Summary of Contents for Streamit SAS310
-
Page 1: User Manual
SAS310 User Manual for software version 1.0 Updated on 9/4/2017... -
Page 2: Table Of Contents
2. Installation 2.1 Included materials ..............................6 2.2 Requirements ..............................6 2.3 Connecting the SAS310 to the audio system ..............................6 2.4 Connecting the SAS310 to the power outlet ..............................7 2.5 Connecting the SAS310 to the network ..............................7 3. - Page 3 15.2 The SAS310 makes a downward sound ..............................32 15.3 There is no audio in the stream ..............................32 15.4 The configuration interface of the SAS310 is not available ..............................32 15.4.1 Using the on-board DHCP server ................................33 SAS310...
-
Page 4: Eu Declaration Of Conformity
2. this device must accept any interference received, including interference that may cause undesired operation. The Streamit internet radio device does not contain any user-serviceable parts. Repairs should be made only by an authorized Streamit service center. Unauthorized repairs or modifications could result in permanent damage to the equipment, and void your warranty and your authority to operate the device under Part 15 regulations. -
Page 5: Version Information
Version information This manual applies to SAS310 firmware version 1.0.0. SAS310... -
Page 6: Installation
Connecting the SAS310 to the audio system Connect the Behringer UCA222 to one of the USB ports on the back of the SAS310. Connect the signal from the audio installation to the input ports on the Behringer UCA222. SAS310... -
Page 7: Connecting The Sas310 To The Power Outlet
This is available from Streamit. Connecting the SAS310 to the power outlet Plug the power cord into the power outlet and plug the other end of the cord into the SAS310. Take the following into account when connecting the SAS310 to the power outlet: ·... -
Page 8: The Configuration Interface
The configuration interface The SAS310 has a configuration interface that consists of a number of web pages to setup e.g. the stream and recording settings. The configuration interface is accessible by navigating in a browser to the IP address of the SAS310: http://<SAS310 IP address>. You can find this IP address in the device register http://register.streamit.eu/sas... -
Page 9: Configuration Via A Server
The use of 'self-signed' certificates is not supported. It is possible to set up your own configuration server. However, this requires considerable technical know- how. The format in which the configuration must be served to the SAS310 is documented in the SAS310 - Technical Manual. -
Page 10: Configuring The Sas310
Network settings You can configure the IP address of the SAS310 on this page. At the bottom of the page the currently used IP address and the Ethernet MAC address are shown. We recommend you to have an IP address automatically assigned to the SAS310 (DHCP), this is the default setting of the SAS310. -
Page 11: Stream Settings
You will find an overview of the different options with a short explanation. Irrelevant options are automatically hidden in the configuration interface of the SAS310. You should therefore always fill in all fields, unless you are very sure that you can leave the field empty. -
Page 12: Download And Upload Stream Settings
This is provided by your streaming service provider (not for internal icecast-2 server). Play sound on error Set how often the SAS310 makes a downward series of tones when internet- or server problems occur: Never, once, or every ten seconds. -
Page 13: Recording Settings
Recording settings The SAS310 can make a recording to its internal storage. This is called "local recording". How local recording works and which requirements apply, is documented in Recording to internal storage. Here, the corresponding settings interface is discussed. Below the recording settings, a list of the available recordings on the internal storage is shown. These can be clicked to download the recordings from the internal storage. - Page 14 Higher bit rates result in less recording time available on the local storage. Free space Free space on the local storage, in megabytes Total space Total size of the local storage, in megabytes SAS310...
-
Page 15: Miscellaneous Settings And Functions
The time on the SAS310 can be changed by clicking 'synchronize' under the heading 'Date and Time Settings'. The URL of the time server with which the SAS310 will be synchronized can be given in the field 'Time Server'. Click on 'set' to make this setting active. -
Page 16: Username And Password For The Configuration Interface
Daily reboot 5.4.4 When using the SAS310 for a long time, it is recommended to reboot the SAS310 once every 24 hours. You can do this automatically by entering a time in the field 'Daily reboot time'. The restart of the SAS310 takes approximately 1 minute. -
Page 17: Device Name
URL. This name is sent to the device register as soon as you click on 'set' and each time the SAS310 starts If no name is set, but the SAS310 streams to a predefined platform, the stream name will be sent as the device name. -
Page 18: Manually Choose And Install Firmware
'open' · Click on 'upload' to load and execute the firmware on the SAS310 The SAS310 will install the new firmware and reboot. You are automatically redirected to the Streamit device register. Do not switch off the SAS310 during firmware update, this process must not be interrupted... -
Page 19: Testing The Sas310
Testing the SAS310 To test the SAS310, you must first plug it in. Then, while on the same local network as the SAS310, go to the Streamit device register (http://register.streamit.eu/sas) using a PC or tablet. The SAS310 should be listed there after at most one minute. If the SAS310 does not appear in the device register, the... -
Page 20: Viewing The Status Of The Sas310
Viewing the status of the SAS310 There are three LEDs on the front of the SAS310: Left: Power Middle: Streaming Right: Recording SAS310 is powered on Stream running SAS310 makes a normally recording SAS310 is powered off No stream configured... - Page 21 This indicates for how long the SAS310 is on already KiloBytes sent Amount of bytes sent to the network CPU load The load of the processor of the SAS310 at that moment CPU temperature The temperature of the processor of the SAS310 at that moment Software Version...
- Page 22 This depends on the bit rate that is configured for the stream. Higher bit rates result in less recording time available on the local storage. Status Status of the recording of the audio stream SAS310...
-
Page 23: Recording To Internal Storage
100% of the time. In particular the following two issues should be taken into consideration: · There is a small chance that a recording is not made when the SAS310 starts, a restart will fix this (this happened with 1 specific device/piece of hardware, chance of 1 in 300) ·... -
Page 24: Start And Stop The Recording
It is not a problem if the SAS310 is still recording when it is turned off, the recording will still be saved. There is a very small chance that a recording gets corrupted when the power is removed from the... -
Page 25: Switching Off The Sas310
Switching off the SAS310 The SAS310 can only be turned off by unplugging the power cord or using a timer or a central power switch, for example as part of an installation that is switched on and off with a single switch. -
Page 26: Restoring To Factory Default Settings
The factory default settings are loaded now, but not yet saved. If you restart the SAS310 without saving settings, nothing has changed and the old settings will still be active. When you no longer have access to the SAS310, you can also follow the steps as described in configuration interface of the SAS310 is not accessible. -
Page 27: Updating The Firmware
SAS310. If you want this, you need to change the setting 'Firmware update' to 'Automatic'. Leave this setting to 'On manual trigger', if you always want to make a decision whether or not to update the SAS310 to the version that is available on the firmware update server. -
Page 28: Update From Usb Storage
SAS310 is updated. Take note of the following: · Connect only 1 USB storage device to the SAS310 at any time. A second USB storage device will not be detected. · Do not change the name of the firmware update file ·... -
Page 29: Device Register
SAS310 By default the SAS310 register will show only devices that have registered in the past 24 hours. If the SAS310 is on for a longer period of time, click on the button 'Show registered anytime' to see devices that have registered any time in the past. -
Page 30: Specification
Specification General Audio encoder Stereo MP3 Sample frequency 11 - 44.1Khz Bit rate (max) 256kbps Ethernet controller 100/1000 Mbps Power adapter 100 - 240VAC/12Vdc - 2A Configuration interface English SAS310... -
Page 31: Streamit Support
Streamit support With this manual we have tried to make the working of the SAS310 as clear as possible. We can imagine, however, that you may come across a question or problem that is not covered. In that case we recommend to check if there is information on this topic on the Streamit website: https://www.streamit.eu. -
Page 32: Troubleshooting
15.4 The configuration interface of the SAS310 is not available There is a number of potential causes, for example the SAS310 may have a static IP address which is not valid or configured incorrectly. SAS310... -
Page 33: Using The On-Board Dhcp Server
Using the on-board DHCP server 15.4.1 The SAS310 has a DHCP server on board which is coupled to the LAN2 connector. You can use this by connecting an Ethernet cable to the LAN2 connection on the SAS310 an putting the other end of the network cable directly in your PC (most modern operating systems can handle this). - Page 34 © 2017 Streamit B.V.
