netsys NC-11DF User Manual

1 megapixel indoor dome ip camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1
M
e
g
a
p
i
x
e
l
I
n
d
1
M
e
g
a
p
i
x
e
l
I
n
d
1
M
e
g
a
p
i
x
e
l
I
n
N
C
-
1
1
D
F
N
C
-
1
1
D
F
N
C
-
1
1
D
F
o
o
r
D
o
m
e
I
P
o
o
r
D
o
m
e
I
P
d
o
o
r
D
o
m
e
I
P
U
S
E
R
'
S
M
A
U
S
E
R
'
S
M
A
U
S
E
R
'
S
M
A
C
a
m
e
r
a
C
a
m
e
r
a
C
a
m
e
r
a
N
U
A
L
N
U
A
L
N
U
A
L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NC-11DF and is the answer not in the manual?

Questions and answers

Summary of Contents for netsys NC-11DF

  • Page 1 ’ ’ ’...

  • Page 2: Copyright

    CAUTION：TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The NC-11DF is for indoor applications only. This product does not have waterproof protection, please do not use in outdoor applications.

  • Page 3: Table Of Contents

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Table of Contents Copyright................................1 Foreword ................................4 Chapter 1. Package Contents ..........................5 Check List..................................5 Chapter 2. Product Specifications........................7 Chapter 3. Product Installation ........................11 3.1 Monitor Settings................................. 11 3.2 Hardware Installation .................................
  • Page 4 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Chapter 8. Factory Default ..........................93 Chapter 9. Universal Password ........................95 Appendix A. Micro SD Card Compatibility (Optional) ..................99 Appendix B: Compliance Information ......................100 Warranty ................................103...

  • Page 5: Foreword

    Foreword NC-11DF is a 1 / 2.7” 1 Mega-Pixel CMOS sensor IP camera with a built-in web server. The user can view real-time video via IE browser. It supports H.264 and M-JPEG video compression, providing smooth and high video quality. The video can be stored in Micro SD card and playback remotely.

  • Page 6: Chapter 1. Package Contents

    5. Please scan the following QR code to view the NV-202 and NV-202P user’s manual. 6. If user only purchase NC-11DF, the accessory only contain 2 x Wall plug and 2 x Screw.
  • Page 7 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 NV-202 user’s manual NV-202P user’s manual...

  • Page 8: Chapter 2. Product Specifications

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Chapter 2. Product Specifications Main Features Supports Real Time HD 720P Digital Wide Dynamic Range Adjustable Shutter Speed 3D+2D Digital Noise Reduction Adjustable Sense Up Day & Night Manual Switch Time Control...
  • Page 9 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Hardware Multimedia SoC 128MB 16MB Flash ROM 1 / 4” Mega-Pixel CMOS sensor Image Sensor Color : 0.2 Lux (AGC ON) Sensitivity B / W: 0.1 Lux (AGC ON) 2.8mm @ F1.8 Lens Type 77.79°(H), 49.55°(V)
  • Page 10 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Dimensions 100mm (∅) x 49mm (H) Weight 180g IR LEDs LEDs 6 LEDs, 850nM, IR distance Network Ethernet 10/ 100 Base-T IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP, Access list, IEEE 802.1X, RTSP, TCP/ IP,...
  • Page 11 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Triggered Action Mail, FTP, Save to SD card, SAMBA, DO Pre/ Post Alarm Yes, configurable Password protection, IP address filtering, HTTPS encrypted data transmission, 802.1X Security port-based authentication for network protection, QoS/DSCP...

  • Page 12: Chapter 3. Product Installation

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Chapter 3. Product Installation 3.1 Monitor Settings Step1 Right-Click on the desktop. Select Properties Step2 Change color quality to highest (32bit).

  • Page 13: Hardware Installation

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 3.2 Hardware Installation 1. Dome Installation Steps...
  • Page 14 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 a. Open the dome by pressing the two sides shown in the following pictures: b. Use screws to place the bottom of camera to the ceiling or the wall. Do not lock it completely because you might need to...
  • Page 15 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 c. Unscrew the lens for adjust the angle. d. After adjusting the lens tight the screw. Repeat steps b & C as many times you need during the whole process.
  • Page 16 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 g. After finishing performing steps b & C close tight the screws on for locking the dome into the ceiling. h. Close the dome cover. 2. Connectors The camera connectors are as below.
  • Page 17 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 3. PoE ( Power Over Ethernet)(Optional) 802.3af, 15.4W / 802.3at, 30W max. *NV-202P is recommended Power over Ethernet (PoE) is a technology that integrates power into a standard LAN infrastructure. It enables power to be provided to a network device, such as an IP phone or a network camera, using the same cable as that used for network connection.
  • Page 18 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Figure 3.1 NV-202P KIT and IP-Camera applications...

  • Page 19: Ip Assignment

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 3.3 IP Assignment Use the software IP Installer to assign the IP address of the IP Camera. User can download the software via http://www.netsys.com.tw/support/download.html IP installer supports two languages: IPInstallerCht.exe：Chinese version IPInstallerEng.exe：English version...
  • Page 20 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 IP Installer configuration:...
  • Page 21 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 IP Installer will search for all the IP Cameras connected on the LAN. The user can click Search Device to search again. Click one of the IP Cameras listed on the left side. The network configuration of this IP camera will be shown on the right side.
  • Page 22 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 PC IP address: 192.168.1.100 To Change the PC IP address: Control Panel Network Connections Local Area Connection Properties Internet Protocol (TCP/IP) Properties Make sure your IP Camera and PC are int the same Subnet. If not, change the IP Camera subnet or the PC IP subnet accordingly.
  • Page 23 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 11. Then, key-in the default user name: admin and password: admin.

  • Page 24: Install Activex Control

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 3.4 Install ActiveX Control 1. For users of IE 6.0 or above: When viewing the camera video for the first time via IE, the browser will ask you to install the ActiveX component.
  • Page 25 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2...
  • Page 26 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 When popup the following dialogue box, click “Yes”.
  • Page 27 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 2. You can choose another way: Go to: IE→Tools → Internet Options… → Security Tab → Trusted sites → Add the IP address and click OK. In the site list you can key one single IP address or a LAN address. For example, if you add 192.168.21.*, all the IP address...
  • Page 28 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 2. To Non-IE Web Browser Users If you use Firefox or Google chrome to access the IP camera but fails to watch the live video, please follow the steps to install necessary tools: (The following pictures are based on chrome.)
  • Page 29 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 In the pop-up window, please tick the first and the third file as the picture below. Click Next to download both Microsoft .NET Framework 4 Client Profile (Web Installer) and Microsoft Visual C++ 2010 Redistributable Package (x64).
  • Page 30 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 After finishing downloading, execute the two files respectively to install them. The windows may ask you to reboot the PC when the installation is finished.
  • Page 31 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 b. Then, click the second link Please click here to download the installation program which does not support IE browser to download Setup ActiveX. After finishing downloading, execute the files to install ActiveX. Then restart the browser.
  • Page 32 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Delete all the files named np_hoem_x.dll. They're the ActiveX control tools installed in your computer, but the old version of ActiveX might not be compatible with the new version of the browser. Therefore, they need to be deleted in order to install...
  • Page 33 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Start your web browser, and repeat the step 2-b: Download the installation program which does not support IE browser to download and install ActiveX.

  • Page 34: Chapter 4. Live Video

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Chapter 4. Live Video Start an IE browser, type the IP address of the IP camera in the address field. It will show the following dialogue box. Key-in the user name: admin and password: admin.
  • Page 35 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Get into the administration page. Video Snapshot. Show the system time, video resolution, and video refreshing rate. Adjust image: 1/2x, 1x, 2x. Streaming source: If the streaming 2 is closed, this function will not be displayed.
  • Page 36 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Shows how many people are connected to this IP camera. Control the relay output connected to this camera. Double-clicking on the video will change the view to full screen mode. Press Esc or double-click the video again for changing back to normal mode.
  • Page 37 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Frame Buffer Sec: This function builds a temporary buffer to accumulate several video frames. This function can make video smooth-going when the Network speed is slow and lag. If you select 100, the camera plays video 100 mSec after receiving images from camera.

  • Page 38: Chapter 5. Camera Configuration

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Chapter 5. Camera Configuration Click to get into the administration page. Click to go back to the live video page...

  • Page 39: System

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 5.1. System I. System Information a. Server Information: Set up the camera name, select language, and set up the camera time. 1. Server Name: This is the Camera name. This name will be shown on the IP Installer.
  • Page 40 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Moreover, click Text Edit for changing the OSD content, including text size and alpha. Finally, click the Upgrade button to keep the settings. c. Server time setting: Select between the options NTP, Synchronize with PC’s time, Manual, The date and time remain...
  • Page 41 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 II. User Management The IP Camera supports three different users: administrator, general, and anonymous user.
  • Page 42 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 a. Anonymous User Login: Select “Yes” for allowing everybody to watch live video without username and password. However, if you try to enter the configuration page the camera will ask you to key-in the username and password.
  • Page 43 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 c. Add user Type the user name and password, then click Add/Set. The guest user can only browse live video page and is not allowed to enter the configuration page.
  • Page 44 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 III. System update a. To update the firmware online, click Browse… to select the firmware. Then click Upgrade to proceed. b. Reboot system: re-start the IP camera c. Factory default: delete all the settings of this IP camera.

  • Page 45: Network

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 5.2. Network Click to get into the administration page. Click to go back to the live video page.
  • Page 46 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Advanced IP Settings IP Assignment The IP Camera supports DHCP and static IP a. DHCP: The IP Camera will get all the network parameters automatically. b. Static IP: Type-in the IP address subnet mask, gateway, and DNS.
  • Page 47 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 IPv6 Assignment By enabling DHCPv6 you can configure the following IPv6 address settings: Manually setup the IPv6 address: Key-in the Address, Gateway, and DNS. DHCPv6: If you have a DHCPv6 server, enable it to assign the IPv6 automatically. The assigned IP address will be displayed beside the column.
  • Page 48 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 a. Port Assignment: The user might need to assign a different port to avoid conflicts when setting up the IP. b. Web Page Port: setup the web page connecting port and video transmitting port (Default: 80) c.
  • Page 49 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 accessing the IP Camera from the Internet; this option allows the IP UPnP Port Forwarding ： E nable UPnP Port Forwarding for Camera to open ports on the router automatically so that video streams can be sent out from a LAN. There are three external ports for being set: Web Port, Http Port and RTSP port.
  • Page 50 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 4. Now the IP device is displayed under the LAN. Double-click the icon to access the camera via web browser. To disable the UPnP, click Hide icons for networked UPnP devices in the tasks column.
  • Page 51 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 RTSP setting If you have a media player that supports RTSP protocol, you can use it to receive video streaming from the IP camera. The RTSP address can be set for two streaming respectively.
  • Page 52 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Multicast Setting (Based on the RTSP Server) Multicast is a bandwidth conservation technology. This function allows several users to share the same packet sent from the IP camera. For using Multicast, appoint here an IP Address and port. TTL means the life time of packet, the larger the value is, the more users can receive the packet.
  • Page 53 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 1. Choose your ONVIF version and settings Under ONVIF connection, the video will be transmitted by RTSP. Be sure to enable the RTSP server in IP setting, otherwise the IP Camera will not be able to receive the video via ONVIF.
  • Page 54 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 The Bonjour function on Safari browser doesn't support HTTPS protocol. If on the camera you select https, the camera will appear on Safari's bookmarks but it cannot be accessed Take as a reference the following image:...
  • Page 55 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 LLTD If your PC supports LLTD, enable this function for allowing checking the connection status, properties, and device location (IP address) in the network map. If the computer is running Windows Vista or Windows 7, you can find LLTD through the path:...
  • Page 56 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 II. Advanced a. Https (Hypertext Transfer Protocol Secure When the users access cameras via Https protocol, the transmitted information will be encrypted, increasing the security level. Select the connection type: Http: the user can access the camera via the Http path but cannot access it via the Https path.
  • Page 57 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 certificate of that domain and verify its trustiness and security. Certificate generation process: Remove the existing certificate: Before you generate a new certificate, please remove the installed one. Select the Http...
  • Page 58 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Created Request: Fill-in the following form and click apply. After generating a certificate request, if you choose to turn it and verified by a trusted third-party, click Content and copy all the request content.
  • Page 59 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 According to the certificate source, there are two ways to install the certificate: If you had sent the certificate request for signing and receiving a signed certificate, click browse and find the certificate file in your computer.
  • Page 60 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 After finishing the installation, click on Content to call out and check the certificate content To use Https to access the camera, open your browser, and key-in https:// (IP address)/ in the address bar. Now your data will be transmitted via encrypted communications.
  • Page 61 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 b. SNMP (Simple Network Management Protocol) SNMPv1 or SNMPv2: write the name of both Write Community and Read Community. 2. SNMPv3: Set the Security Name, Authentication Type, Authentication Password, Encryption Type, Encryption...
  • Page 62 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Enable SNMPv1/SNMPv2 Trap for detecting the Trap server Please set what event needs to be detected. Cold Start: The camera starts up or reboots. Setting changed: The SNMP settings have been changed.
  • Page 63 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 d. QoS/DSCP(Quality of Server/Differentiated Services Code-point): DSCP specifies a simple mechanism for classifying and managing network traffic; and provide QoS on IP networks. DSCP is a 6-bit in the IP header for packet classification purpose. Please define it for Live Stream, Event / Alarm and...
  • Page 64 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 e. IEEE 802.1x: IEEE 802.1x is an IEEE standard for port-based Network Access Control. It provides an authentication mechanism to a device on a LAN or WLAN. The EAPOL protocol support service identification and optional point to point encryption over the local LAN segment.
  • Page 65 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 III. PPPoE & DDNS...
  • Page 66 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 a. PPPoE: Select Enabled to use PPPoE. Key-in the the Username and password for VDSL connection. Send mail after dialed: When connected to the internet, the camera will send a mail to a specific mail account.
  • Page 67 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Enable this service. Key-in the username. IP schedule update. Default: 5 minutes. Click Apply. DDNS Status Updating: Information update Idle: Stop service. DDNS registration successful, can now log by http://<username>.ddns.camddns.com: Register successfully.
  • Page 68 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 To send out the video via mail of FTP, please set up the configuration.
  • Page 69 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Samba Select this option to send the media files via a neighbor network when an event is triggered. Click Apply to save the setting, then use Test button to test the server connection. A message box will tell you OK! if it works, and a test document will be created in the location.
  • Page 70 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2...

  • Page 71: A / V Setting

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 5.3. A / V Setting 1. Image Setting Please refer to the details below for image settings:...
  • Page 72 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 a. For security and privacy purposes, there are three areas that can be set up for privacy. Click the Area button first, and then drag an area on the above image. Remember to save your settings. The masked area will not be shown on both live view and recording image.
  • Page 73 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Option Shutter Time Range (sec.) Outdoor 1/33000 ~ Selected number in Sense-up Indoor NTSC: 1/120 ~ Selected number in Sense-up PAL: 1/100 ~ Selected number in Sense-up 1/30 1/33000 ~ 1/30...

  • Page 74: Event List

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 5.4. Event List The IP Camera provides multiple event settings. 1. Event Setting a. Motion Detection To enable motion detection, tick Area 1/2/3. Click Area 1/2/3 in Area Setting, and draw an area on the preview screen.
  • Page 75 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 • Interval: For example, when selecting "10 sec", once the motion is detected and the action is triggered, it cannot be triggered again within 10 seconds. • Based on the schedule: When the option box is ticked, only during the selected schedule time the motion detection is enabled.
  • Page 76 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Before Tampering Detection Tampering Triggered (Lens Covered) Before Tampering Detection Tampering Triggered (Glare) Before Tampering Detection Tampering Triggered (Camera Moved)
  • Page 77 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Interval: The tampering detecting interval. Take the diagram below as example. The interval is set for 30 second; the camera lens is covered during 10 - 40 sec. At time point B, the camera compares the view with time point A, and sends an alarm when it founds that the lens is covered.
  • Page 78 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 • JPEG Files (with Record Time Setting): This option is enabled when selecting JPEG video format in streaming 1 on Video Setting, this option can be enabled. Select this option to save several JPEG picture files. The successive picture files cover a period of time according to the value set in Record Time Setting.
  • Page 79 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 e. Network Dis-connected: The IP Camera will scan the network. The image will be record to the SD card after the IP Camera detects network dis-connected, if set Save to SD card.
  • Page 80 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 2. Schedule a. Schedule: After completing the schedule setup, the camera data will be recorded according to the schedule setup. b. Snapshot: After enabling the snapshot function; the user can select the storage position of the snapshot file, the interval time of the snapshot and the reserved file name of the snapshot.
  • Page 81 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 3. I/O Setting a. Input Setting: The IP Cam supports input and output. When the input condition is triggered the camera will trigger the relay; send video to mail addresses or /FTP server / SAMBA.
  • Page 82 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 b. Output Setting: The output mode affects the DO or relay out duration. ON/Off Switch: The camera triggers the external device and lasts for 10 seconds. You can turn off the alarm •...
  • Page 83 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Sort by System Logs, Motion Detection Logs and I/O Logs. In addition, System Logs and I/O Logs won’t lose data due to power failure. 5. SD Card a. Playback Insert t h e Micro SD card before using it. Make sure t o push the Micro SD card completely into the slot.
  • Page 84 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 b. SD Management When choosing The 1st day the recoding file will be kept for one day. The oldest file will be deleted if the Micro SD card is full.
  • Page 85 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Note : The use of the SD card will s l i g h t l y affect the operation of the IP Camera, such as affecting the frame rate of the video.
  • Page 86 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 (ii) Open FlashGet, select File → Import → Import list, and find the link list file you just saved. The file name may be called SD_list. (iii) FlashGet will show you the link list, and you can tick the files you want to copy to your PC. Give the directory path in the new download window, and remember to enable Login to Server: key in the IP Camera username and password.
  • Page 87 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 (iv) Click OK to start download. • FlashGet is a free software that can be downloaded from FlashGet official website. The example above is based on FlashGet ver.1.9.6.

  • Page 88: Chapter 6. Network Configuration

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Chapter 6. Network Configuration I. Configuration 1: a. Internet Access: NV-202 and NV-202P(Ethernet Extender) b. IP address: One real IP or one dynamic IP c. Only the IP Camera is connected to the internet.
  • Page 89 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 II. Configuration 2: a. Internet Access: NV-202 and NV-202P(Ethernet Extender) b. IP address: More than one real IP or one dynamic IP c. IP Camera and PC connect to the internet...

  • Page 90: Chapter 7. I/O Configuration

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Chapter 7. I/O Configuration I/O Connection a. Connect the G (GND) & DO pin to the external relay (buzzer) device. b. Connect the G (GND) & DI pin to the external trigger device.
  • Page 91 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 If you select N.O on Input sensor setting, when the switch contacts are opened, the camera input alarm will be triggered and will execute the action user has set, for example, send a snapshot to E-mail address.
  • Page 92 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 c. I/O PIN definition GND (Ground): Initial state is LOW DO (Digital Output): DC 5V DI (Digital Input): Max. 50mA, DC 5V 2. I/O Setup a. Click I/O Setting from the system setup page via IE, and check Out1 to enable I/O signal...
  • Page 93 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 b. Output Test After the external input and output hardware is installed, you can use the Relay Out bottom on the live video page to test if DO / Relay Out works.

  • Page 94: Chapter 8. Factory Default

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Chapter 8. Factory Default If you forget your password, please follow the steps to set back the IP Camera to its factory default state. • Remove the power and Ethernet cable. Open the dome and press and hold the button as shown in the picture below.
  • Page 95 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 • Release the button when the camera finishes booting. • Plug-in the Ethernet cable. Re-login the camera using the default IP (http://192.168.1.200), and user name: admin, password: admin.

  • Page 96: Chapter 9. Universal Password

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Chapter 9. Universal Password If you forgot the password of your IP camera, you can reset the camera to factory default, or follow the procedure below to generate a universal password.
  • Page 97 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Or, if you already know the IP address of camera: Open the web browser, key in http:// (IP address) /GetIPMAC.cgi and press enter. The IP address and MAC address will be displayed on browser.
  • Page 98 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 The universal username and password are generated from the IP address and MAC address you key-in, so if you change the camera IP address the universal password changes, too. Step4 Take the generated username and password.
  • Page 99 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2...

  • Page 100: Appendix A. Micro Sd Card Compatibility (Optional)

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Appendix A. Micro SD Card Compatibility (Optional) The following are the recommended Micro SD Cards: SDHC class4 16GB SDHC class4 32GB class4 16GB class4 32GB SDHC class6 Transcend SDHC class6...

  • Page 101: Appendix B: Compliance Information

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Appendix B: Compliance Information FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a computing device, pursuant to Part 15 of FCC rules.
  • Page 102 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 proper functioning of your equipment. If they do, you will be notified in advance in order for you to make necessary modifications to maintain uninterrupted service. This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs.
  • Page 103 NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 WEEE Warning To avoid the potential effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment, end users of electrical and electronic equipment should understand the meaning of the crossed-out wheeled bin symbol.

  • Page 104: Warranty

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Warranty The original product that the owner delivered in this package will be free from defects in material and workmanship for one year parts after purchase. There will be a minimal charge to replace consumable components, such as fuses, power transformers, and mechanical cooling devices.

  • Page 105: Chinese Sj/T 11364-2014

    NC-11DF 1 Megapixel Indoor Dome IP Camera User’s Manual Ver.A2 Chinese SJ/T 11364-2014 有 毒 有 害 物 质 或 元 素 部件名称 铅(Pb) 汞(Hg) 镉(Cd) 六价铬[Cr(VI)] 多溴联苯(PBB) 多溴二苯醚(PBDE) 结构壳体 ○ ○ ○ ○ ○ ○ 电路组 ○ ○ ○...
