Summary of Contents for Ksenia KSV0010013.300

  • Page 1 User Manual Network Camera...
  • Page 2 This manual applies to: Type Model CUBE KSV0010013.300 BULLET KSV0010113.300 This manual may contain several technical or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual.
  • Page 3 REGULATORY INFORMATION FCC INFORMATION FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 SAFETY INSTRUCTION These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
  • Page 5 environment. •While shipping, the product should be packed in its original packing. •Please use the provided glove when open up the product cover. Do not touch the product cover with fingers directly, because the acidic sweat of the fingers may erode the surface coating of the product cover.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS Chapter 1 System Requirement....................8 Chapter 2 Network Connection.....................9 2.1 Setting the Network Camera over the LAN..............9 2.1.1 Wiring over the LAN....................9 2.1.2 Detecting and Changing the IP Address.............10 2.2 Setting the Network Camera over the WAN............11 2.2.1 Static IP Connection.....................11 2.2.2 Dynamic IP Connection..................12 Chapter 3 Accessto the Network Camera.................14 3.1 Accessing by Web Browser..................14...
  • Page 7 6.6 Configuring and Handling Allarms................51 6.6.1 Configuring Motion Detection................51 6.6.2 Configuring Video Tampering Allarm..............54 6.6.3 Configuring Allarm Input..................55 6.6.4 Configuring Allarm Output..................57 6.6.5 Handling Exception....................57 6.6.6 Configuring PIR Allrm (other allarm)..............58 6.6.7 Configuring Line Crossing Detection..............59 6.6.8 Configuring Intrusion Detection.................60 Chapter 7 Storage Settings....................61 7.1 Configuring NAS Settings...................61 7.2 Configuring Recording Schedule................62...

  • Page 8: Chapter 1 System Requirement

    1.SYSTEM REQUIREMENT Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 3.5 and above version and Google Chrome8 and above version Network Camera User Manual...

  • Page 9: Chapter 2 Network Connection

    2.NETWORK CONNECTION BEFORE YOU START •If you want to set the network camera via a LAN (Local Area Network), please refer to Section 2.1 Setting the Network Camera over the LAN. •If you want to set the network camera via a WAN (Wide Area Network), please refer to Section 2.2 Setting the Network Camera over the WAN.

  • Page 10: Detecting And Changing The Ip Address

    Figure 2.1.2 - Connecting via a Switch or a Router 2.1.2 DETECTING AND CHANGING IP ADDRESS You need the IP address to visit the network camera. STEPS 1. To get the IP address, you can install the SADP client software to list the online devices. Please refer to the user manual of SADP client software for detailed information.

  • Page 11: Setting The Network Camera Over The Wan

    2.2 SETTING THE NETWORK CAMERA OVER THE WAN PURPOSE This section explains how to connect the network camera to the WAN with a static IP or a dynamic IP. 2.2.1 STATIC IP CONNECTION BEFORE YOU START Please apply a static IP from an ISP (Internet Service Provider). With the static IP address, you can connect the network camera via a router or connect it to the WAN directly.

  • Page 12: Dynamic Ip Connection

    2.2.2 DINAMIC IP CONNECTION BEFORE YOU START Please apply a dynamic IP from an ISP. With the dynamic IP address, you can connect the network camera to a modem or a router. • Connecting the network camera via a router STEPS 1.
  • Page 13 • Normal Domain Name Resolution Figure 2.2.4 - Normal Domain Name Resolution STEPS 1. Apply a domain name from a domain name provider. 2. Configure the DDNS settings in the DDNS Settings interface of the network camera. Refer to Section 6.3.4 Configuring DDNS Settings for detailed configuration. 3.

  • Page 14: Chapter 3 Accessto The Network Camera

    3.ACCESS TO THE NETWORK CAMERA 3.1 ACCESSING BY WEB BROWSER STEPS 1. Open the web browser. 2. In the address field, input the IP address of the network camera, e.g., 192.168.2.95 and hit the enter key to enter the login interface. 3.
  • Page 15 Figure 3.1.3 - Install Plug-in (1) Figure 3.1.4 - Install Plug-in (2) Note: You may have to close the web browser to install the plug-in. Please reopen the web browser and log in again after the plug-in is installed. Network Camera User Manual...

  • Page 16: Chapter 4 Wi-Fi Settings

    4.Wi-Fi SETTINGS PURPOSE By connecting to the wireless network, you don’t need to use cable of any kind for network connection, which is very convenient for the actual surveillance application. Note: This chapter is only applicable for the cameras with the built-in Wi-Fi module. 4.1 CONFIGURING Wi-Fi CONNECTION Note: A wireless network is required before you start.
  • Page 17 Note: These parameters are exactly identical with those of the router. 5. Enter the key to connect the wireless network. The key should be that of the wireless network connection you set on the router. • Wireless Connection in Ad-hoc Mode If you choose the Ad-hoc mode, you don’t need to connect the wireless camera via a router.
  • Page 18 6. Choose the SSID and connect. • Security Mode Description: Figure 4.1.6 - Security Mode You can choose the Security Mode as not-encrypted, WEP, WPA-personal, WPA- enterprise, WPA2-personal, and WPA2-enterprise. •WEP mode: Figure 4.1.7 - WEP Mode •Authentication - Select Open or Shared Key System Authentication, depending on the method used by your access point.
  • Page 19 Figure 4.1.8 - Security Mode- WPA-personal • WPA- enterprise and WPA2-enterprise Mode: Choose the type of client/server authentication being used by the access point; EAP- TLS or EAP-PEAP. Figure 4.1.9 - EAP-TLS •EAP-TLS: •Identity - Enter the user ID to present to the network. •Private key password –...

  • Page 20: Easy Wi-Fi Connection With Wps Function

    4.2 EASY Wi-Fi CONNECTION WITH WPS FUNCTION PURPOSE The setting of the wireless network connection is never easy. To avoid the complex setting of the wireless connection you can enable the WPS function. WPS (Wi-Fi Protected Setup) refers to the easy configuration of the encrypted connection between the device and the wireless router.
  • Page 21 When the PBC mode is both enabled in the router and the camera, the camera and the wireless network is connected automatically. PIN Mode: The PIN mode requires a Personal Identification Number (PIN) to be read from either a sticker or the display on the new wireless device. This PIN must then be entered to connect the network, usually the Access Point of the network.

  • Page 22: Ip Property Settings For Wireless Network Connection

    4.3 IP PROPERTY SETTINGS WIRELESS NETWORK CONNECTION STEPS 1. Enter the TCP/IP configuration interface. Configuration> Advanced Configuration> Network> TCP/IP Or Configuration> Basic Configuration> Network> TCP/IP Figure 4.3.1 - TCP/IP Settings 2. Select the NIC as wlan. 3. Customize the IPv4 address, the IPv4 Subnet Mask and the Default Gateway. The setting procedure is the same with that of LAN.

  • Page 23: Chapter 5 Live View

    5. LIVE VIEW 5.1 LIVE VIEW PAGE PURPOSE The live video page allows you to view live video, capture images, realize PTZ control, set/call presets and configure video parameters. Log in the network camera to enter the live view page, or you can click on the menu bar of the main page to enter the live view page.

  • Page 24: Starting Live View

    5.2 STARTING LIVE VIEW In the live view window as shown in Figure 5-2, click on the toolbar to start/stop the live view of the camera. Figure 5.2.1 - Live View Toolbar Table 5.2.1 Descriptions of the Toolbar Icon Description Start/Stop live view Manually capture the pictures displayed in live view and then save it as a JPEG file or BMP file.

  • Page 25: Chapter 6 Network Camera Configuration

    6. NETWORK CAMERA CONFIGURATION 6.1 CONFIGURING LOCAL PARAMETERS Note: The local configuration refers to the parameters of the live view, record files and captured pictures. The record files and captured pictures are the ones you record and captured using the web browser and thus the saving paths of them are on the PC running the browser.

  • Page 26: Configuring Time Settings

    >Live View Performance: Set the live view performance to Least Delay, Balanced or Best Fluency. •Record File Settings: Set the saving path of the recorded video files. Valid for the record files you recorded with the web browser. >Record File Size: Select the packed size of the manually recorded and downloaded video files to 256M, 512M or 1G.
  • Page 27 • Select the Time Zone. Select the Time Zone which is the closest to the location of the camera from the drop- down menu. > Synchronizing Time by NTP Server. 1) Check the checkbox to enable the NTP function. 2) Configure the following settings: Server Address: IP address of NTP server.

  • Page 28: Configuring Network Settings

    2. Click “Save” to save the settings. 6.3 CONFIGURING NETWORK SETTINGS 6.3.1 CONFIGURING TCP/IP SETTINGS PURPOSE TCP/IP settings must be properly configured before you operate the camera over network. The camera supports both the IPv4 and IPv6. Both versions may be configured simultaneously without conflicting to each other, and at least one IP version should be configured.

  • Page 29: Configuring Port Settings

    Note: •The valid value range of MTU is 500 ~ 1500. •The Multicast sends a stream to the multicast group address and allows multiple clients to acquire the stream at the same time by requesting a copy from the multicast group address.

  • Page 30: Configuring Pppoe Settings

    6.3.3 CONFIGURING PPPoE SETTINGS STEPS 1.Enter the PPPoE Settings interface: Configuration >Advanced Configuration > Network > PPPoE Figure 6.3.4 - PPPoE Settings 2. Check the Enable PPPoE checkbox to enable this feature. 3. Enter User Name, Password, and Confirm password for PPPoE access. Note: The User Name and Password should be assigned by your ISP.
  • Page 31 Figure 6.3.5 - DDNS Settings 2. Check the Enable DDNS checkbox to enable this feature. 3. Select DDNS Type. Three DDNS types are selectable: KseniaDDNS,IP Server,No-IP. • Ksenia DDNS (DynDNS): STEPS 1) Enter Server Address of DynDNS (e.g. Kseniadns.com,members.dyndns.org). 2) In the Domain text field, enter logicalname of the device (hostname).
  • Page 32 Note: For the IP Server, you have to apply a static IP, subnet mask, gateway and preferred DNS from the ISP. The Server Address should be entered with the static IP address of the computer that runs the IP Server software. Figure 6.3.7 - IP Server Settings Network Camera User Manual...

  • Page 33: Configuring Snmp Settings

    6.3.5 CONFIGURING SNMP SETTINGS PURPOSE You can set the SNMP function to get camera status, parameters and alarm related information and manage the camera remotely when it is connected to the network. BEFORE YOU START Before setting the SNMP, please download the SNMP software and manage to receive the camera information via SNMP port.

  • Page 34: Configuring 802.1X Settings (Only For Some Versions)

    2.Check the corresponding version checkbox ( to enable the feature. 3.Configure the SNMP settings. Note: The settings of the SNMP software should be the same as the settings you configure here. 4.Click “Save” to save and finish the settings. Note: A reboot is required for the settings to take effect.

  • Page 35: Configuring Qos Settings

    Note: The EAPOL version must be identical with that of the router or the switch. 4. Enter the user name and password to access the server. 5. Click “Save” to finish the settings. Notes: •A reboot is required for the settings to take effect. •The camera supports Wi-Fi function doesn’t support 802.1X.

  • Page 36: Configuring Ftp Settings

    6.3.8 CONFIGURING FTP SETTINGS PURPOSE You can configure the FTP server related information to enable the uploading of the captured pictures to the FTP server. The captured pictures can be triggered by events or a timing snapshot task. STEPS 1. Enter the FTP Settings interface: Configuration >Advanced Configuration >...

  • Page 37: Configuring Upnp Tm Settings

    Configuration > Advanced Configuration > Allarm > Other Allarm > Capturing Picture on Allarm 6.3.9 CONFIGURING UPnP™ SETTINGS Universal Plug and Play (UPnP™) is a networking architecture that provides compatibility among networking equipment, software and other hardware devices. The UPnP protocol allows devices to connect seamlessly and to simplify the implementation of networks at home and in corporate environments.
  • Page 38 2. Enter the Email Settings interface: Configuration > Advanced Configuration > Network > Email Figure 6.3.13 - Email Settings 3. Configure the following settings: Sender: The name of the email sender. Sender’s Address: The email address of the sender. SMTP Server: The SMTP Server IP address or host name (e.g., smtp.263xmail.com). SMTP Port: The SMTP port.

  • Page 39: Configuring Nat (Network Address Translation) Settings

    6.3.11 CONFIGURING NAT (NETWORK ADDRESS TRANSLATION) SETTINGS 1. Enter the NAT settings interface. Configuration >Advanced Configuration > Network > NAT 2. Choose the port mapping mode. To port mapping with the default port number, you can choose Port Mapping Mode as Auto.

  • Page 40: Https Settings

    6.3.12 HTTPS SETTINGS PURPOSE HTTPS provides authentication of the web site and associated web server that one is communicating with, which protects against Man-in-the-middle attacks. Perform the following steps to set the port number of https. E.g: If you set the port number as 443 and the IP address is 192.168.2.95, you may access the device by inputting https://192.168.2.95:443 via the web browser.
  • Page 41 Figure 6.3.16 - Create Self-signed Certificate 2) Enter the country, host name/IP, validity and other information. 3) Click “Ok” to save the settings. Note: If you already had a certificate installed, the Create Self-signed Certificate is grayed out. •Create the authorized certificate 1) Click “Create Button”...

  • Page 42: Configuring Video And Audio Settings

    6.4 CONFIGURING VIDEO AND AUDIO SETTINGS 6.4.1 CONFIGURING VIDEO SETTINGS STEPS 1. Enter the Video Settings interface: Configuration >Basic Configuration > Video / Audio > Video Or Configuration > Advanced Configuration > Video / Audio > Video Figure 6.4.1 - Configure Video Settings 2.Select the Stream Type of the camera to main stream (normal), sub-stream or third stream.

  • Page 43: Configuring Audio Settings

    maintains image quality throughout. Max. Bitrate: Set the max. bitrate to 32~16384 Kbps. The higher value corresponds to the higher video quality, but the higher bandwidth is required. Video Encoding: If the Stream Type is set to main stream, H.264 is selectable, and if the stream type is set to sub stream, H.264, and MJPEG are selectable.

  • Page 44: Configuring Roi Encoding

    6.4.3 CONFIGURING ROI ENCODING ROI stands for the “Region of Interest”. And the ROI encoding enables you to discriminate the ROI and background information in compression, that is to say, the technology assigns more encoding resource to the region of interest to increase the quality of the ROI whereas the background information is less focused.

  • Page 45: Display Info On Stream

    There are two options for ROI encoding, the fixed region encoding and the dynamic tracking: •The fixed region encoding is the ROI encoding for the manually configured area. And you can choose the Image Quality Enhancing level for ROI encoding, and you can also name the ROI area. •The dynamic region refers to the ROI defined by intelligent analysis such as human face detection.

  • Page 46: Configuring Image Parameters

    6.5 CONFIGURING IMAGE PARAMETERS 6.5.1 CONFIGURING DISPLAY SETTINGS PURPOSE You can set the image quality of the camera, including brightness, contrast, saturation, hue, sharpness, etc. Note: The Display parameters vary depending on the camera model. STEPS 1. Enter the Display Settings interface: Configuration >...
  • Page 47 normally 50Hz for PAL standard and 60Hz for NTSC standard. Day/Night Switch: Day, Night and Auto are selectable. Sensitivity: If you choose auto day/night switch, you can choose the sensitivity of the switch as high, normal and low. Mirror: The mirror function enables you to view another aspect of the image. You can flip the image horizontally and vertically.

  • Page 48: Configuring Osd Settings

    6.5.2 CONFIGURING OSD SETTINGS PURPOSE You can customize the camera name and time on the screen. STEPS 1. Enter the OSD Settings interface: Configuration > Advanced Configuration > Image > OSD Settings Figure 6.5.3 - OSD Settings 2. Check the corresponding checkbox to select the display of camera name, date or week if required.

  • Page 49: Configuring Text Overlay Settings

    6.5.3 CONFIGURING TEXT OVERLAY SETTINGS You can customize the text overlay. STEPS 1. Enter the Text Overlay Settings interface: Configuration > Advanced Configuration > Image > Text Overlay In this section you can create a text overlay labels over the video stream. Note: Up to 4 text overlays are configurable.

  • Page 50: Configuring Picture Overlay

    Figure 6.5.6 - Privacy Mask Settings 4. Click and drag the mouse in the live video window to draw the mask area. Note: You are allowed to draw up to 4 areas on the same image. You can click “Clear All” to clear all the draws.

  • Page 51: Configuring And Handling Alarms

    Figure 6-38 - Picture Overlay 2. Click “Browse” to select a picture. 3. Click “Upload” to upload it. 4. Check “Enable Picture Overlay” checkbox to enable the function. X Coordinate and Y Coordinate values are for the location of the picture on the image. And the Picture width and height shows the size of the picture.
  • Page 52 STEPS 1) Enter the motion detection settings interface Configuration > Advanced Configuration> Events > Motion Detection 2) Check the checkbox of “Enable Motion Detection”. Figure 6.6.1 - Enable Motion Detection 3) Click “Draw Area”. Click and drag the mouse on the live video image to draw a motion detection area.
  • Page 53 1. Click “Edit” to edit the arming schedule. The Figure 6.6.2 shows the editing interface of the arming schedule. 2. Choose the day you want to set the arming schedule. 3. Click to set the time period for the arming schedule. 4.

  • Page 54: Configuring Video Tampering Allarm

    STEPS Check the checkbox to select the linkage method. Audible warning, notify surveillance center, send email, upload to FTP, trigger channel and trigger alarm output are selectable •Audible Warning Trigger the audible warning locally. •Notify Surveillance Center Send an exception or alarm signal to remote management software when an event occurs.

  • Page 55: Configuring Allarm Input

    Figure 6.6.5 - Video Tampering Alarm 2. Check “Enable Video Tampering” checkbox to enable the video tampering detection. 3.Set the video tampering area; refer to Task 1 Set the Motion Detection Area in Section 6.6.1. 4. Click “Edit” to edit the arming schedule for video tampering. The arming schedule configuration is the same as the setting of the arming schedule for motion detection.
  • Page 56 Figure 6.6.6 - Alarm Input Settings 3. To set the arming schedule and linkage method for the allarm input please refer to Tasks 2 and Tasks 3 in Section 6.6.1 Figure 6.6.7 - Linkage Method Network Camera User Manual...

  • Page 57: Configuring Allarm Output

    6.6.4 CONFIGURING ALARM OUTPUT STEPS 1. Enter the Alarm Output Settings interface: Configuration>Advanced Configuration> Events > Alarm Output 2. Select one alarm output channel in the Alarm Output drop-down list. You can also set a name for the alarm output (optional). 3.

  • Page 58: Configuring Pir Allrm (Other Allarm)

    STEPS 1.Enter the Exception Settings interface: Configuration > Advanced Configuration> Events > Exception To set the actions taken for the Exception alarm. Refer to Task 3 in Section 6.6.1. Figure 6.6.9 - Exception Settings 6.6.6 CONFIGURING PIR ALARM (OTHER ALLARM) Some of the camera support PIR (passive infrared sensor) alarm.

  • Page 59: Configuring Line Crossing Detection

    6.6.7 CONFIGURING LINE CROSSING DETECTION This function can be used for detecting people, vehicles and objects crossing a pre-defined area. The line crossing direction can be set as bidirectional, from left to right or from right to left. And a series of linkage method will be triggered if any object is detected.

  • Page 60: Configuring Intrusion Detection

    6.6.8 CONFIGURING INTRUSION DETECTION Intrusion detection can set an area in the surveillance scene and once the area is been entered, a set of alarm action is triggered. STEPS 1. Check the “Enable Intrusion Detection” checkbox. 2. Click “Draw Area”, and then draw a rectangle on the image as a defense region. Note: When you draw the rectangle, all lines should connect end to end to each other.

  • Page 61: Chapter 7 Storage Settings

    7.STORAGE SETTINGS BEFORE YOU START To configure record settings, please make sure that you have the network storage device within the network or the SD card inserted in your camera. 7.1 CONFIGURING NAS SETTING BEFORE YOU START The network disk should be available within the network and properly configured to store the recorded files, log files, etc.

  • Page 62: Configuring Recording Schedule

    2. Initialize the added network disk. 1) Enter the HDD Settings interface (Advanced Configuration > Storage > Storage Management), in which you can view the capacity, free space, status, type and property of the disk. Figure 7.1.2 - Initialize Disk 2) If the status of the disk is Uninitialized, check the corresponding checkbox to select the disk and click “Format”...
  • Page 63 Figure 7.2.1 - Recording Schedule Interface 2. Check the checkbox of “Enable Record Schedule” to enable scheduled recording. 3. Set the record parameters of the camera. Figure 7.2.2 - Record Parameters •Pre-record: The time you set to start recording before the scheduled time or the event.
  • Page 64 Figure 7.2.3 - Record Schedule 5.Choose the day to set the record schedule. 1) Set all-day record or segment record: •If you want to configure the all-day recording, please check the All Day checkbox. •If you want to record in different time sections, check the Customize checkbox. Set the Start Time and End Time.

  • Page 65: Configuring Snapshot Settings

    Settings interface. For detailed information, please refer to Section 6.6.3. •Record Triggered by Motion & Alarm If you select Motion & Alarm, the video will be recorded when the motion and alarm are triggered at the same time. Besides configuring the recording schedule, you have to configure the settings on the Motion Detection and Alarm Input Settings interfaces.
  • Page 66 • Upload continuous snapshots to FTP Figure 7.3.1 - Snapshot Settings STEPS 1) Configure the FTP settings and check “Upload Picture” checkbox in FTP Settings interface. Please refer to Section 6.3.8 Configuring FTP Settings for more details to configure FTP parameters. 2) Check the “Enable Timing Snapshot”...

  • Page 67: Chapter 8 Playback

    8.PLAYBACK PURPOSE This section explains how to view the remotely recorded video files stored in the network disks or SD cards. STEPS 1. Click “Playback” on the menu bar to enter playback interface. Figure 8.1.1 - Playback Interface 2. Select the date and click Figure 8.1.2 - Search Video 3.
  • Page 68 Figure 8.1.3 - Playback Toolbar Table 8.1.1 Description of the buttons Button Operation Button Operation Play Capture a picture Pause Start/Stop clipping video files Audio on and adjust volume/ Stop Mute Speed down Download video files Speed up Download captured pictures Playback by frame Enable/Disable digital zoom Note:...

  • Page 69: Chapter 9 Log Searching

    9.LOG SEARCHING PURPOSE The operation, alarm, exception and information of the camera can be stored in log files. You can also export the log files on your demand. BEFORE YOU START Please configure network storage for the camera or insert a SD card in the camera. STEPS 1.

  • Page 70: Chapter 10 Others

    10.OTHERS 10.1 MANAGING USERS ACCOUNT Enter the User Management interface: Configuration >Basic Configuration> Security > User Or Configuration > Advanced Configuration> Security > User The admin user has access to create, modify or delete other accounts. Up to 15 user accounts can be created.

  • Page 71: Configuring Rtsp Authentication

    • Modify a User STEPS 1. Left-click to select the user from the list and click “Modify”. 2. Modify the User Name, Level or Password. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions. 4.

  • Page 72: Anonymous Visit

    2. Select the Authentication type basic or disable in the drop-down list to enable or disable the RTSP authentication. Note: If you disable the RTSP authentication, anyone can access the video stream by the RTSP protocol via the IP address. 3.

  • Page 73: Ip Address Filter

    10.4 IP ADDRESS FILTER PURPOSE This function makes it possible for access control. STEPS 1. Enter the IP Address Filter interface: Configuration> Advanced Configuration> Security > IP Address Filter Figure 10.4.1 - IP Address Filter Interface 2. Check the checkbox of Enable IP Address Filter. 3.
  • Page 74 Figure 10.4.2 - Add an IP 3) Click “Ok” to finish adding. •Modify an IP Address STEPS 1) Left-click an IP address from filter list and click “Modify” button. 2) Modify the IP address in the text filed. Figure 10.4.3 - Modify an IP 3) Click the “Ok”...

  • Page 75: Viewing Device Information

    10.5 VIEWING DEVICE INFORMATION Enter the Device Information interface: Configuration > Basic Configuration> System > Device Information Or Configuration > Advanced Configuration> System > Device Information In the Device Information interface, you can edit the Device Name. Other information of the network camera, such as Model, Serial No., Firmware Version, Encoding Version, Number of Channels, Number of HDDs, Number of Alarm Input and Number of Alarm Output are displayed.

  • Page 76: Restoring Default Settings

    10.6.2 RESTORING DEFAULT SETTING STEPS 1. Enter the Maintenance interface: Configuration > Basic Configuration> System > Maintenance Or Configuration > Advanced Configuration> System > Maintenance 2. Click “Default” or “Restore” to restore the default settings. Figure 10.6.2 Restore Default Settings Note: After restoring the default settings, the IP address is also restored to the default IP address, please be careful for this action.

  • Page 77: Rs-232 Settings

    Figure 10.6.3 - Remote Upgrade 10.7 RS-232 SETTING PURPOSE The RS-232 port can be used in two ways: •Parameters Configuration: Connect a computer to the camera through the serial port. Device parameters can be configured by using software such as HyperTerminal. The serial port parameters must be the same as the serial port parameters of the camera.

  • Page 78: Security Service

    10.8 SECURITY SERVICE To enable the remote login, and improve the data communication security, the camera provides the security service for better user experience. STEPS 1. Go to Configuration > Advanced configuration > Security >Security Service to enter the security service configuration interface. Figure 10.8.1 - Security Service 2.

  • Page 79: Appendix

    APPENDIX APPENDIX 1 SADP SOFTWARE INTRODUCTION •Description of SADP SADP (Search Active Devices Protocol) is a kind of user-friendly and installation-free online device search tool. It searches the active online devices within your subnet and displays the information of the devices. You can also modify the basic network information of the devices using this software.
  • Page 80 can click to expand the device table and hide the network parameter panel on the right side, or click to show the network parameter panel. • Modify network parameters STEPS 1. Select the device to be modified in the device list and the network parameters of the device will be displayed in the Modify Network Parameters panel on the right side.

  • Page 81: Appendix 2 Port Mapping

    APPENDIX 2 PORT MAPPING The following settings are for TP-LINK router (TL-WR641G). The settings vary depending on different models of routers. STEPS 1.Select the WAN Connection Type, as shown below: Figure A.2.1 - Select the WAN Connection Type 2.Set the LAN parameters of the router as in the following figure, including IP address and subnet mask settings.
  • Page 82 3. Set the port mapping in the virtual severs of Forwarding. By default, camera uses port 80, 8000, 554 and 8200. You can change these ports value with web browser or client software. Example: When the cameras are connected to the same router, you can configure the ports of a camera as 80, 8000, 554 and 8200 with IP address 192.168.1.23, and the ports of another camera as 81, 8001, 555, 8201 with IP 192.168.1.24.

This manual is also suitable for:
