Virtium VSFA25 Product Manual

Virtium StorFly™ 25PE – 2.5" SATA 3Gbps SSD
VSFA25 Product Manual
____________________________________________________________________________________

1.0 Introduction

Virtium's StorFly™ 25 is solid state drive (SSD) technology designed for the unique capacity, workload
and product lifecycle requirements of a broad range of embedded systems including networking,
industrial automation, medical and gaming equipment as well as point-of-sale terminals, military data
recorders and wearable computers. StorFly™ 25 SSDs deliver stable configuration for long product life
and eliminate the need for frequent product re-qualifications. StorFly™ 25PE SSDs are designed for
optimum performance at low to moderate capacity points and are excellent solutions for write intensive
applications.
1.1 Features
•
Capacities: 8, 16, 32, 64, 128GB
•
Sequential performance (128GB)
o Read/write: 270.220 MB/s
•
Random Performance (128GB)
o Read/write IOPS: 15K/4K
•
Latency:
μ
o Read/write ( s): TBD/TBD
•
Temperature
o Commercial operating: 0
o Industrial operating: -40
o Non-operating: -55
•
(1)
Power (128GB; 5V)
o Typical: 1.2W
o Idle: 1.07W
•
Reliability
o UBER: 1 error per 1014 bits read
o MTBF: 2,000,000 hours
o Endurance: Upto 600 TBW (128GB)
•
S.M.A.R.T. attribute reporting
•
Compliance
o SAT revision 2.6 (SATA 3Gbps and
1.5Gbps)
o ATA/ATAPI-7
o FCC, CE, UL, RoHS
(1) Measured based on 70/30 random read/write. Power is vary depending upon capacities, see section 4.5 for completed
typical and maximum power measurement per capacities
o o
C to 70 C
o o
C to +85 C
o o
C to +95 C
•
Mechanical Dimensions - L x W x H mm (in.)
100.5 (3.96) x 69.85 (2.75) x 9.5 (0.37)
o
•
Weight
87 +/- 2 g (128GB)
o
•
Environmental (Operating/non-operating):
Shock: 50G (11ms/Axis) x 3 Axes
o
Vibration: 10 to 2000 Hz, 16.4G, 3 Axes
o
Altitude: 40000 feet
o
Humidity: 95%
o
