Keyshare KIMON Quick Start Manual

Flighttips
Welcome to your KIMON. Please read the quick guide manual to help you quickly understand KIMON operation and settings.
We wish you enjoy a pleasant flight experience. For more information, please visit our website www.keyshare.com.
Environmentalrequirements
GPS signal：In outdoor mode, GPS signals can be elevated due to high buildings or weather conditions, therefore it is
recommended to use open spaces to reduce positioning errors.
Aircraft signals: KIMON uses WIFI direct-connection, therefore, please stay away from areas with high interference such
as power lines, transmission stations or magnetic equipment as this could cause the aircraft to crash or it
may be unable to take off due toWIFI interference.
Flight restricted areas: Do not fly near airports, military restricted zones and other sensitive areas of air traffic control. Any
consequences or the above is the sole responsibility of theuser.
Flying locations: Do not fly the aircraft into crowds of people or moving vehicles .
Weather conditions: It is not recommended flying in high temperatures, rain, snow and strong winds above (level 4).

Safety

1. Please make sure to keep a safe distance of 2 meters or more from the aircraft, keep away from the crowds and other
obstacles during flightpreparing.
2. Under outdoor mode, you must check the GPS signal quality before flying; and only when the GPS icon is green,the
aircraft would be unlocked for take-off; otherwise it would be fail to take-off.
3. During the flight, please ensure the aircraft in your view to avoid accidents due to non-distinct flight status.
4. If receive phone call during flying, phone call would take over APP operation in advanced. The aircraft would be kept
hovering until the user switch back to APP during phone call in process. However, in order to ensure flying safe, we
do not recommended to answer the phone during theflight.
5. Note that the default return height is 15 meters, make sure in the return process that there are no obstacles to avoid
GPS positioning error.
APPDownload
To access all operation of KIMON, you must download KIMON from APP library.
APPdownloading:
For Apple IOS user, please search KIMON from Apple Store; For Android user, please search KIMON
from Huawei store, 360 or Baidu mobile assistant.
OrAndroidusercoulddownloadAPPviascanQRcodehere:
PreparingbeforeFly
Aircraft arms
KIMON arms can be folded any horizontal direction,
please move the arms in to the middle position before
flying, ensuring that the KIMON four arms anchor point
is in the middle beforeflight.
SmartBatteryInstallation
Please push battery slightly into the positioning groove
till the back latch automatically fastens. To dismount
battery, please press and hold down the battery latch
as follow instuction, then gently slide the battery out.
Installation
Quick startmanual
Dismount
Compass Calibration
For first time flight, you must apply compass calibration.
Please link aircraft and APP first, then click Compass
Calibration on setting menu and follow instruction of screen.
Blade installation
Note KIMON blade installation instructions. Red blades
are concave point, s.Note KIMON positive and negative
blade installation. Red pits blade corresponds with a
motor pits, pit-free blade without pits corresponding to
the motor.
Turnon powerofAircraft
Quick press the power key, then press and hold power
button for 2 seconds, the indicators would be turn on
from left to right till all lights keep on, after a while you
would hear beep, beep, beep three confirmation sound,
it means the battery was powered on.
Concave Tip
