Summary of Contents for Airsmart Technology R801W-3DI
- Page 1 Tube Queen AM/FM Radio & Bluetooth Speaker R801W-3DI Large collectible table-model Hi-Fi stereo radio /Bluetooth speaker...
- Page 2 Tube Queen AM/FM Radio & Bluetooth Speaker...
- Page 3 Tube Queen is a large table-model radio /Bluetooth speaker produced by our company. This product uses the Hi-Fi concept and draws experience from Germany's excellent radio design style in the 1950s to 60s. The product uses electronic tube to make power amplifier and signal strength received indicator.
- Page 4 Figure 1...
- Page 5 ① Medium wave external antenna port ② FM antenna port ③ FM internal/external antenna transfer switch ④ Short-wave proximity and remote switch ⑤ Right channel inner /outer speaker transfer switch ⑥ Right channel speaker port ⑦ Auxiliary input ⑧ Left channel speaker port ⑨...
- Page 6 ⑫ Bluetooth /AUX / FM stereo and mono FM transfer switch and AFC switch ⑬ Power switch / volume adjustment ⑭ Bass tuning ⑮ Auxiliary input / Bluetooth function switch ⑯ FM transfer switch ⑰ Short wave II transfer switch ⑱...
- Page 7 Power supply voltage Power switch and sound adjustment Panel (Figure 2) ⑬ is the power switch and (Figure 1) ⑩ is the powerport (in), which may be connected with 230V or 115V alternating current volume knob. By clockwise rotation, turn (AC) by use of standard three-pin plug (random the power on, and by counterclockwise configuration).
- Page 8 Wave selection Search for radio broadcasting Bluetooth play/ CD play and auxiliary input Front panel (Figure 2) ⑮ - ⑲ five key (Figure 2) ⑯ -⑲ when a certain wave switch is pressed, See page 14: use of Bluetooth adjust the tuning button, (Figure 2) ○ 2 2 to search for switches function wave...
- Page 9 Listen to FM broadcasting When the machine is used as a radio, it is of paramount This machine has equipped with built-in FM line. If the radio is placed importance to place the machine and the external antenna close to the window in the general urban area (not far from the radio correctly.
- Page 10 Listen to medium wave broadcasting Medium Wave antenna Medium Wave antenna Press (Figure 2) ⑲ switch to be in medium wave band, and turn the knob connection diagram (Figure 2) ○ to listen to the radio programs within the range of 530-1610KHZ.
- Page 11 FM/shortwave outdoor antenna Turn the internal and external switch to external position This machine is provided with exclusive FM / shortwave antenna jack, which can be connected to exclusive FM/shortwave outdoor antenna in order to enhance the indoor reception effect. FM / shortwave antenna connection diagram...
- Page 12 (Figure 2) ⑫ is FM stereo switch, which is provided with AFC (automatic frequency control) switch. When the radio is affected by environment and temperature, frequency shift phenomenon might occur in the received radio program. In this case, AFC function can improve the quality of reception. When using this function, please note that the switch is turned to FM or FM ST position to accurately receive the radio station, and then switch is turned to FM AFC or FM ST AFC position.
- Page 13 External CD Player or Other Signal Resource Please connect audio signal output of CD or other auxiliary signal resource with Bluetooth Function Instructions AUX IN port of the rear part of radio on the left (figure 1) ○ through RCA wire.
- Page 14 This machine inherits the design of the traditional radio in the 1960s, and is Attention: in the power-on state, do not use external provided with "bass" and "treble" toning knob. The user may adjust the two loudspeaker, and be sure to turn the loudspeaker switch (Figure 1) ⑤...
- Page 15 This product uses the shell made of solid wood. We give you the following maintenance recommendations: The vacuum tube is a glass Do not spill liquid on the Place this product away from Avoid excessive indoor dryness, product and easy to be broken. vacuum tube during...
- Page 16 Frequency Range Noise-limited FM: 87- 108MHz sensitivity MW: 530- 1610kHz SW1 : 4.5 - 12MHz FM: 10uv (actual SW2: 12-22MHz measurement 8uv) AM medium wave: 1.5mv (actual measurement lmv) shortwave : lOOuv (actual measurement 80uv) ① Radio (1) Degree of distortion Signal to Noise Ratio ②...
- Page 17 Common faults and removal Fault phenomenon Causes Solution No sound 1. Not power on 1. Pay attention to power connection 2. Not press the function switch 2. Press the corresponding function switch 3. Volume knob in off position (keyboard switch) to adjust the volume knob. 4.
- Page 18 ①What is shortwave radio? Many countries in the world use short frequency to perform worldwide broadcast transmission. Shortwave frequency range is usually between 1.6MHz and 30MHz. The radio that can receive the frequency with the range is called shortwave radio. ②...
- Page 19 ③ ④ Effect of listening to shortwave programs at different times of the day What language programs can be received by shortwave radios? Shortwave signal propagation is subject to the influence of many factors, such as sunspot If in China, in shortwave radio programs, the Mandarin, activity, atmosphere and earth-ionosphere change.
- Page 20 ○ ⑩ How to test the effect of an Must the external antenna be very high and long? external antenna? In a general listening environment, In short, shortwave external antenna will get better effect if it is high and long. But, higher and longer antenna doesn’t turn the radio to a relatively weak imply better effect.
- Page 21 ○ ○ How to reduce the interference of Shortwave radio Shortwave is transmitted mainly relying on the reflection Shorten the lever, change the direction of the and refraction between ionosphere and the ground, antenna, change the listening position, and keep regardless of day and night.
- Page 22 ○ ○ Why more radio stations received at night than that of the daytime? What factor will affect broadcasting reception effect? Medium wave propagation mainly relies on the ground wave. Only a small amount of medium wave is transmitted The reception environment is the main factor that affects by relying on sky wave.
- Page 23 FCC Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
