Summary of Contents for iFarsys MD704
- Page 1 Http://www.ifarsys.com Mobile DVR Manual V6.0 MDVR MD704 4-Channel Industry-Grade 720P AHD Mobile DVR Integrating Special Attention: Images of this model is for reference only, and no further notice will be given in case of any changes. V6.0...
-
Page 2: Table Of Contents
Http://www.ifarsys.com Mobile DVR Manual V6.0 Contents Product Introduction..........................3 1.1. Overview............................3 1.2. Specifications..........................4 1.2.1. Specifications........................4 1.2.2. Basic Working Parameters....................6 1.3. Application..........................7 1.3.1. Environmental Adaptability....................7 1.3.2. Precautions.........................7 1.3.3. Typical Applications......................8 1.4. Features............................9 Appearance and Accessories......................10 2.1. Front Panel Definitions......................10 2.1.1. -
Page 3: Product Introduction
Http://www.ifarsys.com Mobile DVR Manual V6.0 3.7.7. System Upgrade.......................33 ........3.7.8. Shortcuts..................Host Upgrading Instructions......................34 4.1. Upgrading Modes........................34 4.2. Upgrading Steps........................34 4.2.1. Applications........................34 4.2.2. Uboot/ Rootfs/Kernel.......................34 4.2.3. SCM..........................34 4.2.4. Viewing Version Number....................35 FAQs............................... 35 5.1. Questions on Recording........................35 5.2. -
Page 4: Specifications
Http://www.ifarsys.com Mobile DVR Manual V6.0 1.2. Specifications 1.2.1. Specifications Item Description Linux3.0 System parameters can be set through external display and Graphics Operation Interface remote controller 2-level management for user password, administrator Security Management password, supporting encrypted transmission Video Input, 4-channel video input, 1channel video output;... - Page 5 Http://www.ifarsys.com Mobile DVR Manual V6.0 CIF: 300Kbps ~ 1.2 Mbps, 8-level bit rates for selection HD1: 500Kbps ~ 1.5 Mbps, 8-level bit rates for selection Bit Rate D1: 600Kbps ~ 2Mbps, 8-level bit rates for selection 720P: 800Kbps ~ 4Mbps, 8-level bit rates for selection...
-
Page 6: Basic Working Parameters
Http://www.ifarsys.com Mobile DVR Manual V6.0 1. ACC on/off 2. Hard drive lock on/off Power Supply 3. Delayed shutdown 4. Timed on/off Power Input Voltage DC:+9V ~ +36V Supply Output Voltage +12V@5*0.5A; Power With patented UPS power supply continuous working Consumptio... -
Page 7: Application
Http://www.ifarsys.com Mobile DVR Manual V6.0 Standard Ethernet Interface Standard RJ45 interface, with indicator. Interface Standard SD Card Interface Compatible with commerciall avaiblable brands. Interface Working 0℃~ +55℃ Hard drive heating -25℃ ~ +55℃ Temperature 1.3. Application 1.3.1. Environmental Adaptability Applicable to various applications, and the indexes are detailed as follows:... -
Page 8: Typical Applications
Http://www.ifarsys.com Mobile DVR Manual V6.0 short circuit. Before connecting to other external devices, please cut the connection between the device and the power supply; The output voltage of the device is 12V, only used for power supply of the camera, please do not enclose any device that are not allowed to be used on the device;... -
Page 9: Features
Http://www.ifarsys.com Mobile DVR Manual V6.0 rail, vessels. 1.4. Features H.264 video code compression, dual stream output; G.726 audio compression format, 4-channel audio input, 1-channel audio output. Power-off protection in emergency, adopting special UPS technology which ensures the ... -
Page 10: Appearance And Accessories
Http://www.ifarsys.com Mobile DVR Manual V6.0 Appearance and Accessories 2.1. Front Panel Definitions 2.1.1. LED Indicator [PWR]Power supply state indicator: LED on ─ system powered. [AL]Alarm indicator. [REC]Recording indicator: LED ON - recording. [HD]Hard drive indicator: LED ON -hard drive successfully loaded; LED out -failure ... -
Page 11: Rear Panel Definitions
Http://www.ifarsys.com Mobile DVR Manual V6.0 2.2. Rear Panel Definitions [PWR]Power supply interface. ● [GPS]GPS module interface. ● [EXTEND I/O]Extension interface. ● [RJ45]Network interface. ● [AV IN]Audio/video input interface. ● [AV OUT]Audio/video output interface. ● [WI-FI]Wireless LAN antenna interface. ● [3G]3G antenna interface. -
Page 12: Audio/Video Input/Output Cables
Http://www.ifarsys.com Mobile DVR Manual V6.0 2) After the connection, pay attention to the insulation between power cables to prevent short circuit of the power supply that may burn the battery jar. 3) The yellow wire must be connected to the ignition wire, otherwise, the device will not support ignition mode. -
Page 13: Gps Module
Http://www.ifarsys.com Mobile DVR Manual V6.0 2.3.3. GPS Module GPS module antenna The figure above shows the actual GPS module 2.3.4. 3G ，WiFi Antenna : Wi-Fi antenna 3G antenna 2.3.5. Extension Cables Extension cables... -
Page 14: Infrared Remote Controller
Http://www.ifarsys.com Mobile DVR Manual V6.0 AL1—AL8： alarm input RX/TX ： RS232 port 485A/485B： 485 port 12V：12V 500mA power output out1/out2 ：2 channel alarm output ，Can activate the external two independent relay. 2.4. Infrared Remote Controller Function Image Remote on. [LOGIN] Login the system for parameter settings. -
Page 15: Description Of Host Menus
Http://www.ifarsys.com Mobile DVR Manual V6.0 module, card, dialing, online, etc. surveillance menu. [F2] Monitors single channel and displays PTZ information. [F3-F8] Reservation Description of Host Menus 3.1. Menu Structure The user may control various functions of the device through a series of menu operations, in this chapter, we will briefly introduce the structure of such menus, and detailed description will be provided in subsequent chapters. -
Page 16: Main Menu
Http://www.ifarsys.com Mobile DVR Manual V6.0 Move the cursor to “Login” and press [ENTER] to enter the system main menu; Move the cursor to “Cancel” and press [ENTER] to quit the login menu. When the password is set to “Disabled”: press the [ENTER] button after startup of the ... -
Page 17: Rec Query
Http://www.ifarsys.com Mobile DVR Manual V6.0 3.4. Rec Query In the main menu, press the arrow keys to select the video to playback, and press [ENTER] to enter the REC SEARCH interface. 3.5. System Setup In the main menu, press the arrow keys to select the SYSTEM SETUP menu, and press [ENTER] to enter the following SYSTEM SETUP menu. -
Page 18: Basic Setup
Http://www.ifarsys.com Mobile DVR Manual V6.0 3.5.1. Basic Setup This menu is mainly for settings of basic information of the system. Time Format This is used for selecting date format, i.e., year-month-date, date-month-year, month-date-year. press [ENTER] for selection. Time Zone ... -
Page 19: Record Setup
Http://www.ifarsys.com Mobile DVR Manual V6.0 When setting the device No., press DEL to delete the original number and press the numeric keys to input the number, which must be in 5 digits. Enter security settings to set password corresponding to the device No. - Page 20 Http://www.ifarsys.com Mobile DVR Manual V6.0 Record upon Power ON start recording (default)/Timed Recording/Alarm Recording, press [ENTER] to input. There are 3 modes: Power ON Startup, Timed and Alarm, and the default mode is Power on start recodding ON: Automatically starts recording at startup of the device ...
-
Page 21: Power Setup
Http://www.ifarsys.com Mobile DVR Manual V6.0 1-2 are AHD 720P input and 3-4channel is Analog video input. Sub-Stream Move the cursor to “sub-stream”, press [ENTER] to enter the follow menu of Sub–stream Setup: Resolution CIF, press [ENTER] to input. -
Page 22: Alarm Setup
Http://www.ifarsys.com Mobile DVR Manual V6.0 On/off mode Set on/off mode and press [ENTER] to input. TIME mode: turns on or off the device according to the on/off period set by the user. ACC mode: turns on/off the device according to the vehicle key signals. - Page 23 Http://www.ifarsys.com Mobile DVR Manual V6.0 Alarm input Supporting synchronous input of up to 8 channels of alarm. “Enable”: Set whether to enable the function upon alarm, press [ENTER] to input. “PWL”: set high\low level, press [ENTER] to input. “Record”: set whether to start alarm recording of this channel, press [ENTER] to input.
- Page 24 Http://www.ifarsys.com Mobile DVR Manual V6.0 Supporting synchronous output of up to 2 channel of alarm. “Enable”: Set whether to enable the function upon alarm, press [ENTER] to input. “PWL”: set high\low level, press [ENTER] to input. GPS Overspeed Move the cursor to “overspeed” and press [ENTER] to enter the following menu of overspeed alarm: Threshold: 60km/h by default, adjustable within the range of 0~999.
-
Page 25: Security Setup
Http://www.ifarsys.com Mobile DVR Manual V6.0 G-Sensor settings: “Threshold”: Set values of X, Y and Z directions within the range of 0.00g--9.99g, press DEL to delete the original number, press numeric keys to input. “Alarm Switch”: set whether to enable or disable G-sensor alarm, press [ENTER] to input. -
Page 26: Network Setup
Http://www.ifarsys.com Mobile DVR Manual V6.0 Password Set whether to enable the login password, and then press [ENTER] to input. On: When log in with the Admin password, Admin\User password can be set; When log in with the user password, only the User password can be set, press numeric keys to input, the passwords inputted twice should be consistent. -
Page 27: System Info
Http://www.ifarsys.com Mobile DVR Manual V6.0 Wi-Fi Setup Move the cursor to ‘Wi-Fi’, press [ENTER] to enter the following Wi-Fi menu: WiFi On/ Off, press [Enter] for selection Encrypt On/ Off, press [Enter] for selection Encrypt type: WEP by default Wi-Fi wireless local network settings ... -
Page 28: Management Tools
Http://www.ifarsys.com Mobile DVR Manual V6.0 Software version number Software version number of the device. Hardware version number Hardware version number of the device. MCU version number Version number of the SCM Hard drive information “Storage Medium”: SD and HDD. -
Page 29: Log Management
Http://www.ifarsys.com Mobile DVR Manual V6.0 3.7.1. Log Management The Log Management records events of startup and shutdown, GPS time correction, alarm moment, etc., including date, time and event name. Start Date Set the start date of the log recalled, press numeric keys to input. -
Page 30: Disk Management
Http://www.ifarsys.com Mobile DVR Manual V6.0 Press the arrow keys to select “Home”, “Previous”, “Next”, “End”, and press [ENTER] to display page turning information. 3.7.2. Disk Management It is mainly used for formatting designated disk. Disk Selection Select SD or HDD, press [ENTER] for selection. -
Page 31: Peripherals Setting
Http://www.ifarsys.com Mobile DVR Manual V6.0 3.7.4. Peripherals Setting 3.7.5. PTZ Management... -
Page 32: Serial Port Setting
Http://www.ifarsys.com Mobile DVR Manual V6.0 Channel Supporting 4 channels, each channel can be subject to independent serial port information settings. Address Set the address code corresponding to the channel. Baudrate Set the Baudrate of serial port communication, supporting 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600 and 115200. -
Page 33: System Upgrade
Http://www.ifarsys.com Mobile DVR Manual V6.0 Use simulation of capacitive sensor. Need to calibrate channel：select sensor ID calibration：current tank size. Clear calibration value： Oil status(tank sensor)：X sensor is not normal，√sensor is normal. Liquid level：show the data from sensor Clear button：clear Calibration button：set oil reference value... -
Page 34: Host Upgrading Instructions
Http://www.ifarsys.com Mobile DVR Manual V6.0 4. Host Upgrading Instructions Precautions: During the upgrading, the following operations are forbidden: power cut, plugging or insertion of hard disk or SD CARD, unlocking the hard drive lock or disabling ACC. 4.1. Upgrading Modes This device supports local upgrading modes of SD card and hard drive;... -
Page 35: Viewing Version Number
Http://www.ifarsys.com Mobile DVR Manual V6.0 4.2.4. Viewing Version Number Press “INFO” on the remote controller or enter the system menu and select “Upgrade Information” to view the upgrade version number, only display the version numbers of software, hardware and SCM on this page; if the users want to view the version numbers... -
Page 36: Questions On Alarm
Http://www.ifarsys.com Mobile DVR Manual V6.0 5.2. Questions on Alarm Q: Invalid alarm triggering? A: This may be caused by the following causes: Incorrect settings on the Alarm Settings menu; such as failure to enable alarm for designated alarm input and incorrect output level configuration;... - Page 37 Http://www.ifarsys.com Mobile DVR Manual V6.0 Q: Blank screen of some channels? A: This may be caused by the following causes: This channel is not connected to the video; The camera connected to this channel is damaged or abnormal; If the camera is powered through the device, it may be possibly that the voltage of the device cannot ensure normal operation of the camera;...
