Summary of Contents for TYPHOON 20006
- Page 1 USER’S MANUAL Bluetooth™ 56K Wireless Modem Kit Bluetooth™ Software & Modem installation procedures (Read this first) Article Number: 20006 09/2003 Version 2.0 http://www.typhoonline.com...
-
Page 2: Table Of Contents
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 Content: Illustrations Features & System Requirements Windows® 98SE / ME / 2000 / XP installation Bluetooth™ software installation and basic operations Start and Stop Bluetooth™ services iii. Create a connection from the Bluetooth™ icon in the system tray Create a connection using the Bluetooth™... -
Page 3: Features & System Requirements
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 2. Features V.90 Modem • ITU-T V9.0 and K56flex • V.34 (33.6 kbps), V.32 bis, V.32, V.22 bis, V.22, V.23, and V. 21; Bell 212A and 103 • Flow control and speed buffering •... - Page 4 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 Please select “Install Drivers and Application Software” and the installation will proceed. Under “USB Dongle:” click on the blue selection “Windows 98 / ME / 2000 / XP”. (Note: Windows 98 refers to the Second Edition, the First Edition is not supported) 5.
- Page 5 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 8. You can choose to change the destination folder in your system by clicking on the “Change” button, alternatively to use the default, click on the “Next” button to start. 9. The system is ready to install the Bluetooth™ software. If you need to review or change any settings, click the "Back"...
- Page 6 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 10. For Windows® 2000/XP users, system will popup a "Driver Signature Notice", please click the "OK" button to proceed. (As illustrated before this line) 11. During the installation, for some operating system version, Windows might prompt and advice to plug in the adapter.
- Page 7 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 14. Click "Yes" to restart your computer. If you plan to restart later, click "No". Note: this step might be different depending on the operating system. For Windows® XP users, please do restart without the need of the screen above.
-
Page 8: Start And Stop Bluetooth™ Services
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 3ii. Start and Stop Bluetooth™ services 1. To start Bluetooth™: in the Windows system tray, right-click the Bluetooth™ icon and select "Start Bluetooth™ Device". The Bluetooth™ icon is blue in color with a white insert when Bluetooth™ is running. - Page 9 XP users, the screen on the right will appear. Select the option that accurately reflecting your preferences. For using with the Typhoon Bluetooth™ 56K Wireless Modem Kit, go straight to the “My Bluetooth™ Places” and click on “Search for devices in range”. Refer to the manual on the modem for more information.
-
Page 10: Find A Service
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 The services supported by Bluetooth™ are: • Bluetooth™ Serial Port-a wireless connection between two devices. This connection can be used by applications as though a physical serial cable connected the devices. -
Page 11: To Confirm If The Bluetooth™ Device Is Installed Properly
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 and use as if they were actual physical ports. Each Bluetooth™ service that this computer is capable of providing can be started automatically when Bluetooth™ starts. Each service can be setup to require security measures before allowing a remote Bluetooth™... -
Page 12: Bluetooth™ Modem Installation Procedures
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 3viii. Bluetooth™ Modem installation Getting Started At the rear of the modem, push the switch to "BT" position. b. Connect the telephone line to the RJ-11 socket and the other end to the telephone wall socket. - Page 13 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 The Discover Services will start. d. Windows will prompt for a 4-digit PIN Code to pair with the Bluetooth™ Modem. You can find the PIN Code at the bottom of your Bluetooth™ modem.
- Page 14 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 g. When the connection is established, the service icon will change the color to green. h. If you are using the dial-up connection first time, the following window will pop out. Type in the area code of your location, then click the "Close"...
-
Page 15: Windows® Me
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 For Windows® ME Double click the "My Bluetooth™ Places" icon on the desktop. Next, double click the "Find Bluetooth™ Devices" icon. b. The Bluetooth™ software will start searching the surrounding remote devices. Locate the "Bluetooth™... - Page 16 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 Key in the PIN Code and click the "OK" button. When the Bluetooth™ Modem has been paired successfully; it will display 3 new services. Double click on "Dial-up Networking on Bluetooth™ Modem" service icon.
-
Page 17: Windows® 2000
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 The "Connect To" window will auto pop-up. Please type in the user name, the password, and the phone number. Refer to your ISP (Internet Service Provider) for the Login details, and then click the "Connect"... - Page 18 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 The Discovery Service will start searching. d. Windows will then prompt for a 4-digit PIN Code to pair with the Bluetooth™ Modem. You can find the PIN Code on the bottom of your Bluetooth™...
-
Page 19: Windows® Xp
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 g. When the connection is established, the service icon will change the color to green. h. The "Connect To" window will auto pop-up. Please type in the User name, the Password, and the Phone number. - Page 20 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 b. Bluetooth™ software will start searching the surrounding remote devices. Once identified, locate the "Bluetooth™ Modem" icon and then double click on it. The Discover Services will start searching. d. Windows will then prompt for a 4-digit PIN Code to pair with the Bluetooth™...
- Page 21 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 When the Bluetooth™ Modem has been successfully paired it will display 3 services. Double click on the "Dial- up Networking on Bluetooth™ Modem" service icon. g. When the connection is established successfully, the service icon will change the color to green.
-
Page 22: Modem Rs-232 Interface Installation Procedures
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 xi. Modem RS232 interface installation procedures 1. Getting Started At the rear of the modem, push the switch to "RS-232" position b. Connect the telephone line to the RJ-11 socket and the other end to the telephone wall socket. -
Page 23: Windows® Me
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 d. Windows will detect the Modem description and prepare for the installation. Click on the "Next" button to begin the driver installation process. Once completed, click the "Finish" button to complete the installation process. -
Page 24: Windows® 2000
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 Click the "Next" button to start the driver installation process. d. Click the "Finish" button to complete the installation process. For Windows® 2000 Start the computer and launch Windows® 2000. Windows will detect the new device and launch the "Found New... - Page 25 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 Select "Specify a location" then click the "Next" button. d. Type "x:\Modem" (where x:\ is the path of your CD- ROM drive) in the location, or alternatively click the "Browse" button to locate the file in the CD-ROM drive and click the "Next"...
- Page 26 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 g. After completing the process, click the "Finish" button to end the installation process. For Windows® XP Start the computer and launch Windows® XP. Windows will detect the new device and launch the "Found New Hardware Wizard"...
- Page 27 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 d. After completing the process, click the "Finish" button to end the installation. How to dial-up under Windows Please refer to the individual Windows Operating System user guides to setup a dial-up connection.
- Page 28 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 4. Troubleshooting Why doesn't my Bluetooth™ device find any nearby Bluetooth™ devices? 1) Please check that your Bluetooth™ device is enabled by opening the Bluetooth™ Configuration window. 2) If the Bluetooth™ device is enabled, you will see something of the following nature.
- Page 29 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 3) Set this key to 0x0000001. If the "Accept other" key does not exist, simply create it with type DWORD and fill in the value. Save and exit Regedit. Reboot if necessary, now you should be able to send files from Nokia 7650 to your notebook or PC.
- Page 30 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 5. ANNEX 1.1 Icons used for Bluetooth™ devices and services Bluetooth™ icons provide at-a-glance feedback about a device or service's status by changing appearance. The Bluetooth™ icon in the Windows system tray provides feedback about Bluetooth™ status.
- Page 31 TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 Device Icons for Windows XP Service Icons for Windows XP NOTE: Only available services are displayed in the menus. Version 2.0 All specifications and information are subject to changes without further notices...
-
Page 32: Windows® Xp
TYPHOON BLUETOOTH™ 56K WIRELESS MODEM KIT Article Number: #20006 Specifications • Communication software compatible AT command sets • 3.3V low power consumption • Bluetooth™ or RS-232 (D-SUB9) interface Switch • Provides LEDs for showing status information Certification • FCC Part 68 , 15 and CE Mechanical •...
