GreenTech pureWater ALKALINE XT Owner's Manual

Water ionizer

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

ALKALINE

Owner's Manual

Table of Contents

Need help?

Do you have a question about the pureWater ALKALINE XT and is the answer not in the manual?

Questions and answers

Summary of Contents for GreenTech pureWater ALKALINE XT

Page 1 ALKALINE Owner’s Manual...
Page 2: Table Of Contents
We hope you enjoy the endless benefits of alkaline water provided by your Alkaline XT Water Ionizer for many years to come. RECORDS Please record the name and phone number of your Dealer. Name: ________________________________________________________________________________ Phone #: ______________________________________________________________________________ Please record the serial number of your pureWater Alkaline XT. Serial #: _______________________________________________________________________________...
Page 3: Glossary
GLOSSARY The great and many benefits of alkaline water are simple to understand, but the technology and chemistry involved in producing alkaline water can be more difficult to comprehend. Below is a glossary of some frequently used technical terms associated with water ionization. The pH scale measures the level of acidity or alkalinity of a substance.
Page 4: Warnings
WARNINGS Consult a doctor before use, especially if you have a weak liver, kidneys or are under treatment for any ailments. Never use aluminum or copper containers to store your ionized water. A chemical reaction may occur. Acidic water is for external purposes only. Do not ingest. Never take medicine with alkaline water.
Page 5: Parts & Accessories
PARTS & ACCESSORIES Adapter A x 1 Adapter B x 1 Adapter C x 1 Adapter D x 1 Connector x 1 Screws x 3 Adapter Key x 1 Rubber Tightener x 1 Diverter x 1 Clamps x 2 Inlet/Drain Hose x 2 Outlet Hose x 1 Wall Mount x 1 pH Test Kit x 1...
Page 6: Installation
INSTALLATION 1. Determine the faucet’s threading, choose appropriate adapter and install as shown. Adapter Adapter External Thread Internal Thread Adapter Adapter Note: These directions apply to both External and Internal Threads. Tighten the adapter into place using Attach diverter to the adapter and the locking key with the gasket and fasten the nut around it.
Page 7: Installation
INSTALLATION CONT. 2. Install the Connector. Push the connector into the diverter. Twist into position in a counter-clockwise direction. 3. Install Hoses. Place clamps over the hose ends leaving open space to fit Cut the supplied hose in half. Connect and over the water supplies.
Page 8: Controls
CONTROLS Alkaline Water LED Acidic Water LED Lights up when your unit is Lights up when your unit is creating Alkaline Water. creating Acidic Water. Filter Replacement Notification LED Lights Up when your Filter’s lifespan has been reached. Reset Current Mode (Used with Filter Notifies you of which Replacement and...
Page 9: Modes & Uses
MODES & USES Each level of Acidic, Neutral, and Alkaline water has a general use based on its pH level. Use our guide below to know what water mode you should use for a certain situation. NOTE: Each level’s pH can be adjusted to fit your needs. Refer to Customizing Settings (Page 11) Consult a doctor before use, especially if you have a weak liver, kidneys or are under treatment for any ailments.
Page 10: Operations
OPERATIONS How it works The water first travels from your tap through a USA Made NSF-Certified Carbon filter where impurities like chlorine are removed from your tap water. After the impurities are filtered out, the water then travels through platinum coated Japanese made titanium plates where the water molecules are separated by an electric charge.
Page 11: Customizing Settings
CUSTOMIZING SETTINGS Electrolysis Intensity The water first travels from your tap through a USA Made NSF-Certified Carbon filter where The Electrolysis Intensity Setting is designed to help you calibrate each level of pH on your Alkaline XT Water Ionizer. Water quality can affect the output level of pH from your machine.
Page 12: Cleaning & Replacements
CLEANING & REPLACEMENTS Cleaning To clean your Alkaline Water Ionizer, turn on the tap and press “CLEAN”. The light will blink and music will play while your Alkaline Water Ionizer cleans itself. Once the cleaning process is complete, the music will stop and the light will no longer blink. Alkaline Water Ionizer will return to the default setting “Alkaline 3”.
Page 13: Troubleshooting
TROUBLESHOOTING LED backlight isn’t working. Check to make sure the unit is plugged in. Water pressure may be too low. Check to see if the filter is mounted correctly. Straighten any bent hoses. If problem persists, contact your retailer for repair. Ionized water flow isn’t smooth.
Page 14: Specifications
SPECIFICATIONS Dimensions 12.2” H x 8.66” W x 4.92” D Weight 9.4 lb (4.26kg) Voltage/Frequency 110V/60Hz Electrolysis 5 Titanium-Platinum Plates and Ceramic Membrane Continuous Electrolysis (built- in ammeter) Ideal rate of water flow - 1/2 gallon/min (2L/min) Power Consumption 320W MAX Filter NSF-Certified Carbon Filter 5.0 liters/min and up to 6,000L Lifespan.
Page 15: Warranty Information
Likewise, any defects or damages caused by unauthorized service are not covered. GreenTech Environmental will, at its option, repair or replace a defective Water Ionizer that is covered by this warranty. As a matter of warranty policy, GreenTech Environmental will not refund the customer’s purchase price. To obtain warranty service you must return the defective Water Ionizer along with proof of purchase to the pureWater Authorized Warranty Station.

This manual is also suitable for:

Pure water alkaline ti
