INSTALLATION MANUAL

Bottom Mounted Reach-In Refrigerators
CAUTION
service this unit. ALL WIRING AND PLUMBING MUST CONFORM TO NATIONAL AND LOCAL
CODES.
I
NTRODUCTION
This manual contains instructions for installation, operation, and general maintenance of your
commercial refrigerator. It also includes a Troubleshooting chart to diagnose problems along with
corrective actions.
C
S
HECK FOR
HIPPING
Prior to leaving the factory, each cabinet is thoroughly inspected and performance tested up to 12 hours
to assure proper operating temperatures.
Check the crate thoroughly for signs of shipping damage. If external damage exists, internal
damage is also probable and uncrating should be done while the carrier's representative is present. In
any case, the equipment should be uncrated as soon as possible, preferably within five (5) days.
The manufacturer is not responsible for in-transit damage and the consignee must file any required
damage claims directly with the carrier.
If damage is severe and obvious, write a brief description of the evidence on the carrier's delivery receipt
and above the carrier representative's signature.
If hidden damage(s) is found, contact the carrier immediately (save all crating materials) and file the
necessary freight claim with the carrier.
C
A
HECK FOR
CCESSORIES
Upon receiving the equipment, check that the shelves are inside the freezer, including the four clips or
supports for each shelf.
Release Date: June 15, 2004
© 2004, IMI Cornelius Inc.
COR23RRBM, COR49RRBMD
- Only trained and certified electrical, plumbing and refrigeration technicians should
D
AMAGE
www.cornelius.com
- 1 -
Bottom Mounted Reach-In Refrigerators Installation Manual
Revision: A
Publication Number: 630460282INS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COR23RRBM and is the answer not in the manual?

Questions and answers

Related Manuals for Cornelius COR23RRBM

Summary of Contents for Cornelius COR23RRBM

  • Page 1: Installation Manual

    Upon receiving the equipment, check that the shelves are inside the freezer, including the four clips or supports for each shelf. www.cornelius.com Release Date: June 15, 2004 Revision: A © 2004, IMI Cornelius Inc. - 1 - Publication Number: 630460282INS...
  • Page 2 (Shims may also be used when optional casters have been included.) Turn leg clockwise to lower Turn leg counterclockwise to raise Leveling leg FIGURE 2 Publication Number: 630460282INS - 2 - © 2004, IMI Cornelius Inc.

  • Page 3: Remove The Door

    Clearance: Leave at least 8” between the back of the cabinet and the wall to provide adequate air circulation of the unit compartment. 8” FIGURE 3 EMOVE THE UPPORT RACKET Open the door 30 degrees and loosen the screws. Screws FIGURE 4 © 2004, IMI Cornelius Inc. - 3 - Publication Number: 630460282INS...

  • Page 4: Installation

    If the doorway is too narrow to allow installation of the cabinet, follow these steps to remove the doors and hinges on the unit: Lift and remove the header sign (if applicable). Use a wrench to loosen the hinge nut. Publication Number: 630460282INS - 4 - © 2004, IMI Cornelius Inc.
  • Page 5 Unscrew the bottom hinge (the bottom hinge remains attached to the spring hinge rod). Unscrew and remove the top hinge. Top hinge Units with header sign Units without header sign FIGURE 7 © 2004, IMI Cornelius Inc. - 5 - Publication Number: 630460282INS...
  • Page 6 Plug in the electrical cord. Do not, under any circumstances, cut or remove the round grounding prong from the power cord. Removal of the grounding prong invalidates the product warranty. Grounding prong FIGURE 9 Publication Number: 630460282INS - 6 - © 2004, IMI Cornelius Inc.
  • Page 7 At this point it will only be possible to see the Set point or the Max or Min temperature stored. If a key is pressed more than 3 seconds, the “POF” message is displayed. © 2004, IMI Cornelius Inc. - 7 -...

  • Page 8: Troubleshooting

    Not enough refrigerant Leak check. Change drier, evacuate, and recharge. COMPRESSOR RUNS Not enough refrigerant Leak check. Change drier, CONTINUOUSLY—PRODUCT evacuate, and recharge. TOO WARM Inefficient compressor Replace Publication Number: 630460282INS - 8 - © 2004, IMI Cornelius Inc.
