Klargester Envireau GL0052K Installation & Operation Manual

Envireau mono-tech rainwater recovery system
Hide thumbs
Table of Contents

Advertisement

Quick Links

GL0052K
Envireau Mono-Tech Rainwater
Recovery System
Installation & Operation Guidelines
College Road North, Aston Clinton, Aylesbury, Buckinghamshire, HP22 5EW
Tel: +44 (0) 1296 633033
Website: www.klargester.com
Issue
Description
03
CC648
Klargester Environmental
Fax: +44 (0) 1296 633001
Email: sales@.klargester.com
Date
September 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Envireau GL0052K and is the answer not in the manual?

Questions and answers

Related Manuals for Klargester Envireau GL0052K

Summary of Contents for Klargester Envireau GL0052K

  • Page 1 GL0052K Envireau Mono-Tech Rainwater Recovery System Installation & Operation Guidelines Klargester Environmental College Road North, Aston Clinton, Aylesbury, Buckinghamshire, HP22 5EW Tel: +44 (0) 1296 633033 Fax: +44 (0) 1296 633001 Website: www.klargester.com Email: sales@.klargester.com Issue Description Date CC648 September 2008...

  • Page 2: Health & Safety

    GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines HEALTH & SAFETY These warnings are provided in the interest of safety. You must read them carefully before installing or using the equipment. It is important that this document is retained with the equipment for future reference. Should the equipment be transferred to a new owner, always ensure that all relevant documents are supplied in order that the new owner can be acquainted with the functioning of the equipment and the relevant warnings.

  • Page 3: Regulations - General

    GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines REGULATIONS - GENERAL It is important that all relevant Regulations surrounding the installation of the Envireau Rain Water Recovery System are adhered to. For obvious reasons, we are unable to print all of the Regulations that could apply to your project therefore it is important that only Competent, Qualified Personnel with knowledge of the specific regulations are employed to install and commission the system.

  • Page 4: Table Of Contents

    GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines CONTENTS HEALTH & SAFETY..........................2 REGULATIONS - GENERAL ........................3 CONTENTS ............................4 SYSTEMS COVERED ..........................5 NON-STANDARD SYSTEMS .........................6 INSTALLATION INSTRUCTIONS ......................7 NO-MAINS SYSTEM INSTALLATION ....................8 GRAVITY (HEADER TANK) SYSTEM INSTALLATION ................15 DIRECT (PRESSURISED) SYSTEM INSTALLATION ................22 ENVIREAU ELECTRICAL INSTALLATION TROUBLE SHOOTING .............30 These instructions cover the installation of the Mechanical and Electrical components of the system as supplied by ourselves.

  • Page 5: Systems Covered

    GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines SYSTEMS COVERED Your ENVIREAU system comprises of two separate consignments 1) The External Works (Ground-Works) Package – This consignment (perhaps delivered separately) contains the Rain Water Holding Tank and Rainwater Filter. The installation of these items is covered under separate installation instructions which are delivered with both the Tank and the Filter.

  • Page 6: Non-Standard Systems

    GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines NON-STANDARD SYSTEMS Finally, please note there are also available a number of non-standard systems. You should have consulted with ENVIREAU and be fully familiar with your own requirements, particularly regarding EXTRA items of equipment.

  • Page 7: Installation Instructions

    GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines INSTALLATION INSTRUCTIONS General and for all three types of installed system: 1. The Holding tank requires the installation of a duct, of minimum diameter 40mm to carry the pump cable and the Depth Sensor cable.

  • Page 8: No-Mains System Installation

    GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines NO-MAINS SYSTEM INSTALLATION Please refer to the NO-MAINS SYSTEM Guide Sheet (at end of this section) throughout these instructions. Dispose of the instructions for other systems. As you are installing a NO-MAINS system it is assumed that you have no MAINS WATER SUPPLY available, or you do not wish to use MAINS water in this scheme.
  • Page 9 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines conveniently located an alternative hole may be drilled using a proprietary hole-cutter. Do not drill this hole at less than 300mm below ground level, to prevent freezing. In any event, the duct should be sealed into the tank using a quality waterproof sealant.
  • Page 10 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines Although the system can run from a 13 Amp switched socket outlet, this is not advised. In all instances a separate RCD MUST be in circuit. The system draws approximately 4 amps at 240 volts AC. Whatever cable is run to the local switch arrangement, the maximum cable size to enter the CONTROL UNIT should be 1.5mm flexible TRS.
  • Page 11 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines NOTE. If you have extended the pump cables and have used oversized, armoured or solid conductors to achieve this you must convert to the previously specified cable size using a joint box before entering the control unit.
  • Page 12 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines 15) You have now completed the installation of your NO-MAINS system. Before proceeding to the final stage, Set-up and Commissioning, you should check the following. a) Are all pipework joints secure? b) Have you taken precautions to quickly isolate the electrical supply to the system? c) Is the storage tank full (or at least half-full) of clean water, free from installation detritus? d) Are you aware of the location of all items of equipment, particularly the DISPLAY unit?
  • Page 13 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines i) With the pressurised indicator extinguished and water in the external tank, the pump should be running. Check that this is the case by operating appliances. If any appliances are calling for water let them fill until demand ceases.
  • Page 14 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines systemnomains-02 PUMP & PLUMBING DETAILS NO MAINS SYSTEM DIAGRAM A 1) Always secure the pump in a vertical position, but do not suspend. Use the lifting rope to lower and secure. 2) Make certain all joints are secure.

  • Page 15: Gravity (Header Tank) System Installation

    GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines GRAVITY (HEADER TANK) SYSTEM INSTALLATION Please refer to the GRAVITY SYSTEM Guide Sheet (at the end of this section) throughout these instructions. Dispose of the instructions for other systems. As you are installing a GRAVITY system it is assumed that you have MAINS WATER SUPPLY available and you wish to use MAINS water in this scheme by the installation of a header tank.
  • Page 16 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines conveniently located an alternative hole may be drilled using a proprietary hole-cutter. Do not drill this hole at less than 300mm below ground level, to prevent freezing. In any event, the duct should be sealed into the tank using a quality waterproof sealant.
  • Page 17 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines identify the terminals within. The mains supply terminal block is marked L, N and E and is top left (facing) on the control unit Printed Circuit Board. Note. Although the system can run from a 13 Amp switched socket outlet, this is not advised. In all instances a separate RCD MUST be in circuit.
  • Page 18 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines place, with the waterproof connector accessible (on enough spare cable to reach ground level easily), the pump can be lowered carefully, on its rope, into the tank. Do not lower the pump by the electrical cable or by the hose.
  • Page 19 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines To install the sensor, uncoil the cable fully and straighten on the ground surface. You are NOT advised to cut the cable to length at this stage. It is important that this cable is not unduly stretched so lubricate if necessary.
  • Page 20 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines f) Now remove the filter from the in-line filter carrier on the pump incoming pipe and VERY SLOWLY open the incoming stop-cock below the filter carrier. You will hear air rushing up the pipe from the pump. Be ready to turn off the stop-cock to avoid spillage from the filter carrier.
  • Page 21 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines systemgravity-02 PUMP & PLUMBING DETAILS GRAVITY SYSTEM DIAGRAM A 1) Always secure the pump in a vertical position, but do not suspend. Use the lifting rope to lower and secure. 2) Make certain all joints are secure.

  • Page 22: Direct (Pressurised) System Installation

    GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines DIRECT (PRESSURISED) SYSTEM INSTALLATION Please refer to the DIRECT SYSTEM Guide Sheet (at end of this section) throughout these instructions. Dispose of the instructions for other systems. As you are installing a DIRECT system it is assumed that you have MAINS WATER SUPPLY available and you wish to top-up your storage tank with MAINS water during periods of low rainfall.
  • Page 23 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines 7) Refer to the Guide Sheet DIAGRAM A. Lay in the MDPE pump outlet pipe according to your chosen route and ensure that bending radii are kept as large as possible to avoid kinking. Before terminating the pipe in the building, wash it through to void any grit or small stones.
  • Page 24 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines Although the system can run from a 13 Amp switched socket outlet, this is not advised. In all instances a separate RCD MUST be in circuit. The system draws approximately 4 amps at 240 volts AC. Whatever cable is run to the local switch arrangement, the maximum cable size to enter the control unit should be 1.5mm flexible TRS.
  • Page 25 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines 15) Refer to the Guide Sheet DIAGRAM C. At this stage, the pump should not be in the tank. To install the pump you should take great care. It is a heavy item.
  • Page 26 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines 18) You have now completed the installation of your DIRECT system. Before proceeding to the final stage, Set-up and Commissioning, you should check the following. a) Are all pipework joints secure? b) Have you taken precautions to quickly isolate the electrical supply to the system? c) Is the storage tank full (or at least half-full) of clean water, free from installation detritus? d) Are you aware of the location of all items of equipment, particularly the DISPLAY unit?
  • Page 27 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines (i) below. i) With the pressurised indicator extinguished and water in the external tank, the pump should be running. Check that this is the case by operating appliances. If any appliances are calling for water let them fill until demand ceases.
  • Page 28 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines SAFETY CHECK. Now that the system is commissioned you should check that the pump becomes DISABLED when the water level in the storage tank falls to a very low (EMPTY) level. To do this you should turn off the mains stop-cock and lift the sensor until it is approximately 7”...
  • Page 29 GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines PUMP & PLUMBING DETAILS systemdirect-02 DIRECT SYSTEM DIAGRAM A 1) Always secure the pump in a vertical position, but do not suspend. Use the lifting rope to lower and secure. 2) Make certain all joints are secure.

  • Page 30: Envireau Electrical Installation Trouble Shooting

    GL0052-03 – Envireau Mono-Tech Rainwater – Installation & Operation Guidelines ENVIREAU ELECTRICAL INSTALLATION TROUBLE SHOOTING PROBLEM LIKELY CAUSE SOLUTION No indication on the DISPLAY System switched off or Reset R.C.D. If tripping continues check for UNIT.i.e, no pointer or alarm R.C.D.
