Juster Co. BHF-P702 User Manual

Bluetooth Portable Hands-free Speaker
1. Before you use this device, please make sure that you:
1.1 Put four AA batteries into compartment or connect power adapter into DC IN jack
1.2 To pair the speakers with a Bluetooth mobile phone or other Bluetooth devices before you
making calls. The Bluetooth audio connection between the speakers and your phone can be
established by setting up a PAIRED link. (Please refer 3.2 showed below for details.)

2. Instruction

2.1 Features

2.1.1 Line-in connection any kind of Audio Source
2.1.2 Wireless connection of Stereo Bluetooth Streaming from Audio Source.
2.1.3 Built-in S/W, AEC cancellation to reduce eacho and background noise.
2.1.4 Built-in microphone to amplifier conversation via Skype, MSN & Yahoo Messenger.
2.1.5 Handsfree function for Car Kit, Con-Call Device, Amplified Speakers...etc.
2.1.6 Optional: Built-in magnet to stick on metal surface.
2.1.7 Slightness design easy to carry and storage.
2.1.8 Suported AA x4 battery and AC Adapter power supply.

2.2 Product Specification

Receiver Sensitive
Bluetooth chipset
RF Output Power (class 2)
Operation Range
S/N Rate
Frequency Response
Audio Output Power
Speakers
Dimension (WxHxD)
Clear talking Range

USER MANUAL

BHF-P702
＜0.1% BER at -80dBm
CSR BC03MM
~ +4dBm
-6
up to 10m
>75dB
150Hz
2W x2
2 inch x2,
200 x 75 x 50 mm
around 1m area
JUSTER CO., LTD.
10F., No.373, Zhongshan Rd., Sanchong City, Taipei, Taiwan
TEL:886-2-2278-2588 FAX:886-2-8511-4229
Preliminary 2007/10/26
~ 20KH
4 ohm
1
