Callaway Golfit HR Band User Manual

2 in 1 - golf gps and fitness band.
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading

Related Manuals for Callaway Golfit HR Band

Summary of Contents for Callaway Golfit HR Band

  • Page 2 © 2017 CALLAWAY GOLF COMPANY. Callaway Golf and the Chevron device are trademarks of Callaway Golf Company. IZZO Golf is an official licensee of Callaway Golf Company.
  • Page 3 GOLFIT BAND...

  • Page 4: Specifications

    INTRODUCTION The Callaway Golfit HR Band combines elite, on the course performance with a sleek, stylish fitness band. On the course, get accurate distances to Front, Center, Back of the green. Off the course, track your steps, heart rate, and sleep pattern.
  • Page 5 CHARGING Attach the magnetic pins on the charging cord to the magnetic charging ports located on the back of the band (under the heart rate sensor). Be sure the pins are aligned, then insert the other end of the charging cord into a USB port or AC adapter (not included).
  • Page 6 DESCRIPTION OF TERMS PRESS - Press & Release button quickly. • • HOLD - Press & Hold button until desired screen appears or change happens. [ POWER / BACK ] - HOLD to Power On/ Off. Press & Release to return to a previous screen.
  • Page 7 GOLF MODE From Time Screen, Press & Release the [ DOWN ] button twice to display Golf Mode (A). Press & Release the [ OK ] button to select Golf Mode. Device will begin searching for satellite signal (Press & Release the [ BACK ] button to cancel).
  • Page 8 DISPLAY DIAGRAM PLAY MODE Distance to the Front of Green Distance to the Center of Green Distance to the Back of Green Hole Number Par for the hole Unit of Measure (Yards or Meters) While on the Play Mode screen, HOLD the [UP] button to access Shot Distance, or HOLD the [DOWN] button to access the Scorecard.
  • Page 9 SHOT DISTANCE From the Play Mode Screen, HOLD the [ UP ] button display Shot Distance. As you travel to your ball, the distance will begin calculating. Once you arrive at your ball, the distance displayed is the distance of your previous shot (the distance you traveled).
  • Page 10 END ROUND To end your round, PRESS [ POWER/BACK ] button.Scroll to the desired option then PRESS [OK] button to select. • Save & Exit - Save Scorecard, end round, and return to Main Menu. Discard & Exit - Discard Scorecard, end •...
  • Page 11 HEART RATE From Time Screen, Press & Release the [ DOWN ] button until you reach the Heart Rate screen. Press & Release the [OK] button to start. (Wait 1-2 minutes for the heart rate to calibrate). To save the Heart Rate data to the device’s memory (so it can be uploaded to the free APP later), you must return to the Time Screen by Pressing the [UP] button.
  • Page 12 SLEEP Note: You must preset your sleep time in the App to use this feature. In the App, go to Settings at the bottom of the screen. Then select User Settings. Select Preset Sleep from the menu. HOW TO USE...
  • Page 13 Set the time you usually fall asleep (start time) and the time you usually wake up (end time). Then click Save. The band will measure the amount of time you are sleeping based on movement during the preset sleep hours. If the band senses movement for 3-5 minutes, the band will exit sleep mode.
  • Page 14 SCORE HISTORY From Time Screen, Press & Release the [ DOWN ] button until you reach the Score History screen. Press & Release the [ OK ] button to select Score History. Use the [UP/DOWN] buttons to scroll to the scorecard you would like to view, then PRESS [OK].
  • Page 15 SETTINGS From Time Screen, Press & Release the [ UP ] button until you reach the Settings screen. Press & Release the [ OK ] button to select Settings. Use the [UP/DOWN] buttons to scroll to the setting you would like to change, then PRESS [OK].
  • Page 16 TIME SET While in Settings, Use the [UP/DOWN] but- tons to scroll to the Time Set screen, then PRESS [OK]. Auto - will start search for satellite • connection to set the correct time (must be outside). Format • - Choose from 24 or 12 hr time format.

  • Page 17: Screen Display

    SCREEN DISPLAY While in Settings, Use the [UP/DOWN] buttons to scroll to the Screen Display screen, then PRESS [OK]. Use the [UP/DOWN] buttons to select Type 1 or 2, then PRESS [OK]. Press & Release the [ POWER/BACK ] button to return to the Main Menu. FREE APP Search for GOLFIT HR in the Google Play Store...
  • Page 18 PAIRING BAND WITH APP Make sure the phone you’re pairing to has Bluetooth enabled and your Golfit HR is powered on. Open the GOLFIT HR App. Select the settings tab in the bottom right corner. On the settings screen, scroll down to “Bluetooth Pair”...
  • Page 19 Select your specific device when it is listed under “Scan BlueTooth.” Once you select your Golfit HR Device, the band will pair with the app. Once the pairing is successful, “Connect Success” will appear on the screen. PAIRING 17...
  • Page 20 WARRANTY POLICY This product is warranted to be free from defects for up to (1) year from the original purchase date. IZZO Golf cannot refund your purchase unless purchased directly from IZZO Golf. IZZO Golf will replace or repair any unit that is determined defective under normal use within the warranty period.
  • Page 21 • Please do not store the device in places exposed to direct sunlight or in extremely high temperatures. © 2017 CALLAWAY GOLF COMPANY. Callaway Golf and the Chevron device are trademarks of Callaway Golf Company. IZZO Golf is an official licensee of Callaway Golf Company.
