SECTION 1
SECTION 2 UbTrack™ 301 Overview
7
1
Note: Your UbTrack™ wireless key fob has to paired with your device after installation and activation.
1- Power button
2- GSM LED
3- GPS LED
4- Reset Button
5- SMA Adapter for GPS Antenna
6- SMA Adapter for GSM Antenna
7- Two-PIN Power Connector
8- Functional button
9- 9-Status Light
For a complete UbTrack user rmanual, FAQs and troubleshooting tips please go to
SECTION 3
It is strongly recommended that you record and save the 12 character device ID number below the
barcode on the back of your UbTrack™ 101 locator. It is also recommended that you read the owner's
© Aspenta 2014
All rights reserved
Aspenta UbTrack 301
Permanently Installed Vehicle Locator
Quick Start Guide
2
4
3
5
6
manual thoroughly prior to operating your device.
UbTrack™ key fob automates arming and disarming of the
UbTrack™ 301 security feature. Please keep it with you on your
8
9
keychain.
http://aspenta.com/
Revision 1.1
September, 2014
