Summary of Contents for Trebs CC-105

Page 3 OMSCHRIJVING ONDERDELEN achteruitrijdcamera FT LCD monitor en dashboardhouder ACCESSOIRES Bedrading voor permanente Autoruithouder 12 Volt aansluiting bevestiging van monitor Plakstrips om Bouten voor Schroeven voor Accessoire Ventilatiehouder monitor op bevestiging bevestiging ten behoeven dashboard te kentekenplaat kentekenplaat van instellen bevestigen camerahoek Kroonsteentjes voor Afsluitring...
Page 17 Back-up Camera System with Color LCD Monitor Series Model:CC-105...
Page 18: Table Of Contents
CONTENTS Foreword Packing List Structure Installation FCC Information Specifications...
Page 19: Foreword
FOREWORD CONGRATULA TIONS.The Wireless Back-up Camera, when used as described, will give you years of dependable service in your car,truck,RV,or mini-van. We have taken numerous measures in quality control to ensure that your product arrives in top condition, and will perform to your satisfaction. PACKING LIST Back Up Camera TFT-LCD Monitor Series...
Page 20: Structure
STRUCTURE BACK UP CAMERA Power Cord Bracket Lens TFT-LCD MONITOR SERIES TFT-LCD LED Power Light Image Orientation ON/OFF Universal Bracket Installation Mount Brightness Channel Selector Power Supply Socket...
Page 21: Installation
INSTALLATION These installation instructions do not apply to all vehicles. They are meant as only as a general guide due to the large number of vehicle makes & models. For vehicle specific questions, contact your vehicle's manufacturer. Consult your local motor vehicle laws on the use of this product. MONITOR INSTALLATION When choosing a location to mount the monitor, make sure the monitor is on a smooth, flat, level area that will not obstruct your vision while...
Page 22 3.1 Choose a Location and Power Cable 3.1.1 Temporarily place the monitor stand in the location that you have chosen. 3.1.2 If you are using the supplied Monitor Wiring Harness, route the power cable to the vehicle's fuse box. If you are using the 12V adapter, route the power cable to the vehicle's cigarette lighter socket/12V Monitor with the 12 Volt...
Page 23 3.2.4 Then press the monitor stand firmly onto the area you just cleaned. Adhesive reaches maximum strength in 24 hours. Moving the fastener from its original position will weaken the adhesive and may damage the mouning surface.(Fig.4) Fig. 4 To maximize the effectiveness of the Hook & Loop fastener , it is recommended that the application be performed under the following conditions: Surface temperature should be between 21 C and 38 C(70F and 100F)
Page 24 MONITOR POWER CONNECTION There are two ways to supply the monitor with power, one uses a 12 Volt cigarette lighter adapter plugged into the vehicle's cigarette lighter socket, and the other uses a wiring harness hard wired to the vehicle's box.
Page 25: Camera Installation
CAMERA INSTALLATION When mounting the camera you must make sure that it's field of view is not obstructed. To adjust the angle of the camera, use the supplied wedge shaped shims. We recommend to attached the camera under the license plate. The camera can be attached by screwing or sticking. 1.Loosen the license plate bolts/screws, then remove the rear license plate.
Page 26 AND SEE WHAT IS BEHIND WHERE YOU ARE DRILLING. If there are any vehicles components, such as electrical parts or fuel system components behind where you are drilling, you must take whatever precaution is necessary not to Fig. 5 damage them. Remove the license plate and camera before drilling.
Page 27 colored wire. If you are uncertain about the wiring, you can use a 12 volt test light available at most auto parts stores to determine which is the positive wire. a.Remove the reverse light socket from its housing, then remove the blub from the socket.
Page 28 15. Now stick the camera on the chosen location of the vehicle with waterproof montage glue. Please read the instructions of the glue packing carefully before you use it. CAMERA WIRING DIAGRAM The camera is equipped with Reverse Voltage Protection. If the camera does not operate, please check that the Red wire is connected to positive (+) and the Black wire is connected to negative(-).
Page 29: Testing The System
TESTING THE SYSTEM 1.Re-attach the vehicle's negative battery cable. 2.Engage the parking brake and turn the ignition key to the ON position. DO NOT start the vehicle. Put the gear shift into reverse. 3.The camera will start broadcasting, and the monitor will detect the signal and turn itself ON.
Page 30: Fcc Information
FCC INFORMATION This device complies with part15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user s authority to operate the equipment.
Page 31: Specifications
CAMERA 720 480(NTSC) 720 576(PAL) Minimum Illumination <5 Lux 8mW,type (Max.) 90mA Unobstructed Effective Range (Min.) 100m 258 37 41(mm) 115g 2.5 TFT color LCD Screen Type LCD display ISM 2,400~2,483MHz 640(H) 240(V) Effective Pixels Video System NTSC/PAL Color Configuration RGB.delta Received Sensitivity -85dBm...
