Summary of Contents for Marolex VX electric
- Page 1 INSTRUKCJA OBSŁUGI OWNER MANUAL BATTERIESPRITZE АККУМУЛЯТОРНЫЙ ОПРЫСКИВАТЕЛЬ НА КОЛЕСАХ...
-
Page 2: Table Of Contents
Table of Contents Application of the sprayer ....................16 Standard equipment Charging the battery ......................16 Preparation for work and precautions ................17 Preparing for work ....................17 Sprayer’s operation ....................17 Usage recommendations ..................17 Equipment maintenance ....................18 General Comments ...................... -
Page 3: Application Of The Sprayer
Application of the sprayer Battery sprayer trolley V)( is designed for spraying pesticides and liquid fertilizers in gardens, orchards, parks, forests, nurseries and greenhouses. Standard equipment Each packing of the Sprayer V)( contains: Complete sprayer with the wheels, pump, battery 7,2Ah Hose 250cm with the feeding valve integrated with the handle R020j Telescopic lance with adjustable nozzle MR1.5 Ø1.5mm, spraying angle 45 Battery charger... -
Page 4: Preparation For Work And Precautions
Preparing and operating instructions Preparing for work Remove the sprayer from the carton Connect the lance with the feeding valve integrated with handle R020j Open the cap RP11 and fill in the sprayer with clean water to check the operation of the device ... -
Page 5: Equipment Maintenance
In the lance’s handle there’s a filter (R40) installed, designed to protect nozzles from clogging. All Marolex lances are interchangeable (the same thread in all of them). It is possible to use additional extensions (60 and 100 cm) produced by Marolex. With MAROLEX sprayers a wide range of nozzles can be used: cone-shaped, deflecting, flatstream, with adjustable stream angle and with different output. -
Page 6: Safety Information
The only device for making pressure in the container is the sprayer’s pump. Iit’s forbidden to use any other equipment for this purpose! Company Marolex does not allow the use of fluids defined as: explosive, extremely flammable, highly flammable, flammable (in case when the maximum allowable temperature is above flashpoint), very toxic, toxic, oxidising. -
Page 7: Technical Information And Symbols Of The Elements
Description Location Sign Sign indicating possibility of unspecified danger. On the container Sign indicating that a users manual should On the container be read before starting work On the container Warning against poisoning by toxic substances Devices may not be disposed of with household On the container waste, used sprayer should be disposed of through a recycling center... -
Page 8: Construction And Maintenance Of Aps Telescopic Lance
Construction and maintenance of APS system in telescopic lance Telescopic lance is a piece of equipment of sprayer X, with the folded length of 60cm, and after ejection of the inside lance it extends to 108 cm. To get the correct length of the lance, loosen the sleeve R103, pull out the inside lance "A" to the desired length and then tighten the sleeve so that the lance could not fold again. -
Page 9: The Control Panel
Charger does not work Buy new charger the sprayer, the control panel does Defect in control panel Contact Marolex service not light up Tighten the nut or replace the gasket Feeding valve R020j Loose hose nut R80e or R47c (found in repair kit Z08j or... -
Page 10: Removal And Disposal
Clean the sieve R322 reach the maximum Dirty pressure pump Contact Marolex service: pressure serwis@marolex.pl In case of other symptoms preventing proper operation of the sprayer please contact MAROLEX service at: serwis@marolex.pl serwis.marolex.pl We offer technical support and on-line help: Removal and Disposal... -
Page 11: Terms Of Repairs And Guarantees
Terms of repairs and guarantees date of the repair description of the fault... - Page 12 stamp of the retailer and the date...
-
Page 13: List Of Schema Elements
List of schema elements Telescopic lance with handle R010mx Telescopic lance without handle R01mx Z12/15 Feeding valve integrated with handle R020j... - Page 14 R010mx Z12/15 M 8 0 R112 R73nx50 R115_1.5 R73mx60 R114R116 R64 R47c R103 R106 R108 R109 R107 M 1 1 R01mx R47c R020j R02j R47c R81e R80e R43 R48a R47c R50...
- Page 15 MAROLEX Sp.z o.o. ul. Reymonta 2 05-092 Dziekanów Leśny POLAND www.marolex.pl 077/PL,GB,DE,PT,RUS/2014/A...
