Our company network supports you worldwide with offices in Germany, Austria,
Switzerland, Great Britain and the USA. For more information please contact:
FORTEC Elektronik AG
Hauptniederlassung
Lechwiesenstr. 9
86899 Landsberg am Lech
Telefon:
+49 (0) 8191 91172-0
Telefax:
+49 (0) 8191 21770
E-Mail:
sales@fortecag.de
Internet:
www.fortecag.de
FORTEC Elektronik AG
Büro Wien
Nuschinggasse 12
A-1230 Wien
Telefon:
+43 1 8673492-0
Telefax:
+43 1 8673492-26
E-Mail:
office@fortec.at
Internet:
www.fortec.at
The information contained in this document has been carefully researched and is, to the best
of our knowledge, accurate. However, we assume no liability for any product failures or
damages, immediate or consequential, resulting from the use of the information provided
herein. Our products are not intended for use in systems in which failures of product could
result in personal injury. All trademarks mentioned herein are property of their respective
owners. All specifications are subject to change without notice.
Manual
Epsilon-8100
Diamond Systems
FORTEC Elektronik AG
Büro West
Hohenstaufenring 55
50674 Köln
Telefon:
+49 (0) 221 272 273-0
Telefax:
+49 (0) 221 272 273-10
E-Mail:
west@fortecag.de
Internet:
www.fortecag.de
ALTRAC AG
(Tochter der FORTEC):
Bahnhofstraße 3
CH-5436 Würenlos
Telefon:
+41 (0) 44 7446111
Telefax:
+41 (0) 44 7446161
E-Mail:
info@altrac.ch
Internet:
www.altrac.ch
Advertisement
Table of Contents
Summary of Contents for FORTEC Elektronik AG Epsilon-8100
- Page 1 Manual Epsilon-8100 Diamond Systems Our company network supports you worldwide with offices in Germany, Austria, Switzerland, Great Britain and the USA. For more information please contact: FORTEC Elektronik AG FORTEC Elektronik AG Hauptniederlassung Büro West Lechwiesenstr. 9 Hohenstaufenring 55 86899 Landsberg am Lech 50674 Köln...
- Page 2 Epsilon-8100 User Manual Managed 8-Port Gigabit Ethernet Switch Revision Date Comment 08/12/2014 Initial Release 1/23/2015 Removed POE information 1/4/2016 Minor updates Copyright 2016 FOR TECHNICAL SUPPORT Diamond Systems Corporation PLEASE CONTACT: 555 Ellis Street Mountain View, CA 94043 USA support@diamondsystems.com...
-
Page 3: Table Of Contents
Port Configuration ..........................20 6.6.3 Change Switch Password ........................20 6.6.4 Set up VLANs ............................ 21 6.6.5 SNMP configuration ........................... 21 6.6.6 Mirroring ............................. 22 6.6.7 Setup QoS ............................22 6.6.8 Firmware Upgrade ..........................22 www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 2... - Page 4 Web Interface Activation / Deactivation ..................... 30 7.1.9 Firmware Upgrade ..........................30 7.1.10 Save Startup Configuration ........................ 31 7.1.11 Factory Defaults ..........................31 7.1.12 Physical Reset ........................... 32 Specifications ..............................33 Appendix A Supported MIBs ........................... 34 www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 3...
-
Page 5: Important Safe Handling Information
Always store this product in ESD-protective packaging when not in use. Safe Handling Precautions The Epsilon-8100 board contains a high density connector with many connections to sensitive electronic components. This creates many opportunities for accidental damage during handling, installation and connection to other equipment. -
Page 6: Introduction
2. INTRODUCTION Epsilon-8100 is a managed, 8-Port Gigabit Ethernet Switch with wide power supply voltage input and a serial management port. Epsilon-8100 offers 10/100/1000Mbps copper twisted pair ports on a PC/104 format board. An RS-232 interface is provided to enable communication between the on-board management microcontroller and a host processor through a Command Line Interface (CLI). -
Page 7: Mechanical And Environmental
Component and heat sink height -40°C to +85°C ambient operating temperature 2.2 Products The table below lists the model number and description for the Epsilon-8100 and its associated cable kit. Model Number Description 8-Port Gigabit Ethernet Switch with heatspreader, PC/104 EPS-8100-XT form factor, -40°C to +85°C operating temperature... -
Page 8: Functional Overview
Figure 1. Functional Block Diagram Epsilon-8100 is an 8-Port managed Gigabit Ethernet switch module offering 10/100/1000Mbps copper twisted pair ports on a PC/104 form factor board. Epsilon-8100 operates standalone, requiring no connection to a single board computer in the stack. -
Page 9: Board Layout
The following photo shows the locations for all connectors and jumpers which are described in the next sections. Power In LAN1 LAN2 LAN3 LAN4 LAN5 LAN6 LAN7 LAN8 RS-232 Figure 2. Epsilon-8100 Connectors and Jumpers www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 8... -
Page 10: Connector And Jumper List
Power In Wide voltage power input Jumper Block J15 4.2 Jumper Block (J15) The following table summarizes the functions of Epsilon-8100’s jumper block, J15. Refer to the Figure 2 for the location of J15 on Epsilon-8100. Jumper Function J15 Pins 1&2... -
Page 11: Connector Pinout And Pin Description
5. CONNECTOR PINOUT AND PIN DESCRIPTION 5.1 Ethernet (J4-J11) Epsilon-8100 contains eight right-angle, locking pin headers for the eight Ethernet ports. Each port has the same style and pin out. Each signal is associated with a particular color inside of the Diamond Systems cable part number 6981052. -
Page 12: Led Status Signals (J13)
Connector Type: 2mm dual row right-angle, locking pin header with tin plating Mating Connector: JST Sales America PUDP-30V-S housing with SPUD-002T-P0.5 terminals The following diagram shows how to connect external LEDs to connector J13: www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 11... -
Page 13: Command Line Interface
To get access to the CLI you must login by entering a username and password. You will automatically be queried about the password. The password is configurable. You may logout at any time and at any context level using the exit command www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 12... -
Page 14: Help Utility
Negate a command or set its defaults ping Send ICMP echo messages reload Reload system. send Send a message to other tty lines show Show running system information terminal Set terminal line parameters www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 13... -
Page 15: Ip Commands
# show vlan status [ interface ( <port_type> [ <plist> ] ) ] [ combined | admin | nas | mvr | voice-vlan | mstp | erps | vcl | evc | gvrp | all | conflicts ] www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 14... -
Page 16: Dot1X (Ieee Standard For Port-Based Network Access Control)
# show access-list ace-status [ static ] [ link-oam ] [ loop-protect ] [ dhcp ] [ ptp ] [ upnp ] [ arp-inspection ] [ evc ] [ mep ] [ ipmc ] [ ip-source-guard ] [ ip-mgmt ] [ conflicts ] [ switch <switch_list> ] www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 15... -
Page 17: Logging Commands
(config)# loop-protect (config)# loop-protect shutdown-time <t> (config)# loop-protect transmit-time <t> (config)# no loop-protect (config)# no loop-protect shutdown-time (config)# no loop-protect transmit-time # show loop-protect [ interface ( <port_type> [ <plist> ] ) ] www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 16... -
Page 18: Qos Commands
# show snmp mib ifmib ifIndex # show snmp security-to-group [ { v1 | v2c | v3 } <security_name> ] # show snmp user [ <username> <engineID> ] # show snmp view [ <view_name> <oid_subtree> ] www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 17... -
Page 19: Sntp Commands
(config)# no terminal length (config)# no terminal width # terminal editing # terminal exec-timeout <min> [ <sec> ] # terminal help # terminal history size <history_size> # terminal length <lines> # terminal width <width> www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 18... -
Page 20: Reload
| rx | tx } (config)# no monitor destination (config)# no monitor source { { interface ( <port_type> [ <v_port_type_list> ] ) } | { cpu [ <cpu_switch_range> ] } } www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 19... -
Page 21: Examples
10Mbps 100Mbps 1000 1Gbps auto Auto negotiation (config-if)# speed 100 (config-if)# end 6.6.3 Change Switch Password Following example shows setting of new password, # configure terminal (config)# password unencrypted <password> (config)# exit www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 20... -
Page 22: Set Up Vlans
Following example depicts the configuration of SNMP, To enable the SNMP mode operation # configure terminal (config)# snmp-server (config)# exit SNMP Trap configuration, # configure terminal (config)# snmp-server host Example (config-snmp-host)# host 192.168.1.20 (config-snmp-host)# exit (config)# exit www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 21... -
Page 23: Mirroring
(config-if)# qos pcp 1 (config-if)# end 6.6.8 Firmware Upgrade A new WebStax image can be downloaded using the CLI. Copy the Epsilon-8100.dat file to a TFTP server and use the firmware upgrade command to download the file. # firmware upgrade tftp://<ip_address>/<path>/Epsilon-8100.dat 6.6.9 Factory defaults... -
Page 24: Web Interface
3. Modify the IP Address in IPv4 Address column (refer to figure below) 4. Click on Save 5. Navigate to Maintenance -> Configuration -> Save Startup-Config and click on Save Configuration Figure 3 – IP Configuration www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 23... -
Page 25: Port Configuration
4. After port configuration is done click on save 5. To save these settings permanently navigate to Maintenance -> Configuration -> Save Startup-config click on Save startup configuration Figure 4 – Port configuration www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 24... -
Page 26: Change Password
3. Enter the Old password and New Password and click on Save (refer to figure below) 4. Navigate to Maintenance -> Configuration -> Save Startup-Config and click on Save Configuration Figure 5 – System Password Configuration www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 25... -
Page 27: Set-Up Vlans
2. Ports 1 & 4 to 8 assigned to VLAN ID 1, Port 2 is assigned to VLAN ID 2 and Port 4 is assigned to VLAN ID 3 Figure 7 – VLAN Membership Status for Combined users www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 26... -
Page 28: Snmp Configuration
1. Navigate to Security -> Switch -> SNMP -> Trap and click on Add new Entry 2. Make the SNMP Trap configuration as follows and click on save Figure 8 – SNMP Trap configuration www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 27... -
Page 29: Mirroring
1. Connect to the web interface of EPS-8100 switch 2. Navigate to Configuration -> Mirroring (Refer below Figure) Figure 10 – Mirroring Configuration 3. Click on Save to save the mirroring configuration. www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 28... -
Page 30: Setup Qos
All traffic coming on port 1 is mapped to Cos 2 and PCP is set as 1. Web GUI Configuration: (Navigate to Configuration ->QoS->Port Classification) Figure 11 – QoS Ingress Port Classification www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 29... -
Page 31: Web Interface Activation / Deactivation
1. Connect to the web interface of EPS-8100 switch and navigate to Maintenance -> Software -> Upload (as shown in the figure below) 2. Choose Epsilon-8100.dat file and click on upload The existing firmware is erased and new firmware loaded. Once the upgrade completes the switch reboots automatically. -
Page 32: Save Startup Configuration
1. Connect to the web interface of EPS-8100 switch 2. Navigate to maintenance -> Factory defaults 3. Click on Yes for an confirmation message (refer to the figure below) Figure 14 – Restore Factory defaults www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 31... -
Page 33: Physical Reset
Power on the board and wait till the Ethernet connection is established c. Remove the loopback cable Note: The factory default configuration is only loaded and not stored. To permanently store this configuration, refer to section 7.1.9. www.diamondsystems.com Epsilon-8100 User Manual Revision A.3 Page 32... -
Page 34: Specifications
8. SPECIFICATIONS The specifications for Epsilon-8100 are summarized in the following table. 8-port, layer 2+ switch Ethernet switch Built-in 416MHz MIPs 24KEC microcontroller for configuration and management Number of ports 8 10/100/1000Mbps copper Ethernet ports with non-blocking wire-speed performance 4Mb packet memory... -
Page 35: Appendix Asupported Mibs
APPENDIX A SUPPORTED MIBS Epsilon-8100 supports the following management information bases (MIBs). Each MIB contains definitions and information regarding the properties of managed resources and the services that the agents support. The following MIBs are supported by Epsilon-8100: LLDP RFC1213 Interfaces... - Page 36 Our company network supports you worldwide with offices in Germany, Austria, Switzerland, Great Britain and the USA. For more information please contact: FORTEC Elektronik AG FORTEC Elektronik AG Hauptniederlassung Büro West Lechwiesenstr. 9 Hohenstaufenring 55 86899 Landsberg am Lech 50674 Köln...
