Table of Contents
Advertisement
Quick Links
1
Model--------------------------------------------------- 6
2
Features------------------------------------------------ 6
3
Specifications----------------------------------------- 7
4
Standard Accessories------------------------------- 8
5
simply operation------------------------------------- 8
6
Appearance and function--------------------------9
6.1
LCD Screen--------------------------------------9
6.2
Function---------------------------------------- 10
7
Operation-------------------------------------------- 11
7.1
Turn on/off--------------------------------------11
7.2
Absolute power measurement---------------11
7.3
Relative power test--------------------------- 12
7.4
User self-calibration function-------------- 12
7.5
Auto off function------------------------------ 13
7.6
Replace battery--------------------------------13
8
Maintenance-----------------------------------------14
9
Problems--------------------------------------------- 14
10
Warranty notice------------------------------------ 15
Handheld Optical Power Meter V1.0
CONTENTS
3
Advertisement
Table of Contents
Summary of Contents for Sunwin EF-200
-
Page 1: Table Of Contents
Handheld Optical Power Meter V1.0 CONTENTS Model--------------------------------------------------- 6 Features------------------------------------------------ 6 Specifications----------------------------------------- 7 Standard Accessories------------------------------- 8 simply operation------------------------------------- 8 Appearance and function--------------------------9 LCD Screen--------------------------------------9 Function---------------------------------------- 10 Operation-------------------------------------------- 11 Turn on/off--------------------------------------11 Absolute power measurement---------------11 Relative power test--------------------------- 12 User self-calibration function-------------- 12 Auto off function------------------------------ 13 Replace battery--------------------------------13 Maintenance-----------------------------------------14... - Page 2 Handheld Optical Power Meter V1.0 WARNING Security rules： To protect the instrument from being damaged, do not use under the high temperature, high pressure, wet or other prohibited condition. Do not personally take apart or repair the instrument. Quality assurance: We assure that each unit meets the declared specification.
- Page 3 Handheld Optical Power Meter V1.0 Handheld optical power meter manual...
-
Page 4: Model
Handheld Optical Power Meter V1.0 Model A)measurement range: -70~+10dBm，calibrated wavelength： 850nm、1300nm、1310nm、1490nm、 1550nm、1625nm B) measurement range: -50~+26dBm，calibrated wavelength： 850nm、1300nm、1310nm、1490nm、 1550nm、1625nm 2 Features High measurement accuracy and display resolution Quick response and measurement: when power changing, it can track and real-time display the output power ... -
Page 5: Specifications
Handheld Optical Power Meter V1.0 3 Specifications -70～+10 dBm -50～+26 dBm Measurement range dBm Other range is on request Wavelength 800～1650 range（nm） 850nm 、 1300nm 、 1310nm 、 Calibrated 1490nm 、 1550nm 、 1625nm wavelength （optional other wavelength） Detector InGaAs Accuracy <±3% （-10dBm、22℃）... -
Page 6: Standard Accessories
Handheld Optical Power Meter V1.0 4 Standard Accessories power meter…………………………………1 pouch ………………………………1 manual ………………………………1 battery(AAA, transportation permit) ………3 certificate ………………………………1 5 simply operation ON/OFF: press it for a few seconds to turn it on/off .click to turn on/off back light， λ:switch the wavelength dB: press 2 seconds to enter the relative measurement mode. -
Page 7: Appearance And Function
Handheld Optical Power Meter V1.0 6 Appearance and function LCD Screen interface Model Wavelength unit value battery level Auto-off ON/OFF Wavelength select Relative dBm/w power absolute Test power test Wavelength ： display the wavelength, such as 850nm、1300nm、1310nm、1490nm、1550nm and... -
Page 8: Function
Handheld Optical Power Meter V1.0 1625nm； Power value： it displays the current output power under absolute test mode it displays the difference between the current output power and reference power under relative test mode Unit：mW、uW、nW、dBm、dB Relative test：press dB to start relative test Auto-off：activate the 10-minute auto off function Battery level：real-time indicate the battery level. -
Page 9: Operation
Handheld Optical Power Meter V1.0 B) Reference value storage：when enter the relative test, press dB for 2 seconds to save the current absolute power value as REF value and show the relative power value in dB unit c) Enter the relative test and save current reference value: under the absolute test mode, press dB for 2 seconds to enter the absolute test mode and save the current value as reference... -
Page 10: Relative Power Test
Handheld Optical Power Meter V1.0 close one from the power meter. Press dBm/W to choose the display unit. the default wavelength is 1310nm and working mode is dBm. Then the power meter will show the test power value. Relative power test ... -
Page 11: Auto Off Function
Handheld Optical Power Meter V1.0 Take out the battery and pull up the switch 1 to “ON” position. battery back battery compartment and turn on the unit to choose the wavelength for calibration. Now connect it with pigtail and press REF or dBm/W to increase or decrease the data by 0.05dB. -
Page 12: Maintenance
Handheld Optical Power Meter V1.0 8 Maintenance keep all optical connectors and surfaces free from oil, dirt or other contamination to ensure proper operation. Keep using the same type of connector Please cover the dust cap when not in use to keep the connector clean. -
Page 13: Warranty Notice
Handheld Optical Power Meter V1.0 10 Warranty notice Warranty Period： It is within 18 months from the date of purchase Warranty clause： 一、Under the warranty, we would repair the problems caused under the normal operation free of charge. Note: remember to show us the warranty card when repair 二、For the following situation, we have to charge certain cost：... - Page 14 Handheld Optical Power Meter V1.0 Quality certificate Product name：handheld optical power meter Product model： Serial number： Date of production： Inspection ： Warranty card Date of purchase： Customer name： Customer address： Customer phone： Distributor name： Distributor phone； Posted back to：...
