11 LG North America ..............13 LodgeNet PPV ................15 Enseo Set Top Box ..............16... -
Page 3: Product Introduction
Compatible with TeleAdapt MediaHub You have purchased the “stand alone” model of iDock. This product can also be added as an iPod docking accessory to any of the TeleAdapt MediaHub connectivity panel models listed below. Contact your local TeleAdapt representative for more information. -
Page 4: Safety Precaution Information
Safety Precaution Information When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use. - Page 5 not fit into your outlet, consult an electrician for replacement of the obsolete outlet. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles and the point where they exit from the apparatus. Only use attachments/accessories specified by the manufacturer. Use only with the cart, stand, tripod, bracket or table specified by the manufacturer, or sold with the apparatus.
-
Page 6: Definitions
Definitions Auto-switching – the automatic switching of the TV input away from regular tuner mode (TV Mode) to iDock content (AV Mode or Auxiliary). Control Cable – iDock uses an Auto-Sensing Module (ASM) to pass through a serial or game control protocol through a control cable connection, implementing the TV auto- switching feature. -
Page 7: Electrical Requirements
Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the iDock or ASM. Your TeleAdapt product should never be positioned or installed anywhere where it could get hit, dropped, or banged around. Do not drop, knock, or shake the device. Rough handling can harm internal operations. - Page 8 Disposal The crossed-out wheeled-bin symbol on your product, literature, or packaging reminds you that in the European Union all electrical and electronic products must be taken to separate collection at the end of their working life. Do not dispose of these products as unsorted municipal waste.
-
Page 9: Features And Usage
Features and Usage Standard Auto-Switching Feature iDock has been engineered to work in tandem with an Auto-Switching Module (ASM) for the auto-sensing and input switching function. Hotel guests can plug in their own iPod, iPhone or iPad. When an audio or video file is played iDock will automatically detect their device and change the TV input channel to play their personal audio/video selections through the in-room TV and speakers, without having to use the in-room remote control. -
Page 10: Packing List(S)
Packing List(s) Note: To ensure proper installation, you will need the TV/STB remote control. TA-8330 iDock™ iPod Composite Cable Weighted Pull-through Base and Cap 3RCA+USB to CAT5 Adapter CAT5 Cable Acrylic DeskCard Furniture Grommet Security Cap Locking Screw ASM Installation Kit (2 ft. cables) 3RCA Cable Control Cable* USB Cable... -
Page 11: Installation Instructions
Installation Instructions The ASM Installation Kit facilitates the auto-switching functionality for iDock. Please refer to the following pages for installing iDock with specific brands of TV and STB that support control protocols for auto-switching communication. For all noted TV model numbers, “nn”... - Page 12 Ensure the DIP Switch Settings on ASM are in the appropriate positions according to the TV/STB installation choices below. Connect the cables between the iDock, ASM and TV/STB according to schematic shown for your installation choice. Choose the appropriate Control Option (RS232, GAME, DATA, RJP) as outlined in your TV/STB model instructions.
-
Page 13: Lg North America
LG North America For LG hospitality displays implementing legacy RJP protocol (recommended) Follow cable connection diagram below. ASM DIP Mode: Not Applicable, ASM supports RJP protocol in any DIP setting Configure TV Menu Settings: With LG remote control, enter the menu by pressing <MENU>... - Page 14 Follow cable connection diagram below. ASM DIP Mode: UP-UP-DWN-DWN Configure TV Menu Settings: None required. Special Notes: TeleAdapt recommends using the RJP connection for all LG TVs. However, some recent LG TV models (2011 and newer) may not support auto-switching to the Composite AV.
-
Page 15: Lodgenet Ppv
LodgeNet PPV Systems (with ANY TV) Follow the cable connection diagram below. ASM DIP Mode: DWN-DWN-DWN-DWN Configure TV Menu Settings as recommended by your VOD provider. Special Notes: For legacy OnCommand STBs (OCV), please refer to the TV-specific installation instructions. Only certain TV model serial connections support auto-switching MediaHub SL in an OCV... -
Page 16: Enseo Set Top Box
Enseo Set Top Box (with ANY TV) For Enseo HD3000 STB firmware v.2.12.04+ / HD2000 STB firmware v.2.10.29.17+ Follow the cable connection diagram below. ASM DIP Mode: UP-DWN-UP-DWN Configure Enseo STB: Press <Channel Up>, <Right Arrow>, <Left Arrow>, <MUTE> to enter set-up screen. Go to Control Options and AUX panel. Set BAUD Rate to 115200. - Page 17 Panasonic North America Series 20/12 + Enseo HD2000/3000 Configure TV: Go into HOTEL MODE (<MENU>, <G>, <Y>, <0>), set MODE=ON, TA Control=EXTERNAL, BUTTON LOCK is OFF. LG North America + Enseo HD2000/3000 Configure TV: Plug in DATA jack to TV’s DATA port. TV will automatically power off and enter Enseo Mode after 3 minutes of inactivity.
-
Page 18: Samsung North America
Samsung North America Follow the cable connection diagram below. ASM DIP Mode: UP-DWN-DWN-DWN Configure TV Menu Settings according to model year listed. Special Notes: New models (2012+) may utilize a 3.5mm jack for the Composive AV In. For these displays, please use a 3RCA-to-3.5mm Adapter for connecting the CVBS connection to the TV. - Page 19 STB, follow the Enseo Installation Instructions. For Samsung North America Models and an External Enseo STB In this environment, TeleAdapt recommends connecting the iDock control cable to the Enseo STB. See instructions below for installing the serial control connection to the Enseo HD3000 and Enseo HD2000 STB models.
-
Page 20: Panasonic North America
Panasonic North America For Panasonic North America Series 20/30 Hospitality or ProDisplays with serial control Special Notes: Follow the cable connection diagram below. The ASM Installation Kit contains an RS232 ASM DIP Mode: DWN-UP-UP-DWN 3.5mm control cable. Use this cable for the TV’s Configure TV: Go into HOTEL MODE (<MENU>, <G>, <Y>, <0>). - Page 21 These models require an Enseo IMP- or DTB- Tuner Card in Slot 2/3 as well as the Panasonic TY- FB10HMD Dual HDMI Terminal Card in Slot 1. Audio 2RCA to 3.5mm Y-Adapters (TeleAdapt CAB-4066D12 ) are also required for this application.
-
Page 22: Philips North America
Philips North America Follow the cable connection diagram below. ASM DIP Mode: DWN-DWN-UP-DWN Configure TV Menu Settings according to model year listed. Special Notes: The ASM Installation Kit contains an RS232 control cable. Use this cable for the TV’s SerialXpress connection. To use the charging feature of iDock, make sure to connect the USB Power Supply to a wall outlet. -
Page 23: Troubleshooting
Follow Direct-to-TV installation instructions according for Philips HFL/HF models above. 2008 and Other Legacy Philips HFL/HF Models Legacy Philips HFL/HF models use a 3.5mm jack for the AVIN input. Therefore, you will need a 3RCA-to-3.5mm adapter for the CVBS/AV IN connection. Once cable connections are made, configure TV: Using guest remote control, enter the set-up menu by pressing <3>, <1>, <9>, <7>, <5>, <3>, <MUTE>. -
Page 24: Technical Support
Technical Support For North and South American 24/7 Technical Support Toll-Free: 1 877 835 3232 x319 (in US and Canada) Main: 1 775 232 5044 Email: ric.jones@us.teleadapt.com For EMEA Technical Support Main: +44 1923 810253 Email: info@teleadapt.com For APAC Technical Support Main: +82 10 8566 0809 Email: dg.hong@teleadapt.com...
