Aqua Logic
Aqua Logic
Aqua Logic
Aqua Logic
Aqua Logic
Installation/Operation Manual
Base Receiver
for model
AQL-BASE-RF
G
LDLINE
CONTROLS INC.
North Kingstown, RI USA
www.goldlinecontrols.com
®
Advertisement
Table of Contents
Summary of Contents for Gold Line AQL-BASE-RF
- Page 1 Aqua Logic Aqua Logic Aqua Logic Aqua Logic Aqua Logic ® Base Receiver Installation/Operation Manual for model AQL-BASE-RF LDLINE CONTROLS INC. North Kingstown, RI USA www.goldlinecontrols.com...
- Page 2 Compatibility This product is compatible with all Aqua Logic controls operating software revision r1.10 or higher. To verify the software level of your Aqua Logic control: Press the Menu button (possibly multiple times) until “Diagnostic Menu” is displayed. Next, press the “>” or “<“ keys (possibly multiple times) until the main and display soft- ware revision levels are displayed (the “main”...
- Page 3 RF base station. Secure the base receiver in place by firmly tightening the nut from inside the Aqua Logic unit. Lastly, plug the pigtail cable into the “wireless connector” connector on the Aqua Logic main circuit board. Connector for Base Receiver Base Receiver (AQL-BASE-RF) Aqua Logic Main PCB Tighten nut...
- Page 4 Operation Every Base Receiver is manufactured with a unique ID code. This allows private, secure communication with all of your remote devices while ignoring any signals transmitted by other wireless devices including any other Aqua Logic controls in the neighborhood. IMPORTANT: Before trying to use any remote device: You must "teach"...
-
Page 5: Troubleshooting
Troubleshooting If you believe that your system is not operating properly or if you have a general question regarding system operation, you may call the Goldline Technical Service Dept. from Monday through Friday, 8AM to 8PM Eastern at 888-921-7665. Can’t find the “Teach Wireless” display: Press the “menu” button (possibly more than once) until “Settings Menu”... - Page 6 Aqua Rite Aqua Rite Aqua Logic Aqua Logic Aqua Rite Aqua Rite Aqua Rite , Aqua Logic Aqua Logic Aqua Logic ® ® & Aqua Trol Aqua Trol Aqua Trol Aqua Trol Aqua Trol ® Limited Warranty ® ® This warranty statement is applicable to all Aqua Rite Aqua Logic and Aqua Trol units with product date codes of January 1, 2002 and after, and supersedes all warranty statements dated...
- Page 7 The express warranty above constitutes the entire warranty of Goldline Controls, Inc with respect to the Aqua Rite, Aqua Logic, and Aqua Trol products and IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING A WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE.
- Page 8 FCC Statement (Compliance Statement, Part 15.19): This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interfer- ence received, including interference that may cause undesired operation.
