The following rights are reserved:
• Any changes, without previous notice, made to either the functionality or
appearance of this product will invalidate the guarantee.
• Use of this product in any environment or in any way other than specified
here will also invalidate the guarantee.
• Parameters of digital products might change under different external terms.
Our products are only guaranteed for usage under verified circumstances.
iViewer 03 ECO
Electronic Door Viewer
USER MANUAL
www.i-tec.com.pt
9
Advertisement
Table of Contents
Summary of Contents for i-tec iViewer 03 ECO
- Page 1 03 ECO Electronic Door Viewer USER MANUAL The following rights are reserved: • Any changes, without previous notice, made to either the functionality or appearance of this product will invalidate the guarantee. • Use of this product in any environment or in any way other than specified here will also invalidate the guarantee.
- Page 2 Battery: Dispose of used batteries appropriately, DO NOT bury or burn the batteries and keep them away from children. DO NOT re-charge or disassemble the batteries. www.i-tec.com.pt...
-
Page 3: Before Installation
Package list: List of contents: Digital door viewer Locking bolt 1 pc 2 AAA batteries Holding plate Washer Camera Locking barrel Tightening tool Before installation: Prior to mounting the peephole viewer, please make sure you have installed the batteries included. www.i-tec.com.pt... - Page 4 4. Hook the digital door viewer over the bracket at the top of the locking plate and secure the digital door viewer case with the locking bolt.(FIG. 3) Hang Door Screw FIG. 1 FIG. 3 FIG. 2 FIG. 4 www.i-tec.com.pt...
-
Page 5: Specifications
Please change batteries when this indicator appears. Specifications: Door thickness 38~110mm Door barrel diameter 14-22mm Camera 3 Megapixels HD Def. LCD Screen 2.6”TFT Power 2 AAA batteries Size 110 (W) x 59(H) x 14(D)mm (4.33”x2.32”x0.55”) Weight 100g (4.23 oz) www.i-tec.com.pt... - Page 6 Also DO NOT rotate camera when disassembling this product. Correct Assembly Incorrect Assembly Do not rotate the out Rotate the out door door camera when camera when assembling assembling * Please do not twist the door viewer or the monitor after connecting cable. www.i-tec.com.pt...
