3D 4Kx2K HDMI 4X1 SWITCH
3D HDMI SWITCH

User Manual

HDMI 4x1 Switcher
(3D Full HD 4Kx2K)
Bring High-Definition to your life!
Thank you for purchasing our product. To ensure safety and many years'
Trouble-free operation of the product, Please read the manual carefully
before using this product.

PACKAGING ACCESSORIES

1、HDMI SWITCH:
1Piece
2、5V DC Power Adaptor:
1Piece(Optional)
3、User Manual:
1Piece
4、Remote Control:
1Piece(Optional)

INSTALLATION AND PRECAUTIONS

To avoid electric shock, product damage and to protect your safety, please
notice the following:
1、
Please slowly plug or unplug signal cables and do not often plug,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDSW4 and is the answer not in the manual?

Questions and answers

Summary of Contents for SOFLY HDSW4

  • Page 1: User Manual

    3D 4Kx2K HDMI 4X1 SWITCH 3D HDMI SWITCH User Manual HDMI 4x1 Switcher (3D Full HD 4Kx2K) Bring High-Definition to your life! Thank you for purchasing our product. To ensure safety and many years' Trouble-free operation of the product, Please read the manual carefully before using this product.
  • Page 2 3D 4Kx2K HDMI 4X1 SWITCH unplug, or shake them. 2、 The equipment should not be placed under the sun, rain and damp or unventilated environment. 3、 Liquid items should not be placed on the equipment. 4、 Do not install the equipment near heat sources such as fire, power, or other amplifiers that produce heat.
  • Page 3 3D 4Kx2K HDMI 4X1 SWITCH HOW IT WORKS 1. Connect high definition display device such as HDTV TO HDMI Switch's output port 2. Connect source device such as DVD and ps3 TO HDMI Switch's input ports. 3. After all the connections have been successfully done and then power on, you can select the information you want to view or listen Note: When HDMI Switch works, make sure the source device and display device are well connected with cables.
  • Page 4 3D 4Kx2K HDMI 4X1 SWITCH Bandwidth Up to 340Mhz Signal Speed Up to 10.2Gbps The length of input cable PS3≤10M;BLUE DVD≤10M ≤10M The length of output cable The cable standard 28AWG HDMI1.4 Vertical Frequency Range 30Hz Power Consumption(max) 1.5 Watts Operation Temperature 0℃...
