Nagravision DMT 1761 User Manual

Digital set-top box
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Front Cover
LIVEWIRE OS
DIGITAL SET-TOP BOX USER MANUAL
Back Cover
CONTACT INFO
• <Mailing Address >
• <Phone Number>
• <Customer Service Phone Number and Address (If Different)>
• <Parent Company Affiliations (If Necessary)>
Important safety instructions
Safety
CAUTION
:TO REDUCE THE RISK OF ELECTRIC SHOK
DO NOT REMOVE COVER(OR BACK)
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
& FCC information
The lighting flash with arrowhead symbol,
Within an equilateral triangle, is intended to alert the user
to the presence of un-insulated
"dangerous voltage" within the product's enclosure that
may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DMT 1761 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nagravision DMT 1761

  • Page 1 Front Cover LIVEWIRE OS DIGITAL SET-TOP BOX USER MANUAL Back Cover CONTACT INFO • <Mailing Address > • <Phone Number> • <Customer Service Phone Number and Address (If Different)> • <Parent Company Affiliations (If Necessary)> Important safety instructions & FCC information Safety CAUTION :TO REDUCE THE RISK OF ELECTRIC SHOK...
  • Page 2 FOR YOUR SAFETY - The space around the receiver should be clear to allow for proper ventilation of the receiver. - Do not cover the receiver or place it on a unit that emits heat - Use a damp soft cloth to clean the casing. - Do not connect or disconnect cables when the receiver is plugged in.
  • Page 3 Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, install in accordance with the manufacturer’s instructions.
  • Page 4 FCC INFORMATION FCC ID : PFNDMT1761 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 5 MODEM Instructions CAUTION - To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord. Note : 1. Both side shell peeled 6~7mm 2. To take up positions when insert the RJ11 6P2C 3. cable wording (E216131 AWM 20251 26AWG VW-160℃...

  • Page 6: Table Of Contents

    TABLE OF CONTENTS 1 YOUR DIGITAL SET-TOP BOX 1.1 Set-Top Box Details ..........4 1.2 Getting Started ............ 5 1.3 Front Panel ............6 1.4 Rear Panel ............7 1.5 Universal Remote Control........8-9 2 VIEW PROGRAMS 2.1 Program Information ........10-11 2.2 Program Navigation ........11-12 2.3 Program Guide ..........12-16 2.4 Options ..............

  • Page 7: Your Digital Set-Top Box

    Under Resale Agreements with Nagravision KUDELSKI GROUP User Manual v2.5.7 © 2006 NAGRAVISION. All Rights Reserved. In order to provide you with the best user experience available, there will be periodic upgrades to the system software. The screen examples used in this manual are for demonstration purposes only and are subject to change without notification and may not accurately represent what you will see onscreen.

  • Page 8: Front Panel

    If you have connected your Digital Set-Top Box using RCA Cables make sure your TV is set to the proper Video Input Mode. (Example: Video 1, Video 2) 7. Using your Universal Remote Control, select the CABLE (CBL) button on the remote, then press the POWER button.

  • Page 9: Rear Panel

    Decreases or Increases the level of audio Power Button Switches Power On or into Stand-By Mode 1.3 Rear Panel DC POWER Power Supply Input CABLE IN RF Input ( Coax Cable) This is used to connect the cable from the wall to the Digital Set-Top Box. ANT OUT RF Output (Coax Cable) When the Digital Set-Top Box is in Stand-By mode, this output can be connected to a...
  • Page 10 ANT IN RF Input (Coax Cable) This can be used to connect a TV antenna using a Coax Cable to the Digital Set-Top Box. When the Digital Set-Top Box is in Stand-By Mode, the original signal can be displayed through the Digital Set-Top Box and into your TV or VCR directly (bypass) using the ANT OUT connector.

  • Page 11: Universal Remote Control

    1.3 Universal Remote Control...
  • Page 12 POWER In CABLE MODE switches Power On or into Stand-By Mode. In all other modes turns the power of that device On or Off. CABLE Activates remote to control the Digital Set-Top Box (CABLE MODE). Activates remote to control a TV (TV MODE). Activates remote to control a VCR (VCR MODE).

  • Page 13: View Programs

    EXIT Returns video to full screen from any INFO, MENU SYSTEM or PROGRAM GUIDE screen. RECORD Sets a VCR to Record. PAUSE Instructs a VCR, DVD or CD player to Pause. PLAY Instructs a VCR, DVD or CD player to Play. REWIND Instructs a VCR, DVD or CD player to Rewind.

  • Page 14: Program Navigation

    • Start and End Times INFO 2 MODE Displays the following information: • Channel Name • Channel Number • Current Date and Time • Program Start Time • Program End Time • Program Theme (If Available) • Program Rating (If Available) •...

  • Page 15: Program Guide

    Use “CH +” or “CH -” to tune to the next or previous available channel. The screen will remain in the INFO MODE you have selected. To exit INFO MODE, continue to press the “Info” button until the information screens disappear, or press “EXIT” at any time. NOTE: Even if you are not in INFO MODE, your screen will display information about the current program each time you change the channel.
  • Page 16 The Program Guide is divided into four sections. The top left corner of your screen displays an INFO WINDOW that contains the following information about the program that you have highlighted: • Channel Number • Program Start Time • Program End Time •...
  • Page 17 • Current Program Names The RIGHT COLUMN displays the upcoming programs available on the currently highlighted channel. Scroll down to show all the programs scheduled for the day or select DAY SHIFTER (see p.15) to quickly jump ahead 24 hours. The right column displays the following information: •...
  • Page 18 DAY SHIFTER When you move the cursor inside the RIGHT COLUMN, the list will begin with the current program. From this position, use the "Up" arrow on your remote control to start the DAY SHIFTER feature, or press the “Last” button on your remote control to automatically highlight the DAY SHIFTER. Once the current date is highlighted, use the "Right"...

  • Page 19: Options

    If you select a FUTURE PROGRAM, you will be given the option to set a timer so that you can view the program when it begins. Choose "SET TIMER" onscreen by pressing "OK" on your remote control. A TIMER ICON will then appear next to the program for which you have set a timer. Your TV will automatically tune to this program when it begins.

  • Page 20: Ordering Pay-Per-View

    your remote control to navigate and select the available option. Select “DONE” onscreen to activate changes. The changes will only affect your currently viewed program, and will default back to normal once the program is complete. TIP: Press the “FAV+”(Red) button on your remote control to rotate through your favorite lists. When you activate this feature, you will switch between All Channels and if active, your currently selected Theme and any of the eight Custom Favorite Lists.

  • Page 21: Menu Features

    MAIN MENU Access the Main Menu at any time by pressing the “MENU” button on the remote control. MENU FEATURES • Portal Cable Mágico (Section 2.1) • Program Guide (Section 2.2) • Favorites • Parental Controls • Timers • System Menu TIP: Press the blue “Done”...
  • Page 22 SELECT FAVORITE LIST OR BROWSE BY THEME • Display All Channels: Quickly reset your current mode to include all available channels. • Channel Themes: Choose from a variety of different themes for browsing, such as Movies, Kids, or Sports. • Edit Current Favorites: Opens the EDIT FAVORITE Menu Page, where you can change the name or channel lineup of any of your eight custom favorites list.

  • Page 23: Parental Controls

    your remote control to exit the TEXT WINDOW and highlight the “SAVE” button onscreen. Press "OK" on your remote control to save changes to the name. You can choose up to 30 channels for each Custom Favorite List. Scroll through the channel lineup using the “Page Up/Down”...

  • Page 24: Timers

    Change PIN-Code: Opens a screen that allows you to set a new PIN-Code. You may also wish to consider the following General Settings: • Lock Set-Top Panel: Lock the Digital Set-Top Box front panel buttons. Select “DONE” onscreen to confirm Parental Control status and return to the MENU FEATURES screen.

  • Page 25: System Menu

    SET MANUAL TIMER The SET-MANUAL TIMER screen allows you to set an ON/OFF timer on your Digital Set-Top Box. You can use this feature, if you have turned your Digital Set-Top Box off and would like to have it turn back on at a specific date and time to be available to record a program with a VCR. First press the "OK"...
  • Page 26 GENERAL SETTINGS 1 SCREEN FORMAT: To set your preference for the dimensions of video that you would like to receive on your TV, use the “Arrow” buttons on your remote control to select one of the 3 following options: • Standard 4:3 (Standard Screen): Select this option if your TV is standard format •...
  • Page 27 SUBTITLING: Use the “Arrow” buttons on your remote control to first turn Subtitling ON or OFF. If you choose ON then the subtitle text will appear over your video in the language that you specify here. NOTE: You can switch to any subtitle language that may be available for a program by using the OPTIONS screen while you watching a program (Section 2.6).
  • Page 28 • Smart Card • Tuning Status • Reset System to Factory Defaults SYSTEM INFO 1, 2 and 3 The information on these screens indicate details about your Digital Set-Top Box, System Software, Data Collection, Number of TV Channels, and your System Clock. NOTE: Use the “Page Up/Down”...

  • Page 29: Trouble Shooting

    With this screen you can quickly see if your Digital Set-Top Box is locked to the correct frequency. If the signal is locked you will see the “LOCKED” icon on-screen. RESET SYSTEM To reset your system to the original factory defaults, enter your PIN-Code using the numbers “0-9”...

  • Page 30: Message Screens

    control, or by using the arrow buttons to select “HELP” (Yellow) located at the bottom of each MENU SCREEN. Select “DONE” onscreen to exit HELP AND INFORMATION and return to the MENU SCREEN you came from. TIPS: Press the yellow “Help” button on your remote control to display the HELP AND INFORMATION for the current screen you are viewing.

  • Page 31: Problem Solving

    MESSENGER SCREENS Specific messages regarding your account, line-up changes, temporary outages or weather patterns can be transmitted directly to your Digital Set-Top Box by way of MESSENGER SCREENS. Once read, some MESSENGER SCREENS are temporary, and go away after a few seconds, or are removed by pressing the “OK”...
  • Page 32 The front panel displays a Green LED Light, but nothing is displayed on the TV. The Digital Set-Top Box is not hooked up properly to your television set. If your system is connected by Coax Cables, switch your TV to the channel you have selected as its channel for the Digital Set-Top Box.
