Car Solutions MASERATI PAS-T 161209 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MASERATI PAS-T

(VIDEO Interface)

MODEL
MASERATI PAS-T-161209
DATE
2016.04.20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MASERATI PAS-T 161209 and is the answer not in the manual?

Questions and answers

Summary of Contents for Car Solutions MASERATI PAS-T 161209

  • Page 1: Video Interface

    MASERATI PAS-T (VIDEO Interface) MODEL MASERATI PAS-T-161209 DATE 2016.04.20...
  • Page 2 Main Spec. 1. Input Spec. (MULTI VIDEO INTERFACE) - 2 x A/V Input (External video source). - 1 x CVBS(REAR CAMERA) Input. (Rear camera source) - 1 x CVBS(FRONT CAMERA) Input. (Front camera source) - 1 x Analog RGB Input (Navigation System output) - 1 x LVDS Input.

  • Page 3: External Appearance

    External Appearance LVDS IN LVDS OUT PROGRAM DIP S/W IMAGE POWER/IE Capacitive Touch NAVI NAVI MODE TOUCH...

  • Page 4: Connector Pin Assignment

    Connector Pin Assignment *POWER Connect *Touch Connect *NAVI Connect ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ① ② ③ ④ ① ② ③ ④ ⑤ ⑥ ⑦ ① ACC (Red) ① Y- ① R DATA (Red) ② CAN-H (Orange) ②...

  • Page 5: Product Composition

    Product Composition LVDS CONNTOR 1 EA Power Cable(8pin) 1 EA Interface 1 EA LVDS-OUT Cable 1 EA A/V Cable 1 EA RGB Navi Cable 1 EA LVDS-IN Cable 1 EA Touch converter Cable (for KD-900) 1 EA OSD Board 1 EA Mode S/W 1 EA...
  • Page 6 Product Composition TOUCH Option Option : TOUCH Board Option : 7.0 inch Capacitive Option : Touch Cable Touch Screen...

  • Page 7: Dip S/W Setting

    DIP S/W Setting * ON : DOWN , OFF : UP Function Selection * Example ON : Skipping NAVI -Use input mode : NAVI, AV1 NAVI OFF : Display -Mode change : by using OEM button on steering wheel ON : Skipping Video -Car : GranTurismo MC AV1 (DVB-T) OFF : Display...

  • Page 8: Mode Change

    Mode Change Steering wheel Not use Steer wheel button. Use Steer wheel button. ※The screen is switched in order as the pictures below NAVI...
  • Page 9 Mode Change Touch screen – Switching mode ※ It is necessary to install the provided capacitive touch file on OEM monitor ※ Switching from OEM screen to External screen only (not possible to switching input mode) Sliding the screen from right Sliding the screen from left to left for switching mode to right for switching mode...
  • Page 10 Mode Change Touch screen – Switching mode Use Home icon, OSD menu set ‘ON’ Back to OEM screen Press long Home icon Or, press return icon...
  • Page 11 OSD(On Screen Display) Control OSD Control Board MENU DOWN MENU Push -> OSD menu On/Off Item Selection, Value Selection Item up Increase selected value DOWN Item down Decrease selected value Mode State First Menu Second Menu Third Menu...
  • Page 12 OSD(On Screen Display) Control First Menu Second Menu Third Menu Action Original Camera RearCam-Type ExtDevice Use aftermarket Rear camera Rear camera get +12V consistently RearCam-Power AUTO Rear camera get +12V when reverse gear on Shut out the power supply. Original Camera FrontCam-Type Option ExtDevice...
  • Page 13 OSD(On Screen Display) Control NAVI-RGB menu DVD,DVB-T(DMB),NAVI-AV,REAR,FRONT menu First Menu Second Menu Third Menu Action First Menu Second Menu Third Menu Action Brightness Adjust the value of brightness Brightness Adjust the value of brightness Contrast Adjust the value of contrast Contrast Adjust the value of contrast Color-RED...
  • Page 14 OSD(On Screen Display) Control OSD Setting– Screen Mode - Horizontal - Vertical - Scaler X Up - Scaler X Down - Scaler Y Up - Scaler Y Down...
  • Page 15 OSD(On Screen Display) Control OSD Setting – Front Camera Auto Mode - Option -> RearCam-RcvOpt -> 0 second = RearCam-RcvOpt menu OFF 1~30 second = RearCam-RcvOpt menu ON & time control NAVI NAVI REAR FRONT AV1(DVB-T) AV1(DVB-T) AV2(DVD) AV2(DVD) 1~30 second...
  • Page 16 OSD(On Screen Display) Control OSD Setting – Utility Mode - Factory Reset : Execute - Reset All (Setting Default) - Version : FW Version Finish update FW, check the FW versoin Last Source : BEPP06SGX-130950 Software Version Software Month Software Year Special Version National : CN=CHINA, KR=KOREA, JP=JAPAN, US=United States Hardware Version...
  • Page 17 Install Manual 1. Quattroporte...
  • Page 18 Install Manual 2. GranTurismo * Quattroporte and GranTurismo LVDS cable are different LCDIN/OUT change.
  • Page 19 Q & A 1. If Interface has a problem, Please check LED. - ACC on (12v), If Interface does not have a problem; GREEN LED is blinking every 1 sec.. LED is turn on (not blinking), Interface has a problem. LED is turn off every 1 sec, there is no input.
