Read the following safety cautions for your

safety.

Please read the following safety matters for your safety. This

User's Manual describes circumstances that may

inflict injury onto drivers and others with the following notations

(Warning, Caution, Information, Notice).

Before using the product, read the contents of this user's

manual carefully and use this product safely.

The design and specification of this product may change

without prior notification for product improvement.

(Confidential) /

/ 10.230.25.192 / 2012-04-02 08:49 /

Notations used within this User's Manual

Safety Warnings

Failure to observe the safety instructions within this category

could result in serious injury or death.

Safety Cautions

Failure to observe the safety instructions within this category

could result in accident related injuries or damage

to the vehicle.

Caution

• Information on matters that could potentially lead to injury or vehicle

damage/malfunction

• Information that could lead to higher user safety

Information

• Information and tips that provides additional user convenience in

using the product

Notice

• Information on specific features that facilitate proper product use and

functional understanding

• Information on terminology used within this manual

Table of Contents

Summary of Contents for Hyundai AV240DPAN

Page 1 Read the following safety cautions for your Notations used within this User's Manual safety. Safety Warnings Please read the following safety matters for your safety. This Failure to observe the safety instructions within this category User's Manual describes circumstances that may could result in serious injury or death.
Page 2: Cautions Upon Using Sd Cards
Cautions upon Using SD Cards Ejecting and Inserting SD Cards • Ejecting and inserting SD cards while the Navigation system is operating may result in SD Card or System errors. To eject or insert the SD card, first turn off the Navigation system and the vehicle ignition.
Page 3 Bluetooth The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth® SIG, Inc. and any use of such marks by Hyundai/Kia is under license. A Bluetooth® enabled cell phone is required to use Bluetooth® wireless technology. For more information on Bluetooth® compatibility, refer to the Hyundai Motor website (http://www.hyundaiusa.com).
Page 4 Basic Warnings and Cautions Key Product Features Component Names and Functions (Confidential) / / 10.230.25.192 / 2012-04-02 08:49 /...
Page 5 Warnings and Cautions Safety Warnings Even when receiving route guidance from the Navigation Heed caution not to spill water or introduce foreign objects system, please abide by actual traffic and road regulations. into the device. Such acts could lead to smoke, fire, or Following only the Navigation route guidance may lead to product malfunction.
Page 6: Safety Cautions
Safety Cautions Pay attention to traffic conditions while driving. Technical expertise is required to install or disassemble In some instances, the navigation may provide guidance the device. through restricted areas. Turn on the car ignition before using this device. Do not Operating the device while driving could lead to accidents operate the Navigation system for long periods of time with due to a lack of attention to external surroundings.
Page 7: Key Product Features
Key Product Features This device is an Audio Navigation system equipped with a multifunctional disc player that supports Radio (FM1, FM2, AM), Audio CD, MP3, USB, iPod, and Audio AUX features. The WIDE VGA LCD provides a high quality resolution while the powerful and rich sound system adds to driving enjoyment.
Page 8: Component Names And Functions
Component Names and Functions Head Unit Notation Description [PHONE] Converts to Bluetooth® Handsfree mode When [ SEEK TRACK ] keys are pressed shortly (under 0.8 seconds) • In FM/AM mode, plays previous/next frequency • In XM mode, plays the previous/next channel •...
Page 9 Component Names and Functions Head Unit Notation Description • When power is off, press to turn power on • When power is on, press and hold (over 0.8 seconds) PWR key to turn power off VOL Knob • When power is on, press shortly (under 0.8 seconds) to turn AV off •...
Page 10: Steering Remote Controller
Steering Remote Controller Notation Description Notation Description Controls the volume • Each time this key is pressed, the mode is changed in order of FM1 USB(Music Image) [MUTE] Mutes the sound or iPod Bluetooth Audio My Music • If the media is not connected or a disc is not inserted, [MODE] When , keys are pressed shortly (under 0.8 seconds) corresponding modes will be disabled.
Page 11: Climate System
Component Names and Functions Climate System Notation Description [MODE] Sets the fan direction [CLIMATE] Displays the climate info screen Removes humidity and frost by blowing fan towards the front window The side mirror and rear window defroster is turned on/off [A/C] Turns the air conditioner on/off [TEMP]...
Page 12: Turning The System On/Off
Turning the System On/Off Turning the System Off Information Press the engine start button again or press and • If the engine start button is pressed without hold the power key on the system to turn the pressing the brakes, then the ACC and system Turning the System On system off.
Page 13: Resetting The System
Component Names and Functions Resetting the System Battery Warning Message This feature is used to reset the system in the Use the system only when the engine is running. occurrence of an unforeseen error or problem. If the system is turned on with the engine off, then the following warning will be displayed.
Page 14 Audio • FM/AM Mode • HD Radio Mode • XM Mode • About DISC • CD Mode • MP3 CD Mode • USB Mode • iPod Mode • AUX Mode • Bluetooth ® Audio Mode • My Music Mode (Confidential) / / 10.230.25.192 / 2012-04-02 08:53 /...
Page 15 FM/AM Mode Basic Mode Screen (HD Radio OFF) Name Description Mode Display Displays currently operating mode Preset Shows saved presets for user selection Setting Displays currently operating features/options Display Text On Stereo Indicates that the current broadcast is a stereo Reception broadcast Frequency...
Page 16 FM/AM Mode Basic Mode Screen (HD Radio ON) HD 3 92.9 101.9 105.1 96.9 87.1 91.3 Name Description 87.1 HD Radio PS NAME Genre Displays main HD Radio channels Reception Song Title Song Title Song Title Broadcast Artist Artist Artist Displays the current broadcast station Station Album...
Page 17: Starting Mode
Starting Mode Using SEEK Selecting Presets Press the [ SEEK, TRACK ] keys to automatically search for frequencies. Press the [FM/AM] key to change the mode • Shortly press the key (under 0.8 seconds): in order of FM1 Plays previous/next frequency •...
Page 18: Saving Radio Frequency
FM/AM Mode Saving Radio Frequency Scanning Radio Frequency Saving Automatically Press the | Auto Store| to automatically save receivable frequencies to Preset Press the | Scan |button to scan all buttons. A total of 18 frequencies with six radio frequencies. preset frequencies each for FM1/FM2/AM modes can be saved..
Page 19: Using The Menu Buttons
About HD Radio Using the Menu Buttons Text On/Text Off Press the | Menu| button to use the Preset Press the | Menu| button Press the Scan menu. | Text On| The Text feature is turned on/off. If the | Text On| button is displayed (Text off state), information will not be displayed even if there is information being transmitted from the broadcast station.
Page 20: Operating Hd Radio Mode
Operating HD Radio Mode Starting Mode Press the [FM/AM] key to turn on Radio Selecting a Frequency mode. HD 3 92.9 101.9 105.1 96.9 87.1 91.3 87.1 PS NAME Genre Song Title Song Title Song Title Artist Artist Artist Album Album Album Menu...
Page 21: Song-Tagging
Song-Tagging Song-tagging is a feature that song data of the currently playing broadcast. Upon connecting an iPod, song information is transferred to the iPod and can be downloaded through iTunes. Information • Up to 50 songs can be saved if an iPod device is not connected.
Page 22 XM Mode Basic Mode Screen XM 2 Name Description Category 1 Mode Display Displays currently operating mode Category Channel Channel 1-3 The desired frequency can saved as a preset and Channel Logo Preset selected. Title Title Ch 15 Setting Artist Displays currently operating features/options Artist Display...
Page 23 Selecting Presets Starting Mode Information • Within category mode, channels within the Press the [SAT] key to change the mode in current channel will be played. order of XM1 XM22 XM3. • Within channel mode, all channels in all categories will be played. •...
Page 24: Saving Xm Channels
Saving XM Channels Using the Menu Buttons Selecting through Channel/Category List Press the | Menu| button to use the Search, Press the |List| button Select the Preset Scan, and Scan menus desired category and channel XM 2 Category 1 Category Channel Channel 1-3 Channel...
Page 25 XM Mode Scan Preset Scan Press the | Scan |button to scan all Press the | Menu| button Press channels. | Preset Scan| Channels saved to the 6 preset buttons are each played for 5 seconds and the previous channel is restored. Starting from the current channel, channels with superior reception are scanned for 5 seconds and the previous...
Page 26: About Discs
About Discs Precautions upon handling discs After using a disc, put the disc back in its original case to Do not disassemble the device. Contact a designated prevent disc scratches. service center in case of malfunction. (Complete after service assistance will not be provided if the user Do not use abnormally shaped discs (8cm, heart-shaped, disassembles the device.) octagon-shaped) as such discs could lead to malfunctions.
Page 27 Disc Format Supported disc formats Disc/Content format compatibility Disc Disc Format Device Support By Format according to Disc Type This device supports the following disc Type formats. Disc Disc Format Device Support 3CD-DA Type Disc Type LPCM MPEG4 AAC DTS-CD MEPG1, Disc Disc Format...
Page 28 About Discs Ordinary Disc Compatibility CD-R/RW Compatibility This device has been designed/ • This device supports CD-R, CD-RW, manufactured to be compatible with software and MP3 discs burned in Audio CD formats. bearing the following logo marks. • The recording of CD-R and CD-RW discs with this device is not supported.
Page 29 Cautions upon writing CDs Before playing a MP3 Disc • This device supports WMA audio files using 20kbps ~ 320kbps(CBR), VBR. • When a multi-session disc is being • Variable bit rate files may operate, but recorded, make sure to close the session the play time information may not be Supported MP3 File Specification before recording.
Page 30 About Discs Detailed Specification MP3 File Structure Recognition occurs through the same folder structure used within the disc. • Maximum directory layers: 8 layers • Maximum folder length: 64 bytes, file name length: 64 bytes • Supported characters for folder name/ file name: Alphanumeric characters, Korean standard character set 2350 characters, Simplified Chinese 4888...
Page 31 CD Mode Basic Mode Screen Name Description Mode Displays currently operating mode Track Index Shows the current track/total tracks Repeat/ From Repeat/Shuffle/Scan, displays the currently operating Shuffle/ Scan function Play Time Displays the current play time Track Track number of current song Displays Repeat, Shuffle, Scan, and Info On (Info Off) Menu menus...
Page 32 Starting Mode Fast-forwarding or Rewinding CD Tracks Information • CD mode will automatically start once a CD is inserted. Press the [MEDIA] key Press |CD| While Playing Press and hold the [ SEEK TRACK ] key (over 0.8 Playing a CD seconds) This will rewind or fast-forward the track.
Page 33: Searching Cd Tracks
CD Mode Using the Menu Buttons Searching CD Tracks Shuffle Press the | Menu| button Press Press the [ TUNE ] key Search tracks | Shuffle| Once the desired track name is displayed, Press the | Menu| button to set the repeat, press the [ENTER] key shuffle, scan and Info On/Info Off menus.
Page 34 Info On/Info Off Press the | Menu| button Press the | Info on| The amount of information displayed on the screen can be selected. The title, artist, and album info are additionally displayed and the button will automatically change to | Info Off|.
Page 35 MP3 CD Mode Basic Mode Screen Name Description Mode Displays currently operating mode File Index Shows the current MP3 file/total number of MP3 files From Repeat All/Repeat One Song/Repeat Repeat/ Shuffle/ Folder/Shuffle Folder/Shuffle All/Folder Scan/Scan All, Normal Play displays the currently operating function Play Time Displays the current play time Folder Time...
Page 36: List Menu Screen
List Menu Screen Name Description Folder Name Folder name of current list Current Song Shows current file name highlighted Back button Converts to basic mode screen Previous list Moves to the previous list Next list Moves to the next list List page Shows current file list page/total number of pages List Focus...
Page 37: Selecting Mp3 Files
MP3 CD Mode Starting Mode Selecting MP3 files Information • MP3 mode automatically starts when an MP3 disc is inserted. • If there are numerous songs and folders Press the [MEDIA] key Press |MP3| Selecting from the Mode Screen within the disc, reading time could take more •...
Page 38 Using Menus within List Searching MP3 Files Using the Menu Buttons Screen Press the [ TUNE ] key Search files Press the | List| button Select the file Press the | Menu| button to set the copy, Once the desired file name is displayed, from the list repeat, shuffle, scan, and Info On/Off press the [ENTER] key...
Page 39 MP3 CD Mode Using Menus within List Screen Repeat Scan Moving between Lists Press the | Menu| button Press | Scan| Press the | Menu| button Press | Repeat| Each time the button is pressed, the option is changed from Folder Scan Scan All Press | List| button Press the | |,| |...
Page 40: Moving Between Folders
Moving between folders If five (5) or more files or folders exist the Information same folder, in the list will be displayed • If there are no more parent folders, both Press the | | button Select folder across two or more pages. |Home|,| | buttons will be disabled.
Page 41: Usb Mode
USB Mode About USB Some USB devices may not be supported due to Before playing a USB MP3 compatibility issues. Connect the USB device after turning on the engine. The USB Avoid contact between the USB connector with bodily device may become damaged if it is already connected when parts/foreign objects..
Page 42 When using mass storage USB devices with separate logical USB memory sticks used by connecting an Adaptor (SD drives, only files saved to the root drive can be played. Type or CF Type) may not be properly recognized. When application programs are installed to specific USBs, files may not properly play.
Page 43 USB Mode MP3 USB Information and Precautions Information • In cases that are not fixed bit rates, the play time may not be properly displayed. Name Description • If a problem occurs while playing or when playing an unsupported video format file, use an up-to-date encoding software MP3 File Specification: MPEG1 AUDIO LAYER 3 to change the format for use.
Page 44 Basic Mode Screen Name Description USB Music Mode Mode Displays currently operating mode File Index Shows the current file/total files within the USB From Repeat All/Repeat One Song/Repeat Folder/Shuffle Repeat / Folder/Shuffle All/Folder Scan/Scan All, displays the Shuffle /Scan currently operating function Play Time Displays the current play time/total play time Folder Name...
Page 45: Usb Image Mode
USB Image Mode Name Description Mode Displays currently operating mode Folder Name Displays folder name where image is located File Name Name of image file Shows the current image file/total image files within File Index the USB Displays Slideshow, Rotate Image, Adjust Image Menu Size, Save Image, and Info menus (Press the button again to hide the buttons)
Page 46: Starting Usb Music Mode
USB Mode Starting USB Music Mode Searching USB Music Files Information • Once a USB is connected, USB Music mode will operate automatically. Press the [MEDIA] key Press |USB Music| While Playing Press the |<|,|>| buttons or • If a previously played USB is reconnected, the [ SEEK TRACK ] key to play the then the song after the most recently played previous/next file...
Page 47: Info On/Info Off
Using the Menu Buttons Repeat Scan Press the | Menu| button Press | Scan| Press the | Menu| button Press Press the | Menu| button to set the Copy, | Repeat| Repeat, Shuffle, Scan, Info On (Info Off) Each time the button is pressed, the option is menus.
Page 48: Starting Usb Image Mode
USB Mode Starting USB Image Mode Using the Menu Buttons Searching USB Image Files While Playing Press the |<|,|>| buttons to view the previous/next image Press the [MEDIA] key Press |USB Image| Press the| Menu| button to set the Slideshow, Rotate Image, Adjust Image Size, Save Image and Info menus.
Page 49 Adjusting Image Size Saving Image Image slideshow intervals can be set at |5sec|, |10sec|, |20sec|, |30sec| intervals Press the | Menu| button Press | Save Image| Press the | Menu| button Press Rotating Image | Adjusting Image Size| Press |Done| Information •...
Page 50: Ipod Mode
iPod Mode Using iPod Devices iPod is a registered trademark of Apple Inc. To listen to the iPod sound, re-connect the USB cable or exit then re-enter iPod mode. iPod mode will not operate if the connected iPod cannot be recognized due to operation of unsupported versions that do In order to use the iPod while operating the keys, you must not support related protocols, iPod abnormalities, or iPod...
Page 51: Supported Ipod Devices
Supported iPod devices Some iPod versions may not sync with the system. then the system may not properly restore the previously operated mode. (For iPads, battery charging is not supported.) • Operation is supported and Apple Inc. certified: • Operation is supported but uncertified: Applications that are not exclusively used as iPod Applications within iPhone/iPod Touch devices are not Device/Gener...
Page 52 iPod Mode Basic Mode Screen Name Description Mode Displays currently operating mode File Index Shows the current file/total files within the iPod From Repeat Once/Shuffle Category/Shuffle Repeat / Random, Shuffle displays the currently operating function Play Time Displays the current play time/total play time Title Displays name of current title Artist Info...
Page 53: Starting Mode
Starting Mode Searching iPod Information • Once an iPod is connected, iPod mode Press the | List| button to display the will operate automatically. initial iPod list screen. Press the [MEDIA] key Press | iPod| Notice • Some iPods with unsupported communication protocols may not properly operate in the Navigation system.
Page 54 iPod Mode Searching iPod Files Information • If the search mode is accessed while playing a song, the most recently searched Press the [ TUNE ] key Search files step is displayed. Once the desired file name is displayed, • Search steps upon initial connection may press the [ENTER] key differ depending on the type of iPod device.
Page 55 Using the Menu Buttons Shuffle Press the| Menu| button Press | Shuffle| Press the | Menu| button to set the Repeat, Shuffle, and Info On (Info Off) Information menus. • Each time the | Shuffle| button is pressed, the option is changed from Shuffle Category Shuffle Album Off.
Page 56: Aux Mode
AUX Mode Starting Mode Connecting an External Device Information • If an external device connector is connected with the AUX terminal, then AUX mode will Press the [MEDIA] key Press | AUX| automatically operate. Once the connector is disconnected, the previous mode will be restored.
Page 57: Bluetooth® Audio Mode
Bluetooth® Audio Mode Basic Mode Screen Name Description Mode Displays currently playing mode Phone Name Displays name of connected phone Title Name of current song Artist Info Name of current artist Play Plays Bluetooth® Audio Pause Pauses Bluetooth® audio Connections Displays the Connections screen.
Page 58: Using Bluetooth® Audio
Bluetooth® Audio Mode Using Bluetooth® Audio Starting Mode Playing Bluetooth® Audio Press the [MEDIA] Key Press Bluetooth® Audio Mode can be used | Bluetooth Audio| only when a Bluetooth® phone has been connected. While Bluetooth® Audio is playing, if the Bluetooth®...
Page 59 Bluetooth® device after converting to streaming audio mode. The Streaming audio feature may not be supported in some mobile phones. For more information on mobile phone compatibility, visit the Hyundai Motor website (http://www.hyundaiusa.com). (Confidential) / / 10.230.25.192 / 2012-04-02 08:53 /...
Page 60 My Music Mode Basic Mode Screen Name Description Mode Displays currently operating mode File Index Shows the current file/total files within the iPod From Repeat Once/Shuffle Category/Shuffle Random, Repeat/Shuffle / Scan displays the currently operating function Play Time Displays the current play time/total play time File Displays the name of the current file Displays Repeat, Shuffle, Scan and Info On (Info Off)
Page 61 Starting Mode Playing My Music Selecting My Music Press the [MEDIA] Key Press |My Music| While Playing Press the |<|,|>| buttons or the [ SEEK TRACK ] key to play the previous/next file • Pressing and holding the [ SEEK TRACK ] keys (over 0.8 seconds) will rewind or fast-forward the current file.
Page 62: My Music Mode
My Music Mode Using the Menu Buttons Shuffle Info On/ Info Off Press the | Menu| button Press Press the | Menu| button to set the Repeat, | Shuffle| Press the | Menu| button Press Shuffle, Scan, Info On (Info Off) menus. | Info On| When turned on, files are played in random The screen display can be set differently...
Page 63: Moving Between Lists
Using Menus within List Screen Returning to current location Deleting Files While searching files within other folders, Press the | List| button Select the files to press the |Now Playing| button to return to delete Press | Delete Items| Moving between Lists the currently playing file screen.
Page 64 Memo (Confidential) / / 10.230.25.192 / 2012-04-02 08:53 /...
Page 65 Navigation • Before Use • Starting Navigation • Using the Navigation • Map Landmarks and Logos (Confidential) / / 10.230.25.192 / 2012-04-02 08:55 /...
Page 66: Before Use
Before Use Precautions for safe driving Please observe and comply with local traffic rules and regulations. The position of the vehicle within the navigation may differ Some features cannot be operated while driving for your from your actual location depending on various reasons, safety.
Page 67: Operating The Navigation
Operating the Navigation The navigation can be operated via touch. Touch the corresponding button on the screen to operate. If the button does not respond, take your finger off the screen and try again. When a button function is operating, the color of the selected button will be displayed differently.
Page 68: About The Map
Before Use About the Map Actual Distance About Map Icons Level mi/ft km / m Some roads, site names and facility Icons displayed on the map may differ 150ft information may have changed after map from actual conditions. Multiple icons 300ft 100 m data update and may differ with actual...
Page 69: About Gps
About Voice Recognition About GPS Example of voice guidance when arriving at the destination In front of the destination : During destination guidance, voice GPS (Global Position System) : guidance will be provided when reaching You are near you GPS is a system developed and operated an intersection or you are nearby the destination.
Page 70: Starting Navigation
Starting Navigation Map Screen Name Description Used to set split map and shows map display mode Car Direction GPS status Map Scale Shows current map scale Function/ Info Window Shows map function buttons or current position info Current Position Shows current road name and destination name in 5 Info Window second intervals Switches route guidance mode between preliminary...
Page 71: Initial Screen
Information Initial Screen Current Position • When riding in a new car or after replacing the battery terminal, the car position mark may at first appear at a different location. • Even if the car position mark on the map is different, map matching and GPS coordinates are utilized to automatically update the current position.
Page 72: Map Display Settings
Starting Navigation Information Map Display Settings Name Description • The Heading-Up/North-Up, 2D/3D, and map scale adjustments can be used when using Adjust Map Use the|+| / |-| buttons Split Screen map. Press the [MAP] key Press the | Scale to display the scale bar Shows map scales in Administrati categories of detail...
Page 73: Adjusting Navigation Volume
Map Menu Adjusting Navigation Volume POI Display Press the |>| button Press the |Menu| Press the |>| button Press the | Press the |>| button Press the |POI| Adjust volume button Features frequently used within the map Press the |>| button and then the | When POI menus are displayed, pressing screen, such as |Set as Destination|, button.
Page 74: Editing Poi Icons
Starting Navigation Editing POI Icons Searching POIs Press the Search by local |POI button| Press the |Edit POI Icon| button Press the |POI| Press |Done| Press the search criteria (Near current position, Near scroll mark, Near destination) Press the |Edit POI Icon| button to select the desired facility from the various facility types.
Page 75: Adding A My Place
Adding a My Place Name Description Within the ‘Search by Near Press the | | button Press the POI’ menu, searches Current facilities based on the desired group Position current vehicle position Within the ‘Search by Near Scroll POI’ menu, searches Mark facilities based on the current scrolled position...
Page 76: Using The Navigation
Using the Navigation Destination Search Press the [DEST] key to display the Destination Search menu Name Description screen. Used to search for neighboring POIs near current (Point of position/near scroll position/near destination/near Interest) city center Previous Used for route guidance to recently set destinations Destination Previous Used for route guidance to recently searched...
Page 77: Quick Menu
Quick Menu Name Description Quick Menu Display/hide Quick Menus Menus added to the Quick Menu Bar Quick Menu (possible to set up to 6 menus) Add/Delete Quick Edit Menus Current Quick Shows list of current Menus Quick Menus Add or remove Quick Add/Remove Menus List of categories that...
Page 78 Previous Destination, Previous Press the [DEST] Key Press |Previous Name Description Searches, Previous Start Point Start Point| Near Searches POIs based on the Current Press the [DEST] Key Press |Previous current vehicle position Position Destination| Near Scroll Searches POIs based on the Mark current map scroll position Searches POIs nearby the...
Page 79: Intersection Search
Using the Navigation Address My Places Intersection Search Press the [DEST] key Press |Address| This search feature is used to search destinations by selecting previously saved My Places to set as destinations. My Places This search feature is used to search can be placed in groups, and group names destinations by addresses through state can be edited within Setup.
Page 80 Displays list of where the cursor is Hospital Hospitals closest from Add Waypoint positioned as a the current position waypoint Displays list of Hyundai View Displays information for Motor Dealerships Dealership Destination the set destination closest from the current position...
Page 81: Phone Number Search
Phone Number Search Setting a Destination [Press the [DEST Key] Search for the Destination Press |Set as Destination| (Alternative Route) This search feature is used to search the locations of POIs by entering the phone number of the desired POI destination. •...
Page 82: Route Calculation
Using the Navigation Route Calculation • Once you have set a destination, calculate the route. The route overview and route • Press the |Add Waypoint| button to option menus will be displayed add a waypoint destination. • After checking the Route Overview, press •...
Page 83: Add Waypoint
Add Waypoint Route Recalculation • Within the Route Overview screen, press the |Demo| button. • During Demo, press the [MAP] key to end the demo and display the current map position. If you start driving while viewing the route demo, demo will end and route guidance will start Information •...
Page 84: Cancel Route
Using the Navigation Information For more information on Fastest, Shortest, and other route calculation options, refer to the route calculation section. Cancel Route In the Map menu screen, press the |Cancel Route| button. Information You can cancel the route by pressing the |Cancel Route| button that is displayed after pressing the |Menu| button.
Page 85: Route Guidance
Route Guidance Intersection Zoom Mode Information • Within all guidance mode screens, pressing the button at the bottom right side of the screen will change the route guidance mode.. • Each time the button is pressed, the guidance mode will change in order of preliminary guidance turn list motorway guidance...
Page 86 Using the Navigation Motorway Mode Turn List Mode Name Description Guidance for all POIs View All on the Motorway Shows List of turn points and other Summary directional route guidance while driving within motor ways Guidance for only the Rest Area rest areas on the motorway Upon entering a motorway during route...
Page 87: Route Menu
Route Menu Pres the |ROUTE| key to use, edit, or optimize various route Name Description options. Cancel Cancels the currently set route Route Route Shows the route overview to the set destination Overview Route Info Shows detailed info for the current route Route Route calculation features with various route Option...
Page 88: Route Overview
Using the Navigation Cancel Route Route Info Within the Route Overview screen, press the Alternative Route button to display Press the [ROUTE] key and then press Press the [ROUTE] Key Press |Route other potential routes to the set destination. the | Cancel Route| button to cancel Info| From the alternative route options,...
Page 89: Route Option
Route Option Detour Name Description Press the [ROUTE] Key Press | Route Press the [ROUTE] Key Press | Detour| Optimal route as Option| Set and press |Done| determined by the system Recommended upon consideration of various route conditions The shortest distance Shortest from start point to the destination...
Page 90 Using the Navigation Avoid Streets Edit Route Avoid Area Press the [ROUTE] Key Press | Avoid Press the [ROUTE] Key Press | Edit Press the ROUTE Key Press Streets| Select the streets you want to Route| Set and press |Done| | Avoid Area| |Done| avoid and press |Done|...
Page 91 Map Landmarks and Logos 2D Landmarks These are landmark and logo icons that display facilities within 2D map mode. The size of the symbol may be displayed differently according to the map scale. Symbols may change without prior notice during map updates. Symbols shown within the manual represent a portion of all symbols and should only be used as a reference.
Page 92 Map Landmarks and Logos 3D Landmarks These are landmark and logo icons that display facilities within 3D map mode. The size of the symbol may be displayed differently according to the map scale. Symbols may change without prior notice during map updates. Symbols shown within the manual represent a portion of all symbols and should only be used as a reference.
Page 93 Bluetooth® Handsfree • Before Use • Basic Mode Screen • Using Bluetooth...
Page 94: Before Use
Bluetooth® Handsfree refers to a device which allows the user to conveniently make phone calls with Bluetooth® mobile phones through the Navigation system. The Bluetooth handsfree feature may not be supported in some mobile phones. For more information on mobile phone compatibility, visit the Hyundai Motor website (http://www.hyundaiusa.com).
Page 95 Cautions upon connecting Bluetooth® phone Before connecting the head unit with the mobile phone, If the Bluetooth® audio does not play, go to [Setup] check to see that the mobile phone supports Bluetooth® | Bluetooth| | Streaming Audio Setting|. If the feature features.
Page 96: Basic Mode Screen
Basic Mode Screen When no phones have been paired Press the [ ] key on the steering remote controller or press the [PHONE] Press |Yes| Information From the Bluetooth® device, search for • Press the |Help| button within the pop-up to the car name and pair the device.
Page 97: When A Phone Is Already Paired
Basic Mode Screen When a phone is already paired Name Description Help section related to pairing and Help connecting/disconnecting Press the [ ] key on the steering remote Bluetooth® devices and controller or the [PHONE] key Press |Yes| Handsfree phone features Select the device from the device list Pair a new Bluetooth®...
Page 98: When There Is A Connected Device
When there is a connected device Press the | | key on the steering remote controller or the [PHONE] key on the head unit to display the following screen Name Description 9 10 Info Display Displays name of currently connected device Window If no number has been entered, switches to call Send...
Page 99: Using Bluetooth
Using Bluetooth® During a call Name Description Info Displays other party’s name/number. If there is a Display call waiting, displays call waiting information Window If there is a call waiting, switches the current call Switch and connects the waiting call Ends call Dial Pad Used to enter phone number...
Page 100: Making/Answering Calls
Making/Answering Calls Making a call from Speed Dial If you press the | Send | button without entering a number, the Call History Enter the 1 or 2 digit speed dial number screen is displayed with the Dial Pad Press and hold the Press and hold the dial pad |0 +| (over Calling by dialing a number last number...
Page 101 Using Bluetooth® Calling through Redial Making a call from Call history Press the hold (over 0.8 seconds) the Press the | Send | button or the [ ] Key on | Send| button or the [ ] key on the the steering remote controller Select the steering remote controller...
Page 102 Rejecting a call Answering a call Information • When the incoming call pop-up is displayed, Incoming call notice Press the Incoming call notice Press the |Reject| most functions within audio and SETUP mode |Accept| button or the | | key on the button or the | | key on the steering remote will not operate.
Page 103: Operating Menus During A Call
Using Bluetooth® Operating Menus during a Call Switching Call to the Handsfree During call on mobile phone Press the | Private| button or press and hold the [ ] Switching Call to the Bluetooth® phone key (over 0.8 seconds) on the steering remote controller.
Page 104 Ending a call Switching to Call Waiting If there is waiting call, press the [ ] key on the steering remote controller (under 0.8 While on a call Press the | End| button or If another person calls while you are already seconds) or press the | Switch| button on the [ ] Key on the steering remote controller.
Page 105 Using Bluetooth® Setting Mic volume Adjusting the Ring/Call Volume Information • The volume heard by the other party may While on a call Select |Outgoing Vol.| While on a call Use the VOL knob on differ depending on the mobile phone. If call Set Outgoing Volume Press |OK| the head unit or the [VOL+], [VOL-] keys...
Page 106 • The download feature may not be supported in some mobile phones. Check to see that the Bluetooth® device supports the download feature. • For more information on mobile phone compatibility, visit the Hyundai Motor website (http://www.hyundaiusa.com).
Page 107: Mobile Contacts Screen Configuration
Using Bluetooth® Mobile Contacts Screen Configuration Name Description Search car contacts and mobile phone contacts Search (Search by name or number) Download Download contacts from Bluetooth® device Bluetooth® Device Name of connected Bluetooth® device Name Displays total list pages and current list page List page (List page jump upon selecting scroll area) Download...
Page 108 Downloading Mobile Phone Contacts Checking Mobile Contacts Details Press the |Download| button from the Select the desired phone number from the Contacts screen Press |Yes| mobile contacts list to check details about the number. Information • Upon downloading mobile phone contacts, the previous corresponding data is deleted.
Page 109 Using Bluetooth® Adding as a Favorite Select number from the Contacts screen Within the details screen, press |Add as Favorite| Saved Favorites can be viewed by pressing the | Favorites| button in the Phone screen. Information • Up to 8 Favorites can be added. •...
Page 110 Favorites Selecting/Deleting Favorites Information • Favorites can be added through Phone In Favorites screen Press |Delete Items| | Contacts| Select contact |Add as Select items you want to delete and press Calling Favorites Favorite|. |Delete| Press |Yes| • Up to 8 Favorites can be added and Favorites In Phone screen Press | Favorites| can be used only when a Bluetooth device has...
Page 111 Using Bluetooth® Search by Name Searching by Number Searching Contacts In Phone screen Press |Search| Press the | Search by Name button| Press the | Search by Number| button Enter name and press |Search| Enter number and press |Search| Information Information •...
Page 112: Call History Screen Configuration
Call History Call History Screen Configuration Entering Call History Screen Within the Phone screen, press the | Send| button or the [ ] key on the steering remote controller. Information The call history may not be saved in the call history list in some mobile phones.
Page 113 • The download feature may not be supported in some mobile phones. Check to see that the Bluetooth® device supports the download feature. • For more information on mobile phone compatibility, visit the Hyundai Motor website Name Description (http://www.hyundaiusa.com). Download call histories from...
Page 114: Setting Bluetooth® Connection
Setting Bluetooth® Connection Connections Menu Connecting a Device |Connections| Press the | Connections| button on the Phone screen. Function Description Displays Bluetooth® Help Help screen Pairs a new Bluetooth® Add New device Connect/ Connects/disconnects Disconnect a Bluetooth® device Deletes a paired Delete Bluetooth®...
Page 115: Pairing A New Device
Using Bluetooth® Pairing a New Device • When a Bluetooth® device is being connected, the connection process cannot be canceled. • Only Bluetooth® Handsfree and Bluetooth® For more information on pairing, refer to audio related features will operate within this the ‘When no phones have been paired’...
Page 116 Disconnecting a Device Select the device you wish to disconnect Press |Disconnect| Press |Yes| A device cannot be deleted if it is connected. Deleting a Device To delete a paired device, first disconnect the Bluetooth® connection. Select the device you want to delete Press |Delete All| to delete all paired Press |Delete| Press |Yes|...
Page 117 Using Bluetooth® Setting Auto Connection Name Description Press the |Auto Connection| button Select Disable Auto Disables auto connection Connection the desired option Set and press |Done| Previously Auto connection with the Connected previously connected Phone Bluetooth® phone Automatically connects to User Selected a user selected Phone...
Page 118 Voice Recognition • Starting Voice Recognition • Voice Command Lists...
Page 119: Using Voice Recognition
Using Voice Recognition Starting Voice Recognition Once voice recognition starts, the voice Information command entry window and the six • To change the Normal/Expert setting, press representative commands are displayed. Starting Voice Recognition the [SETUP] key and enter the Voice If voice recognition is in [Normal Mode], Recognition settings screen.
Page 120: Ending Voice Recognition
Using Voice Recognition Adjusting Voice Recognition Ending Voice Recognition Using Voice Recognition Volume While Voice Recognition is operating Press the [ VR] key on the steering remote While Voice Recognition is operating Press and hold the [ VR] key on the controller.
Page 121 Using Voice Recognition Illustration on Using Voice Recognition (When Home is set as the destination) Press the [ VR] key (under 0.8 seconds). The system is await your command and display a list of accessible commands on the screen. Destination Please say a command Beep- Please say a command...
Page 122: Voice Command List
Voice Command List Voice Command List Voice commands within this system are categorized into “Common Commands” and “Mode Commands”. • Common Commands ( ) : commands that can be used in all situations. • Mode Commands ( ) : commands that can be used in specific multimedia/navigation/Bluetooth mode states.
Page 123: Help Command List
Help Command List Command Operation Help Displays the mail Help screen Destination Help Displays the Destination related command list Map Help Displays the Map related command list Radio Help Displays the FM/AM radio related command list XM Help Displays the XM radio related command list Disc Help Displays the DISC mode related command list for the disc inserted in the CD Player iPod Help...
Page 124: Audio System Command List
Audio System Command List FM/AM Radio Command Operation Radio Plays the most recent frequency for the most recently operated band (Radio) AM Plays the most recent frequency for the corresponding band Plays the most recent frequency for the corresponding band. In the case of FM, the most recent frequency within the most (Radio) FM recently played FM1 or FM2 band is Played FM1/FM2...
Page 125 XM Radio Command Operation Plays the last channel within the last band from XM1, XM2, and XM3 XM1/ XM2/ XM3 Plays the most recent channel for the corresponding Band Plays the desired XM band channel XM Channel <1~255> (ex : XM channel “Eleven”) XM1 Preset <1~6>...
Page 126 CD(Audio Type) Command Operation If the DISC inserted in the CD Player is either a CD or MP3 DISC, then the CD or MP3 will be played CD Track <1~99> If the DISC inserted in the CD Player is a CD, then CD Mode will start and plays the desired track Play Plays the currently paused song Pause...
Page 127 CD(MP3 Type) Command Operation If the DISC inserted in the CD Player is either a CD or MP3 DISC, then the CD or MP3 will be played Play Plays the currently paused song Pause Pauses the current song Next File Plays the next track Previous File Plays the previous track...
Page 128: Usb Music
USB Music Command Operation If the USB has been connected to the device, plays the MP3 or Image files within the USB USB Music If the USB has been connected to the device, plays the MP3 files within the USB Play Plays the currently paused song Pause...
Page 129: Usb Image
USB Image Command Operation If the DISC inserted in the CD plays is either a CD or MP3 DISC, then the CD or MP3 will be played USB Image If the USB has been connected to the device, plays the MP3 files within the USB Next File Displays the next image file Previous File...
Page 130 My Music Command Operation My Music Plays the songs within the My Music Play Plays the currently paused song Pause Pauses the current song Next File Plays the next file Previous File Plays the previous file Repeat Repeats the current file Repeat Off Cancels repeat play to play files in sequential order Shuffle On...
Page 131: Phone Command List
Others Command Operation Audio On Turns on the Audio/Video Audio Off Turns off the Audio/Video Bluetooth Audio Plays Bluetooth Audio Auxiliary Plays the connected auxiliary device Blue Link Displays the Blue Link mode screen Phone Command List Command Operation Call Name Makes the call to the name Call <Name>...
Page 132 Navigation Command List Command Operation Find Address Sets the destination through address search for route guidance Previous Destination Sets one of the previous destination as the current destination Previous Searches Sets one of the previous searches as the current destination Find Nearest Sets a POI...
Page 133 Command Operation Map Current Location Displays current position of the vehicle. Voice Guidance On Turns the Voice Guidance On Voice Guidance Off Turns the Voice Guidance Off Voice Guidance Lauder Increases Voice Guidance volume by 1 level Voice Guidance Softer Decrease Voice Guidance volume by 1 level Repeat...
Page 134 Command Operation XM Traffic Displays XM Traffic information on the screen Auto Zoom On Turns the Auto Zoom feature on Auto Zoom Off Turns the Auto Zoom feature off Auto Mode Converts the map display is between daylight/night modes automatically Daylight Mode Converts the map display into daylight mode Night Mode...
Page 135: Poi Category List
Check Cashing Service Physician Car Wash Gift Shop Money Transfer Social Service Gas Station Grocery Store Community Tailor & Alteration Hyundai Dealership Hardware Store City Hall Tax Service Motorcycle Dealership Home Specialty Store Civic Center Parking Music Store Convention, Center...
Page 136 Information • XM Data • Blue Link • GPS Information • Help...
Page 137: About Gps
XM Data About GPS About XM Data Service Weather Data Service Press the [INFO] key Press |XM Data| The XM Data Service is a paid membership Press the [INFO] key Press |XM Data| Satellite radio service which provides users Press [Weather : More] with traffic, stock, sports, and weather information.
Page 138 XM Data Forecast Warnings and Advisories Provides current weather information and This service provides weather information, This service provides weather warnings and weather information for the coming next such as Cloud, Fog, Rain, Snow, and Road advisories, such as Tornado, Storm, Flood, three days for your region.
Page 139 XM Data Traffic Data Service Traffic Stocks Service 2.Displays Road Traffic situations RTM (Road Traffic Message) is a feature which displays symbols of icons for each Press the [INFO] key Press |XM Data| XM Stock data Service is a service which type of road traffic condition, such as Press [Traffic : More] provides real-time updated information on...
Page 140 XM Data Stocks Stock Search My Favorites Stocks is a feature that shows the current Use the Stock Search menu to search for My Favorites shows list of stocks added by value and change of stocks. specific stocks. the user. For symbols which you are interested in, press the <Favorites>...
Page 141 XM Data When GPS info cannot be used My Teams You can save teams which you are interested in as part of <My teams> to easily The service provides real-time updated view related scores and schedules. information on scores and schedules for major sports, such as NFL, NBA, NCAA Football, NCAA basketball, NHL, MLB, NASCAR and more.
Page 142 Blue Link Blue Link Blue Link Blue Link Blue Link Auto Crash Notification Press the [INFO] key Press |Blue Link| ECO Driving , Blue Link System Blue Link [Downloade Blue Link d POI] [ECO Driving] [system Blue Link Info] [Gas Blue Link Station] Gas Station...
Page 143 Blue Link [SOS] . SOS Blue Blue Link Link...
Page 144 Blue Link Blue Link Blue Link Blue Link 1. Blue Link (www.myhyndai.com) Blue Link POI Blue Link Call [Blue Link POI] Blue Link 3.YES Blue Link Call...
Page 145 Blue Link Gas Station Information • Press the [INFO] key |Blue Link| Press the [INFO] key |Blue Link| [Downloaded POI] [Gas Station] Distance On Route • Gas Station Gas Station [View Map] [Call] [Delete]...
Page 146 Blue Link Restaurants Press the [INFO] key |Blue Link| Press the [INFO] key |Blue Link| [Restaurants ] [Location Sharing ] Blue Link POI Restaurants Location Sharing [Blue Link POI] Blue Link Restaurants Location Sharing Blue Link Call Blue Link...
Page 147: Eco-Driving
Blue Link Eco Driving Blue Link Press the [INFO] key |Blue Link| [Eco Driving] Eco Driving (Community) Average Fuel Economy Fuel Consumptio n last 2.5 Eco Reward Help...
Page 148: System Info
Blue Link Blue Link Eco Driving Press the [INFO] key |Blue Link| [System Info] System Info Model Blue Link Blue Link Version MEID NO. Blue Link Update Blue Link (USB)
Page 149: Gps Information
GPS Information Errors unavoidable due to About GPS When GPS info cannot be used system characteristics GPS info may not operate under the GPS (Global Position System) : • The navigation system uses GPS following conditions. GPS is a system developed and operated information, various sensors, road map •...
Page 150: Viewing Gps Info
Viewing GPS Info Press the [INFO] key Select | GPS Info| The GPS reception and vehicle speed information are displayed.
Page 151: Viewing Help
Help Viewing Help Press the [INFO] key Select | Help| Help sections on the Navigation and Bluetooth® features can be selected and viewed.
Page 152: Other Features
Other Features • Climate Mode • PGS...
Page 153: Operating Climate Mode
Climate Mode Operating Climate Mode Press the [CLIMATE] key to display the Climate status bar. Information • When operating the Multimedia or Navigation mode, press a Climate related key, such as [TEMP], [AUTO], [A/C] to display the Climate status bar at the top of screen.
Page 154 Basic Mode Screen Name Description Driver-side Displays the driver-side temperature temperature Displays whether the heating/cooling auto AUTO Display function is on/off A/C Display Displays whether the a/c is on/off Fan level Display Displays the current fan level Fan Direction Displays the set fan direction Display Enables the driver/passenger temperature to DUAL Display...
Page 155: Basic Operation
Climate Mode Basic Operation Controlling driver/passenger temperature independently Controlling driver/passenger Temperature simultaneously Press the [DUAL] key to turn the DUAL setting back on. Press the [DUAL] key to turn the DUAL setting off. When DUAL is disabled, the driver-side and passenger-side temperatures are controlled simultaneously.
Page 156: Setting Fan Direction
Setting Fan Direction Press the fan keys to change the fan direction. Information When DUAL has been enabled, the driver-side and passenger-side temperatures can be When setting the driver-side temperature controlled independently. with DUAL on, the DUAL button will turn OFF if the driver-side temperature is set to LOW or HIGH Information...
Page 157: Setting Fan Level
Climate Mode Setting Fan Level Press the [ |key to change the fan level. Information If the fan level is changed while in [AUTO] mode, AUTO mode will turn off.
Page 158: About Pgs (Parking Guide System)
PGS (Parking Guide System) About PGS (Parking Guide Operating sequence of the PGS System) 1. Position the ignition key in ACC or ON. • PGS System is a system which provides 2. Position the transmission lever to R. monitored parking guidance. •...
Page 159 Setup • Setup • Using Setup...
Page 160 Setup Basic Mode Screen Name Description Sound Sets sound related settings Display Sets display related settings HD Radio Sets HD Radio related settings Bluetooth® Sets Bluetooth® related settings Sets various settings found within Navigation Navigation mode Edit My Places Set/Edit My Places within Navigation Mode Traffic Sets Traffic Information related settings Voice...
Page 161: Starting Mode
Starting Mode Sound Information The Balance/Fader settings allows you to set Press the [SETUP] key Press | Sound| the sound position. For example, you can set the sound close to the driver-seat so that the volume is relatively lower in the passenger or rear seats.
Page 162: Using Setup
Using Setup Setting Volume Ratio Setting Beep Information • The rear seat speaker will maintain its audio Press the | Sound| button Press Press the | Sound| button Press volume regardless of which volume ratio is |Volume Ratio| Set and press |Done| | Beep| Set and press |Done| selected.
Page 163: Setting Illumination
Display HD Radio Setting Illumination Press the | Display| button Press Press the [SETUP] key Press |Illumination| Press the [SETUP] key Press | HD Radio| | Display| Adjusting Screen Press the | Display| button Press |Adjust Screen| Set and press |Done| These settings are used to set whether to Name Description...
Page 164 Using Setup Bluetooth® Auto Connection Settings Information Press the [SETUP] key Press • If you press the |Setting| button next to the Press | Bluetooth| button Press |Auto | Bluetooth| |User Selected Phone| and |Connect by Connections Settings| Set and press Priority| options, you can designate the phone |Done| you want to connect or set the phone priority.
Page 165: Contacts Download Setting
Using Setup Contacts Download Setting Streaming Audio Setting Press | Bluetooth| Press| Contacts Press | Bluetooth| Press| Streaming Download Setting| Set and press |Done| Audio Setting| |Done| Name Description Changes the passkey Change used to authenticate Passkey Bluetooth® Device Searches car Bluetooth® Device device information and You can select the contacts you wish to...
Page 166 Change Passkey Device Information Delete All Favorites Press | Bluetooth| Press| Advanced Press | Bluetooth| Press| Advanced Press | Bluetooth| Press| Advanced Settings| Press| Change Passkey| Settings| Press | Device Information| Settings| Press | Delete All Favorites| Set and press |Done| This feature is used to change the passkey This feature allows you to check device This feature allows you to delete all...
Page 167 Using Setup Navigation Delete All Call History Restore Factory Settings Press | Bluetooth| Press| Advanced Press | Bluetooth| Press | Advanced Settings| Press | Delete All Call History| Settings| Press | Restore Factory Press the [SETUP] key Press Settings| | Navigation| Main Press the | Navigation| button Press...
Page 168 Driving Speed Setting This menu is used to set general navigation The changed driving speed is used to options. calculate the estimated time until the Press the |Edit| button within the “Driving Speed Setting” menu to set the estimated destination or waypoint. Name Description driving speed for residential roads, main...
Page 169 Using Setup Route Indicator Line Display Route Search Press the | Edit| button within the |Route Press the | Navigation| button Press Press the | Navigation| button Press Indicator Line| menu to change the color |Display| Set and press |Done| |Route Search| Set and press |Done| of the route indicator line.
Page 170 Using Setup Speed Alert Guidance Guidance To change the |Speed Alert Guidance| Press the | Navigation| button Press the option, press the |Edit| button within the desired |Guidance| Set and press |Done| “Speed Alert Guidance” menu. Name Description Sets Alarm sound for speed alerts/ over Guidance speeding and speed...
Page 171 My Places Driver Alert Guidance Default To set the Driver Alert Guidance, option, press the |Edit| button within the “Driver Alert Press the | Navigation| button Press Press the [SETUP] key Press | Edit My Guidance” menu. |Default Set and press |Done| Places| My Places Press the | Edit My Places| button...
Page 172: Favorite Places
Using Setup Favorite Places From the My Places list, select the desired Name Description menu to either add, delete or edit My Places. Store Adds the current vehicle current position as a Favorite Press the | Edit My Places| button Press Position Place...
Page 173 Home, Office Information • If the Home and Office has not been set, Press the | Edit My Places| button Press these buttons will be displayed as disabled |Home| or |Office| within the Destination Search screen. Speed Alerts Press the | Edit My Places| button Press |Speed Alerts| Set and press |Done|...
Page 174: Traffic Setup
Using Setup Traffic Setup Voice Recognition Settings Press the [SETUP] key Press | Traffic Check information on XM Data Radio Setup | traffic data service Press the [SETUP] key Press | Voice activation and activation ID Recognition Set and press |Done| Display Sets whether to display Traffic and...
Page 175: Clock Setting
Clock Settings Picture Frame Information • When Daylight Savings Time is turned on, the Press the [SETUP] key Press | Clock| clock is moved back one hour. Press the [SETUP] key Press | Picture Frame| Set and Press |Done| Clock Setting View Press |Time| Set and press |Done|...
Page 176 Using Setup Language Keyboard Name Description Keyboard with characters arranged in order Press the [SETUP] key Press Press the | Language| Set and Press | Keyboard| Set and press |Done| |Done| Keyboard similar to the one QWERTY used within a computer Information •...
Page 177: System Update
Using Setup System Update Display Off Information • This product requires regular updates for Press the [SETUP] key Press software corrections, new functions and map Press the [SETUP] key Press | Display | System Update| Press |Update| updates. Updating may require up to 1 hour Off| |OK| depending on the data size.
Page 178 Appendix • Product Specification • Before thinking the product has malfunctioned • Before thinking there is a product defect • Troubleshooting • FAQ (Confidential) / / 10.230.25.192 / 2012-04-02 09:02 /...
Page 179: Product Specification
Appendix Product Specification Radio FM: 87.5MHz ~ 108.0MHz(Step: 100kHz) Channels DOLBY AM: 531kHz ~ 1602kHz(Step: 9kHz) Sensitivity FM: Under 10dBu /AM: Under 40dBu Manufactured under license from Dolby Laboratories. Dolby and double-D symbol are trademarks of Dolby Laboratories. Distortion Within 2% Speakers 2 ~ 8 Factor...
Page 180 KCC-CMM-HMO-AV310DMDG Operating Company Storage Hyundai Mobis Temperatur -20º ~ 70º ~ +80 Name Temperature Manufacturer/ Hyundai Mobis/Republic of Korea Country Dimensions 221.8mm(W) x 171mm(H) x 225mm(D) Weight 2.7 Kg Bluetooth Supported Frequency 2402 ~ 2480 MHz Bluetooth 2.1 + EDR...
Page 181 Appendix 0101 Afar 0625 Frisian 1222 Latvian 1912 Slovenian 0315 Corsican 0923 Hebrew 1518 Oriya 2012 Tagalog 0101 Abkhazian 0701 Irish 1307 Malagasy 1913 Samoan 0319 Czech 1009 Yiddish 1601 Punjabi 2014 Tswana 0106 Afrikaans 0704 Scots 1309 Maori 1914 Shona 0325 Welsh...
Page 182: Before Thinking There Is A Product Defect
Before thinking there is a product defect Correct route guidance may not occur due to search conditions or driving position. The current position as shown on the navigation may differ from The following occurrences are not malfunctions the actual position under the following conditions. •...
Page 183: Before Thinking The Product Has Malfunctioned
• If there is no disc or the corresponding 3. If the problems persist, contact your HYUNDAI dealer. screen is not displayed device is not connected, the mode operated prior to the most recent mode will operate.
Page 184: Troubleshooting
Troubleshooting Problem Possible Cause Countermeasure Problem Possible Cause Countermeasure • Replace with a suitable fuse. The image The brightness, saturation, • Properly adjust the brightness, • If the fuse is disconnected color/tone hue, and contrast levels saturation, hue, and contrast The fuse is disconnected again, please contact your quality is low...
Page 185 Appendix Problem Possible Cause Countermeasure Problem Possible Cause Countermeasure • USB memory is damaged. • Please use after formatting the • USB into FAT 12/16/32 format. • • Remove any foreign substances • USB memory has been • contaminated. on the contact surface of the USB •...
Page 186: About Pairing Mobile Phones
Appendix Information What is a Passkey? A passkey is the password used to authenticate the connection • While operating the device, if an abnormality occurs that cannot be between the head unit and mobile phone. The passkey only needs to corrected with the above described measures, press the [RESET] key be entered once when pairing the mobile phone for the first time.
Page 187 Appendix About Bluetooth® / Head unit use environment What is the distance in which wireless connection can be used? The wireless connection can be used within 15 yards. How many mobile phones can be paired? It is possible to pair up to five mobile phones. What does call quality sometimes worsen? Check the reception sensitivity of the mobile phone when call quality becomes worsened.
Page 188 Appendix • Product Specification • Before thinking the product has malfunctioned • Before thinking there is a product defect • Troubleshooting • FAQ (Confidential) / / 10.230.25.192 / 2012-04-02 09:02 /...
Page 189 Appendix Product Specification Radio FM: 87.5MHz ~ 108.0MHz(Step: 100kHz) Channels DOLBY AM: 531kHz ~ 1602kHz(Step: 9kHz) Sensitivity FM: Under 10dBu /AM: Under 40dBu Manufactured under license from Dolby Laboratories. Dolby and double-D symbol are trademarks of Dolby Laboratories. Distortion Within 2% Speakers 2 ~ 8 Factor...
Page 190 KCC-CMM-HMO-AV310DMDG Operating Company Storage Hyundai Mobis Temperatur -20º ~ 70º ~ +80 Name Temperature Manufacturer/ Hyundai Mobis/Republic of Korea Country Dimensions 221.8mm(W) x 171mm(H) x 225mm(D) Weight 2.7 Kg Bluetooth Supported Frequency 2402 ~ 2480 MHz Bluetooth 2.1 + EDR...
Page 191 Appendix 0101 Afar 0625 Frisian 1222 Latvian 1912 Slovenian 0315 Corsican 0923 Hebrew 1518 Oriya 2012 Tagalog 0101 Abkhazian 0701 Irish 1307 Malagasy 1913 Samoan 0319 Czech 1009 Yiddish 1601 Punjabi 2014 Tswana 0106 Afrikaans 0704 Scots 1309 Maori 1914 Shona 0325 Welsh...
Page 192 Before thinking there is a product defect Correct route guidance may not occur due to search conditions or driving position. The current position as shown on the navigation may differ from The following occurrences are not malfunctions the actual position under the following conditions. •...
Page 193 • If there is no disc or the corresponding 3. If the problems persist, contact your HYUNDAI dealer. screen is not displayed device is not connected, the mode operated prior to the most recent mode will operate.
Page 194 Troubleshooting Problem Possible Cause Countermeasure Problem Possible Cause Countermeasure • Replace with a suitable fuse. The image The brightness, saturation, • Properly adjust the brightness, • If the fuse is disconnected color/tone hue, and contrast levels saturation, hue, and contrast The fuse is disconnected again, please contact your quality is low...
Page 195 Appendix Problem Possible Cause Countermeasure Problem Possible Cause Countermeasure • USB memory is damaged. • Please use after formatting the • USB into FAT 12/16/32 format. • • Remove any foreign substances • USB memory has been • contaminated. on the contact surface of the USB •...
Page 196 Appendix Information What is a Passkey? A passkey is the password used to authenticate the connection • While operating the device, if an abnormality occurs that cannot be between the head unit and mobile phone. The passkey only needs to corrected with the above described measures, press the [RESET] key be entered once when pairing the mobile phone for the first time.
Page 197 Appendix About Bluetooth® / Head unit use environment What is the distance in which wireless connection can be used? The wireless connection can be used within 15 yards. How many mobile phones can be paired? It is possible to pair up to five mobile phones. What does call quality sometimes worsen? Check the reception sensitivity of the mobile phone when call quality becomes worsened.
Page 198 Setup • Setup • Using Setup...
Page 199 Setup Basic Mode Screen Name Description Sound Sets sound related settings Display Sets display related settings HD Radio Sets HD Radio related settings Bluetooth® Sets Bluetooth® related settings Sets various settings found within Navigation Navigation mode Edit My Places Set/Edit My Places within Navigation Mode Traffic Sets Traffic Information related settings Voice...
Page 200 Starting Mode Sound Information The Balance/Fader settings allows you to set Press the [SETUP] key Press | Sound| the sound position. For example, you can set the sound close to the driver-seat so that the volume is relatively lower in the passenger or rear seats.
Page 201: Using Setup
Using Setup Setting Volume Ratio Setting Beep Information • The rear seat speaker will maintain its audio Press the | Sound| button Press Press the | Sound| button Press volume regardless of which volume ratio is |Volume Ratio| Set and press |Done| | Beep| Set and press |Done| selected.
Page 202 Display HD Radio Setting Illumination Press the | Display| button Press Press the [SETUP] key Press |Illumination| Press the [SETUP] key Press | HD Radio| | Display| Adjusting Screen Press the | Display| button Press |Adjust Screen| Set and press |Done| These settings are used to set whether to Name Description...
Page 203 Using Setup Bluetooth® Auto Connection Settings Information Press the [SETUP] key Press • If you press the |Setting| button next to the Press | Bluetooth| button Press |Auto | Bluetooth| |User Selected Phone| and |Connect by Connections Settings| Set and press Priority| options, you can designate the phone |Done| you want to connect or set the phone priority.
Page 204 Using Setup Contacts Download Setting Streaming Audio Setting Press | Bluetooth| Press| Contacts Press | Bluetooth| Press| Streaming Download Setting| Set and press |Done| Audio Setting| |Done| Name Description Changes the passkey Change used to authenticate Passkey Bluetooth® Device Searches car Bluetooth® Device device information and You can select the contacts you wish to...
Page 205 Change Passkey Device Information Delete All Favorites Press | Bluetooth| Press| Advanced Press | Bluetooth| Press| Advanced Press | Bluetooth| Press| Advanced Settings| Press| Change Passkey| Settings| Press | Device Information| Settings| Press | Delete All Favorites| Set and press |Done| This feature is used to change the passkey This feature allows you to check device This feature allows you to delete all...
Page 206 Using Setup Navigation Delete All Call History Restore Factory Settings Press | Bluetooth| Press| Advanced Press | Bluetooth| Press | Advanced Settings| Press | Delete All Call History| Settings| Press | Restore Factory Press the [SETUP] key Press Settings| | Navigation| Main Press the | Navigation| button Press...
Page 207 Driving Speed Setting This menu is used to set general navigation The changed driving speed is used to options. calculate the estimated time until the Press the |Edit| button within the “Driving Speed Setting” menu to set the estimated destination or waypoint. Name Description driving speed for residential roads, main...
Page 208 Using Setup Route Indicator Line Display Route Search Press the | Edit| button within the |Route Press the | Navigation| button Press Press the | Navigation| button Press Indicator Line| menu to change the color |Display| Set and press |Done| |Route Search| Set and press |Done| of the route indicator line.
Page 209 Using Setup Speed Alert Guidance Guidance To change the |Speed Alert Guidance| Press the | Navigation| button Press the option, press the |Edit| button within the desired |Guidance| Set and press |Done| “Speed Alert Guidance” menu. Name Description Sets Alarm sound for speed alerts/ over Guidance speeding and speed...
Page 210 My Places Driver Alert Guidance Default To set the Driver Alert Guidance, option, press the |Edit| button within the “Driver Alert Press the | Navigation| button Press Press the [SETUP] key Press | Edit My Guidance” menu. |Default Set and press |Done| Places| My Places Press the | Edit My Places| button...
Page 211 Using Setup Favorite Places From the My Places list, select the desired Name Description menu to either add, delete or edit My Places. Store Adds the current vehicle current position as a Favorite Press the | Edit My Places| button Press Position Place...
Page 212 Home, Office Information • If the Home and Office has not been set, Press the | Edit My Places| button Press these buttons will be displayed as disabled |Home| or |Office| within the Destination Search screen. Speed Alerts Press the | Edit My Places| button Press |Speed Alerts| Set and press |Done|...
Page 213 Using Setup Traffic Setup Voice Recognition Settings Press the [SETUP] key Press | Traffic Check information on XM Data Radio Setup | traffic data service Press the [SETUP] key Press | Voice activation and activation ID Recognition Set and press |Done| Display Sets whether to display Traffic and...
Page 214 Clock Settings Picture Frame Information • When Daylight Savings Time is turned on, the Press the [SETUP] key Press | Clock| clock is moved back one hour. Press the [SETUP] key Press | Picture Frame| Set and Press |Done| Clock Setting View Press |Time| Set and press |Done|...
Page 215 Using Setup Language Keyboard Name Description Keyboard with characters arranged in order Press the [SETUP] key Press Press the | Language| Set and Press | Keyboard| Set and press |Done| |Done| Keyboard similar to the one QWERTY used within a computer Information •...
Page 216 Using Setup System Update Display Off Information • This product requires regular updates for Press the [SETUP] key Press software corrections, new functions and map Press the [SETUP] key Press | Display | System Update| Press |Update| updates. Updating may require up to 1 hour Off| |OK| depending on the data size.
Page 217 Other Features • Climate Mode • PGS...
Page 218 Climate Mode Operating Climate Mode Press the [CLIMATE] key to display the Climate status bar. Information • When operating the Multimedia or Navigation mode, press a Climate related key, such as [TEMP], [AUTO], [A/C] to display the Climate status bar at the top of screen.
Page 219 Basic Mode Screen Name Description Driver-side Displays the driver-side temperature temperature Displays whether the heating/cooling auto AUTO Display function is on/off A/C Display Displays whether the a/c is on/off Fan level Display Displays the current fan level Fan Direction Displays the set fan direction Display Enables the driver/passenger temperature to DUAL Display...
Page 220 Climate Mode Basic Operation Controlling driver/passenger temperature independently Controlling driver/passenger Temperature simultaneously Press the [DUAL] key to turn the DUAL setting back on. Press the [DUAL] key to turn the DUAL setting off. When DUAL is disabled, the driver-side and passenger-side temperatures are controlled simultaneously.
Page 221 Setting Fan Direction Press the fan keys to change the fan direction. Information When DUAL has been enabled, the driver-side and passenger-side temperatures can be When setting the driver-side temperature controlled independently. with DUAL on, the DUAL button will turn OFF if the driver-side temperature is set to LOW or HIGH Information...
Page 222 Climate Mode Setting Fan Level Press the [ |key to change the fan level. Information If the fan level is changed while in [AUTO] mode, AUTO mode will turn off.
Page 223 PGS (Parking Guide System) About PGS (Parking Guide Operating sequence of the PGS System) 1. Position the ignition key in ACC or ON. • PGS System is a system which provides 2. Position the transmission lever to R. monitored parking guidance. •...
Page 224 Information • XM Data • Blue Link • GPS Information • Help...
Page 225: About Gps
XM Data About GPS About XM Data Service Weather Data Service Press the [INFO] key Press |XM Data| The XM Data Service is a paid membership Press the [INFO] key Press |XM Data| Satellite radio service which provides users Press [Weather : More] with traffic, stock, sports, and weather information.
Page 226 XM Data Forecast Warnings and Advisories Provides current weather information and This service provides weather information, This service provides weather warnings and weather information for the coming next such as Cloud, Fog, Rain, Snow, and Road advisories, such as Tornado, Storm, Flood, three days for your region.
Page 227 XM Data Traffic Data Service Traffic Stocks Service 2.Displays Road Traffic situations RTM (Road Traffic Message) is a feature which displays symbols of icons for each Press the [INFO] key Press |XM Data| XM Stock data Service is a service which type of road traffic condition, such as Press [Traffic : More] provides real-time updated information on...
Page 228 XM Data Stocks Stock Search My Favorites Stocks is a feature that shows the current Use the Stock Search menu to search for My Favorites shows list of stocks added by value and change of stocks. specific stocks. the user. For symbols which you are interested in, press the <Favorites>...
Page 229 XM Data When GPS info cannot be used My Teams You can save teams which you are interested in as part of <My teams> to easily The service provides real-time updated view related scores and schedules. information on scores and schedules for major sports, such as NFL, NBA, NCAA Football, NCAA basketball, NHL, MLB, NASCAR and more.
Page 230 Blue Link Blue Link Blue Link Blue Link Blue Link Auto Crash Notification Press the [INFO] key Press |Blue Link| ECO Driving , Blue Link System Blue Link [Downloade Blue Link d POI] [ECO Driving] [system Blue Link Info] [Gas Blue Link Station] Gas Station...
Page 231 Blue Link [SOS] . SOS Blue Blue Link Link...
Page 232 Blue Link Blue Link Blue Link Blue Link 1. Blue Link (www.myhyndai.com) Blue Link POI Blue Link Call [Blue Link POI] Blue Link 3.YES Blue Link Call...
Page 233 Blue Link Gas Station Information • Press the [INFO] key |Blue Link| Press the [INFO] key |Blue Link| [Downloaded POI] [Gas Station] Distance On Route • Gas Station Gas Station [View Map] [Call] [Delete]...
Page 234 Blue Link Restaurants Press the [INFO] key |Blue Link| Press the [INFO] key |Blue Link| [Restaurants ] [Location Sharing ] Blue Link POI Restaurants Location Sharing [Blue Link POI] Blue Link Restaurants Location Sharing Blue Link Call Blue Link...
Page 235: Eco-Driving
Blue Link Eco Driving Blue Link Press the [INFO] key |Blue Link| [Eco Driving] Eco Driving (Community) Average Fuel Economy Fuel Consumptio n last 2.5 Eco Reward Help...
Page 236 Blue Link Blue Link Eco Driving Press the [INFO] key |Blue Link| [System Info] System Info Model Blue Link Blue Link Version MEID NO. Blue Link Update Blue Link (USB)
Page 237 GPS Information Errors unavoidable due to About GPS When GPS info cannot be used system characteristics GPS info may not operate under the GPS (Global Position System) : • The navigation system uses GPS following conditions. GPS is a system developed and operated information, various sensors, road map •...
Page 238 Viewing GPS Info Press the [INFO] key Select | GPS Info| The GPS reception and vehicle speed information are displayed.
Page 239 Help Viewing Help Press the [INFO] key Select | Help| Help sections on the Navigation and Bluetooth® features can be selected and viewed.
Page 240 Voice Recognition • Starting Voice Recognition • Voice Command Lists...
Page 241: Using Voice Recognition
Using Voice Recognition Starting Voice Recognition Once voice recognition starts, the voice Information command entry window and the six • To change the Normal/Expert setting, press representative commands are displayed. Starting Voice Recognition the [SETUP] key and enter the Voice If voice recognition is in [Normal Mode], Recognition settings screen.
Page 242 Using Voice Recognition Adjusting Voice Recognition Ending Voice Recognition Using Voice Recognition Volume While Voice Recognition is operating Press the [ VR] key on the steering remote While Voice Recognition is operating Press and hold the [ VR] key on the controller.
Page 243 Using Voice Recognition Illustration on Using Voice Recognition (When Home is set as the destination) Press the [ VR] key (under 0.8 seconds). The system is await your command and display a list of accessible commands on the screen. Destination Please say a command Beep- Please say a command...
Page 244 Voice Command List Voice Command List Voice commands within this system are categorized into “Common Commands” and “Mode Commands”. • Common Commands ( ) : commands that can be used in all situations. • Mode Commands ( ) : commands that can be used in specific multimedia/navigation/Bluetooth mode states.
Page 245 Help Command List Command Operation Help Displays the mail Help screen Destination Help Displays the Destination related command list Map Help Displays the Map related command list Radio Help Displays the FM/AM radio related command list XM Help Displays the XM radio related command list Disc Help Displays the DISC mode related command list for the disc inserted in the CD Player iPod Help...
Page 246 Audio System Command List FM/AM Radio Command Operation Radio Plays the most recent frequency for the most recently operated band (Radio) AM Plays the most recent frequency for the corresponding band Plays the most recent frequency for the corresponding band. In the case of FM, the most recent frequency within the most (Radio) FM recently played FM1 or FM2 band is Played FM1/FM2...
Page 247 XM Radio Command Operation Plays the last channel within the last band from XM1, XM2, and XM3 XM1/ XM2/ XM3 Plays the most recent channel for the corresponding Band Plays the desired XM band channel XM Channel <1~255> (ex : XM channel “Eleven”) XM1 Preset <1~6>...
Page 248 CD(Audio Type) Command Operation If the DISC inserted in the CD Player is either a CD or MP3 DISC, then the CD or MP3 will be played CD Track <1~99> If the DISC inserted in the CD Player is a CD, then CD Mode will start and plays the desired track Play Plays the currently paused song Pause...
Page 249 CD(MP3 Type) Command Operation If the DISC inserted in the CD Player is either a CD or MP3 DISC, then the CD or MP3 will be played Play Plays the currently paused song Pause Pauses the current song Next File Plays the next track Previous File Plays the previous track...
Page 250 USB Music Command Operation If the USB has been connected to the device, plays the MP3 or Image files within the USB USB Music If the USB has been connected to the device, plays the MP3 files within the USB Play Plays the currently paused song Pause...
Page 251 USB Image Command Operation If the DISC inserted in the CD plays is either a CD or MP3 DISC, then the CD or MP3 will be played USB Image If the USB has been connected to the device, plays the MP3 files within the USB Next File Displays the next image file Previous File...
Page 252 My Music Command Operation My Music Plays the songs within the My Music Play Plays the currently paused song Pause Pauses the current song Next File Plays the next file Previous File Plays the previous file Repeat Repeats the current file Repeat Off Cancels repeat play to play files in sequential order Shuffle On...
Page 253 Others Command Operation Audio On Turns on the Audio/Video Audio Off Turns off the Audio/Video Bluetooth Audio Plays Bluetooth Audio Auxiliary Plays the connected auxiliary device Blue Link Displays the Blue Link mode screen Phone Command List Command Operation Call Name Makes the call to the name Call <Name>...
Page 254 Navigation Command List Command Operation Find Address Sets the destination through address search for route guidance Previous Destination Sets one of the previous destination as the current destination Previous Searches Sets one of the previous searches as the current destination Find Nearest Sets a POI...
Page 255 Command Operation Map Current Location Displays current position of the vehicle. Voice Guidance On Turns the Voice Guidance On Voice Guidance Off Turns the Voice Guidance Off Voice Guidance Lauder Increases Voice Guidance volume by 1 level Voice Guidance Softer Decrease Voice Guidance volume by 1 level Repeat...
Page 256 Command Operation XM Traffic Displays XM Traffic information on the screen Auto Zoom On Turns the Auto Zoom feature on Auto Zoom Off Turns the Auto Zoom feature off Auto Mode Converts the map display is between daylight/night modes automatically Daylight Mode Converts the map display into daylight mode Night Mode...
Page 257 Check Cashing Service Physician Car Wash Gift Shop Money Transfer Social Service Gas Station Grocery Store Community Tailor & Alteration Hyundai Dealership Hardware Store City Hall Tax Service Motorcycle Dealership Home Specialty Store Civic Center Parking Music Store Convention, Center...
Page 258 Bluetooth® Handsfree • Before Use • Basic Mode Screen • Using Bluetooth...
Page 259 Bluetooth® Handsfree refers to a device which allows the user to conveniently make phone calls with Bluetooth® mobile phones through the Navigation system. The Bluetooth handsfree feature may not be supported in some mobile phones. For more information on mobile phone compatibility, visit the Hyundai Motor website (http://www.hyundaiusa.com).
Page 260 Cautions upon connecting Bluetooth® phone Before connecting the head unit with the mobile phone, If the Bluetooth® audio does not play, go to [Setup] check to see that the mobile phone supports Bluetooth® | Bluetooth| | Streaming Audio Setting|. If the feature features.
Page 261: Basic Mode Screen
Basic Mode Screen When no phones have been paired Press the [ ] key on the steering remote controller or press the [PHONE] Press |Yes| Information From the Bluetooth® device, search for • Press the |Help| button within the pop-up to the car name and pair the device.
Page 262 Basic Mode Screen When a phone is already paired Name Description Help section related to pairing and Help connecting/disconnecting Press the [ ] key on the steering remote Bluetooth® devices and controller or the [PHONE] key Press |Yes| Handsfree phone features Select the device from the device list Pair a new Bluetooth®...
Page 263 When there is a connected device Press the | | key on the steering remote controller or the [PHONE] key on the head unit to display the following screen Name Description 9 10 Info Display Displays name of currently connected device Window If no number has been entered, switches to call Send...
Page 264: Using Bluetooth
Using Bluetooth® During a call Name Description Info Displays other party’s name/number. If there is a Display call waiting, displays call waiting information Window If there is a call waiting, switches the current call Switch and connects the waiting call Ends call Dial Pad Used to enter phone number...
Page 265 Making/Answering Calls Making a call from Speed Dial If you press the | Send | button without entering a number, the Call History Enter the 1 or 2 digit speed dial number screen is displayed with the Dial Pad Press and hold the Press and hold the dial pad |0 +| (over Calling by dialing a number last number...
Page 266 Using Bluetooth® Calling through Redial Making a call from Call history Press the hold (over 0.8 seconds) the Press the | Send | button or the [ ] Key on | Send| button or the [ ] key on the the steering remote controller Select the steering remote controller...
Page 267 Rejecting a call Answering a call Information • When the incoming call pop-up is displayed, Incoming call notice Press the Incoming call notice Press the |Reject| most functions within audio and SETUP mode |Accept| button or the | | key on the button or the | | key on the steering remote will not operate.
Page 268 Using Bluetooth® Operating Menus during a Call Switching Call to the Handsfree During call on mobile phone Press the | Private| button or press and hold the [ ] Switching Call to the Bluetooth® phone key (over 0.8 seconds) on the steering remote controller.
Page 269 Ending a call Switching to Call Waiting If there is waiting call, press the [ ] key on the steering remote controller (under 0.8 While on a call Press the | End| button or If another person calls while you are already seconds) or press the | Switch| button on the [ ] Key on the steering remote controller.
Page 270 Using Bluetooth® Setting Mic volume Adjusting the Ring/Call Volume Information • The volume heard by the other party may While on a call Select |Outgoing Vol.| While on a call Use the VOL knob on differ depending on the mobile phone. If call Set Outgoing Volume Press |OK| the head unit or the [VOL+], [VOL-] keys...
Page 271 • The download feature may not be supported in some mobile phones. Check to see that the Bluetooth® device supports the download feature. • For more information on mobile phone compatibility, visit the Hyundai Motor website (http://www.hyundaiusa.com).
Page 272 Using Bluetooth® Mobile Contacts Screen Configuration Name Description Search car contacts and mobile phone contacts Search (Search by name or number) Download Download contacts from Bluetooth® device Bluetooth® Device Name of connected Bluetooth® device Name Displays total list pages and current list page List page (List page jump upon selecting scroll area) Download...
Page 273 Downloading Mobile Phone Contacts Checking Mobile Contacts Details Press the |Download| button from the Select the desired phone number from the Contacts screen Press |Yes| mobile contacts list to check details about the number. Information • Upon downloading mobile phone contacts, the previous corresponding data is deleted.
Page 274 Using Bluetooth® Adding as a Favorite Select number from the Contacts screen Within the details screen, press |Add as Favorite| Saved Favorites can be viewed by pressing the | Favorites| button in the Phone screen. Information • Up to 8 Favorites can be added. •...
Page 275 Favorites Selecting/Deleting Favorites Information • Favorites can be added through Phone In Favorites screen Press |Delete Items| | Contacts| Select contact |Add as Select items you want to delete and press Calling Favorites Favorite|. |Delete| Press |Yes| • Up to 8 Favorites can be added and Favorites In Phone screen Press | Favorites| can be used only when a Bluetooth device has...
Page 276 Using Bluetooth® Search by Name Searching by Number Searching Contacts In Phone screen Press |Search| Press the | Search by Name button| Press the | Search by Number| button Enter name and press |Search| Enter number and press |Search| Information Information •...
Page 277 Call History Call History Screen Configuration Entering Call History Screen Within the Phone screen, press the | Send| button or the [ ] key on the steering remote controller. Information The call history may not be saved in the call history list in some mobile phones.
Page 278 • The download feature may not be supported in some mobile phones. Check to see that the Bluetooth® device supports the download feature. • For more information on mobile phone compatibility, visit the Hyundai Motor website Name Description (http://www.hyundaiusa.com). Download call histories from...
Page 279 Setting Bluetooth® Connection Connections Menu Connecting a Device |Connections| Press the | Connections| button on the Phone screen. Function Description Displays Bluetooth® Help Help screen Pairs a new Bluetooth® Add New device Connect/ Connects/disconnects Disconnect a Bluetooth® device Deletes a paired Delete Bluetooth®...
Page 280 Using Bluetooth® Pairing a New Device • When a Bluetooth® device is being connected, the connection process cannot be canceled. • Only Bluetooth® Handsfree and Bluetooth® For more information on pairing, refer to audio related features will operate within this the ‘When no phones have been paired’...
Page 281 Disconnecting a Device Select the device you wish to disconnect Press |Disconnect| Press |Yes| A device cannot be deleted if it is connected. Deleting a Device To delete a paired device, first disconnect the Bluetooth® connection. Select the device you want to delete Press |Delete All| to delete all paired Press |Delete| Press |Yes|...
Page 282 Using Bluetooth® Setting Auto Connection Name Description Press the |Auto Connection| button Select Disable Auto Disables auto connection Connection the desired option Set and press |Done| Previously Auto connection with the Connected previously connected Phone Bluetooth® phone Automatically connects to User Selected a user selected Phone...
Page 283 MAP DATABASE HOTLINE M & SOFT AMERICA MAP CENTER TEL : 888-757-0010 WEBSITE : www.mapnsoft.com This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

Hyundai AV240DPAN User Manual

Quick Links

Related Manuals for Hyundai AV240DPAN

Summary of Contents for Hyundai AV240DPAN

Table of Contents
