- Page 1 Ethernet Access Residential Unit 110X (1103/1104) Please read this manual carefully before operating your set. Retain it for future reference.
- Page 2 C O N T E N T S Product and personal safety guidelines Regulatory information About EARU 110X Checking package contents Installing EARU 110X Setting EARU 110X...
-
Page 3: Precautionary Messages
Precautionary messages To prevent personal injury, equipment damage, and service interruptions, you must follow all precautionary messages in LG-Nortel documentation and all local safety standards required by your service provider. The following precautionary messages appear in LG-Nortel documentation:... -
Page 4: Safety Standards
Safety standards LG-Nortel products conform to all relevant safety standards. The EARU 110X complies with the following safety standards: •IEC/EN 60950-1:2001+A11:2004—Information technology equipment - Safety, Part 1 : General requirements • IEC 60825-1:2001 and IEC 60825-2:2004—Safety of Laser Products • FDA 21 CFR 1040—Performance Standards for Light-Emitting Products Laser radiation—eye safety hazards... - Page 5 Handling optical fibers When you work with optical fibers, you must take the following general precautions: • Wear safety glasses when you install optical fibers. • Do not look into the opening of an optical fiber, or the opening of an optical fiber connector, if the optical fiber is active or the unit has the power turned on.
- Page 6 Repairing optical fibers When an accidental break occurs in the optical fiber, do the following: • Report the location of the damaged optical fiber to both the service provider and the field repair personnel. • Power down all laser sources to the optical fiber or disconnect the remote optical fiber end from the laser sources.
- Page 7 CAUTIONS Warranty: Customers can receive repair services for this product under specified conditions. This warranty does not cover failure or damage of the product caused from, using a power adapter other than the one provided, PC failures, data loss, or negligent treatment of the product.
-
Page 8: Regulatory Information
Regulatory information This chapter contains the following information: • a list of global technical standards (electromagnetic compatibility, safety) to which the EARU 110X complies • a country-by-country list of specific regulatory text required by national authorities • information on the regulatory labels affixed to the product (artwork and location on the product) The list of global technical standards provided in this chapter is not exhaustive. -
Page 9: United States Of America
Country-specific regulatory information Canada This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. United States of America This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 10: Australia/New Zealand
The product bears the CE mark as illustrated in figures on page14. A signed Declaration of Conformity is available upon request. Brazil The EARU 110X conforms with the requirements of Anatel Resolution Number 442:2006 (EMC) for a Class B product and Anatel Resolution NR 238:2000 for product safety. -
Page 11: Names And Functions Of Each Part
About EARU 110X Thank you for selecting EARU 110X (1103, 1104). The EARU 110X is an equipment working as a modem in WDM-PON (Wavelength Division Multiplexing - Passive Optical Network). This product multiplexes 125Mbps to 100Mbps Fast Ethernet signals (maximum 4ea) into WDM-PON optical signal. - Page 12 ⑥ ⑨ ① ③ ② ④ ⑤ ⑥ ⑧ ⑦ Open view...
- Page 13 LEDs and Ports functions Number Indicator Usage Color Function Power ON : Power OK ① Green display Blink : Firmware Downloading Fail ON : Alarm event & Uplink LOS ② FAIL display Blink : Temperature alarm Blink (by turns) : CPU booting ①+②...
- Page 14 Labels ③ ② ① Number item Label Location CLEI Label Side 9.652mm x 27.94mm PEC & SN Label Side 9.652mm x 27.94mm Regulatory Side 40mm x 81mm ④...
-
Page 16: Specifications
Specifications Item Specification Dimensions in mm 251mm(w) x 97(d) x 323(h) Power DC 12V, 2A Ambient Temperature -40℃ to 65℃ Humidity 20% to 80% EN 300 386 (ClassB, other then Telecom Centres) Technical standards FCC part 15 (CFR 47) (Class B) EN 55022 (Class B) / 55024 Data rate 100Mbps... -
Page 17: Checking Package Contents
Checking package contents Before installing this product, ensure all parts are provided. Checking what is in the package Check the package to make sure the following items are included. EARU 110X Main body) User manual Mounting packaging list The mounting kit is optional according to your installation invironment. - Wall mounting kit list Item Name Quantity... - Page 18 Pole mounting kit list Item Name Quantity Item Number POLE MOUNTING BRACKET M05801-00 CLAMP M05815-00 SCREW(BN660-5-25) P04963-00 WASHER(BN670-5) P04962-00 POLE MOUNTING M05816-00 INSTALLATION AIR CAP VINYL BAG ZIPPER VINYL BAG VINYL BAG...
-
Page 19: Installation Environments
Installing EARU 110X This section provides the specifications for EARU 110X installation, it also describes how to install it and connect it into a network. Installation environments Install the EARU 110X in an environment where the following specifications are met. - Operating temperature: -40℃... -
Page 20: Installing The Product
Installing the product mounting method Wall mounting Item Name Quantity Item Number EARU110X BODY POLE MOUNTING BRACKET M05801-00 SCREW(BN660-5-25) P04963-00 TAPPING SCREW BN695-5.5-32 SPRIAL PLASTICPLUG) BN309-8-38 WASHER(BN670-5) P04962-00... - Page 21 Pole mounting Item Name Quantity Item Number EARU110X BODY POLE MOUNTING BRACKET M05801-00 CLAMP M05815-00 SCREW(BN660-5-25) P04963-00 WASHER(BN670-5) P04962-00 Step1. Pass the two straps into the space back of the pole mounting bracket and then tighten the straps backward the pole with hand.
- Page 22 Step2. Tighten suitably and insert the hook into the hole of the other position of strap. Insert the rod (bolt) in the ring and tighten the nut (3 ~ 5N·m). Step3. After tightening the nut, bend the strap at the other side. suitably Step4.
- Page 23 Grounding STEP1: Unfasten the grounding screw on the rear side of the EARU 110X (see following picture) STEP2: Attach the 1-hole lug using the screw that was removed in STEP 1. The grounding connection is suitable for terminating a #18 AWG wire. GROUNDING SCREW 1-HOLE LUG...
- Page 24 Connecting power cable Connect the Battery plug to BATT interface. BATTERY INTERFACE Mark Signal Name Description +12V + Voltage + Voltage - Voltage - Voltage Signal Return Signal Return Low when operating from utility line. On Battery Open when operating from battery. Low when battery is charged.
- Page 25 Connecting optical cable Insert the SC APC connector from RN distributor into the lower optical port of the EARU 110X. Insert the SC APC connector from OTX Module distributor into the lower optical port of the EARU 110X Upper optical port Lower optical port...
- Page 26 Connecting Ethernet cable Connect Ethernet cables to the RJ45 Ethernet port numbered ETH1 to ETH4 in EARU 110X. 4 Ethernet ports Connecting Telephone cable Connect PCM cables to the PCM ports in EARU110X. Connect Telephone cables from PCM ports to RJ11 POTS port numbered TEL1 to TEL4 in EARU 110X. 4 Telephone ports 8 PCM Terminals...
- Page 27 Tieing cables After finishing calbing, tie cables at 3 points with cable ties as it looks below picture. Tieing points Checking the connection status of user devices When EARU 110X is power-fed, the Green and Yellow LEDs should be on. The green LED is the data indicator.
-
Page 28: Using Internet
Setting EARU 110X When you select to receive WDM-PON service, you do not have to make additional settings on the product to use it. Using Internet With a web browser such as the Internet Explorer on your PC, you can surf freely through the Internet.
