Thunderbolt™ Product
ARC-8050
(Thunderbolt to 6Gb/s SAS RAID Storage)
User Manual
Version: 1.1
Issue Date: May, 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARC-8050 and is the answer not in the manual?

Questions and answers

Related Manuals for Thunderbolt ARC-8050

Summary of Contents for Thunderbolt ARC-8050

  • Page 1 Thunderbolt™ Product ARC-8050 (Thunderbolt to 6Gb/s SAS RAID Storage) User Manual Version: 1.1 Issue Date: May, 2013...

  • Page 2: Fcc Statement

    Manufacturer’s Declaration for CE Certification We confirm ARC-8050 has been tested and found comply with the re- quirements set up in the council directive on the approximation of the low of member state relating to the EMC Directive2004/108/EC. For...

  • Page 3: Table Of Contents

    2.3 Locations of the Storage Component ........14 2.3.1 Drive Tray LED Indicators ..........14 2.3.2 LCD Panel LED Indicators ..........15 2.3.3 Thunderbolt Port LED Indicators ........15 2.4 Setting Up RAID Storage ..........16 2.4.1 Software Installation ........... 16 2.4.2 Hardware Installation ..........
  • Page 4 4.5.2 Delete Raid Set ............42 4.5.3 Expand Raid Set ............43 4.5.4 Offline Raid Set ............44 4.5.5 Rename Raid Set ............44 4.5.6 Activate Incomplete Raid Set ........44 4.5.7 Create Hot Spare ............45 4.5.8 Delete Hot Spare ............46 4.5.9 Rescue Raid Set ............
  • Page 5 • Background Task Priority ..........61 • JBOD/RAID Configuration ..........62 • SATA NCQ Support ............62 • HDD Read Ahead Cache ..........62 • Volume Data Read Ahead ..........62 • HDD Queue Depth ............62 • Empty HDD Slot LED ............63 •...
  • Page 6 • NTP Sever Address ............73 • Time Zone ..............74 • Automatic Daylight Saving..........74 4.8.8 View Events/Mute Beeper ..........74 4.8.9 Generate Test Event ........... 74 4.8.10 Clear Events Buffer ........... 75 4.8.11 Modify Password ............75 4.8.12 Update Firmware ............. 76 4.9 Information ..............
  • Page 7 • Auto Declare Hot-Spare ..........100 • Auto Rebuilding ............101 • Adjustable Rebuild Priority ..........101 High Reliability ..............102 • Hard Drive Failure Prediction .......... 102 • Auto Reassign Sector ............ 102 • Consistency Check ............103 Data Protection ..............103 •...

  • Page 8: Introduction

    2 channels able to achieve the 10Gbps speeds flowing both ways simultaneously. A single Thunderbolt port supports hubs as well as a daisy chain of up to seven Thunderbolt devices. To improve bandwidth transmis-...
  • Page 9 RAID manager allows local or remote to access it from any standard internet browser via a out-of-band 10/100Mbits LAN port or in-band Archttp utility. ARC-8050 Thun- derbolt RAID storage also provides API library for customer to combine with its own monitor utility. The intelligent cooling con- tinuously adapts to environmental conditions by automatically controlling the speed of the cooling fans.
  • Page 10 INTRODUCTION 1.2 Features Controller Architecture • 800MHz Dual Core ROC processor • 1GB on-board DDR3-1333 SDRAM with ECC protection • Write-through or write-back cache support • Support 8 internal 6Gb/s SAS ports • Multi-RAID storage support for large storage requirements •...

  • Page 11: Raid Management

    INTRODUCTION Host Connection • Two Thunderbolt technology ports • Simultaneous bi-directional, 10Gbps transfers over a single cable • Dual-protocol support (PCI Express and DisplayPort) • Compatible with existing DisplayPort devices • Daisy-chaining devices RAID Management • Field-upgradeable firmware in flash ROM In-Band Manager •...

  • Page 12: Installation

    ARC-8050 RAID storage is packed inside an anti-static bag be- tween two sponge sheets. Remove it and inspect it for damage. If the ARC-8050 RAID storage appears damaged, or if any items of the contents listed below are missing or damaged, please contact your dealer or distributor immediately.

  • Page 13: Raid Storage View

    1. Disk Activity LED 4. Thunderbolt Port1 2. Disk Fault/Link LED 5. Thunderbolt Port2 3. LCD Panel with Keypad 6. Thunderbolt Port1 Link LED 7. Thunderbolt Port2 Link LED 8. System Fan1 9. LAN Port (For McRAID Web Manager) 10. Reset Button 11.

  • Page 14: Locations Of The Storage Component

    INSTALLATION 2.3 Locations of the Storage Component The following components come with LEDs that inform ARC-8050 RAID storage managers about the operational status. 2.3.1 Drive Tray LED Indicators Figure 2-1, Activity/Fault LED for ARC-8050 RAID Storage The following table describes the RAID storage disk drive tray LED behavior.

  • Page 15: Lcd Panel Led Indicators

    (3) status-indicating LEDs. The LEDs on the front panel are defined, from top to bottom, Power, Busy, and Caution, as shown in Figure 2-2. Figure 2-2, LCD Panel LED for ARC-8050 RAID Storage The following table provides a summary of the front panel LED. Panel LED...

  • Page 16: Setting Up Raid Storage

    6Gb/s SAS RAID storage. 2.4.1 Software Installation To install the ARC-8050 driver and software into the existing operating system. Driver is required for the operating system to be able to interact with the ARC-8050 RAID storage. Windows users must firstly install drivers on their computer in order to use the Thunderbolt connection.
  • Page 17 In this scenario, you are installing the RAID storage in an existing Windows system. This section describes detailed instructions for installing the Windows driver & utility for the ARC-8050. You can use the installer to install driver & Archttp at once or “Custom” to install special components.
  • Page 18 6. Normally ArcHTTP and CLI are installed at the same time on ARC-8050. Once ArcHTTP and CLI have been installed, the archttp background task automatically starts each time when you start your computer. There is one MRAID icon showing on your “Pro grams”...
  • Page 19 For Mac Thunderbolt capable system: This section describes detailed instructions for installing the Areca Mac driver & utility for the ARC-8050 on your Apple Thunderbolt capable machine. You must have administrative level permissions to install Areca Mac driver & utility. You can use the installer to install Areca Mac driver &...

  • Page 20: Hardware Installation

    SNMP traps notification. Refer to the Chapter 5 Archttp Configu- ration on ARC-8050 user manual, for details about the mail and SNMP traps configuration. • CLI (Command Line Interface) lets you set up and manage RAID controller through a command line interface.
  • Page 21 Thunderbolt connectors are provided on the back of the ARC-8050 RAID storage for connecting the array to Thunderbolt host and next Thunderbolt devices. There are two Thunderbolt connectors on the rear of ARC-8050 RAID storage. You can plug-in two host ports. 1. Direct connection to a Thunderbolt technology capable computer.
  • Page 22 A single Thunderbolt port supports hubs as well as a daisy chain of up to seven Thunderbolt devices on, including the Thunderbolt capable computer.
  • Page 23 ARC-8050 RAID storage. 2. ARC-8050 RAID storage will turn on automatically when host computer with the power on is received by the ARC-8050. It takes about 30 seconds to fully start up the RAID storage.

  • Page 24: Volume Setup

    2.4.3 Volume Setup After hardware installation, the SAS/SATA disk drives connected to the ARC-8050 must be configured and the volume set units initialized by the controller before they are ready to use by the system. With MRAID software installed on your host computer...

  • Page 25: Configure Volume Set

    2.4.3.1 Configure Volume Set ARC-8050 RAID storage is normally delivered with LCD pre-in- stalled. Your ARC-8050 RAID storage can be configured by using McRAID storage manager (launched by ArcHttp proxy server and LAN port) or LCD with keypad (refer to ARC-8050_LCD manual).

  • Page 26: Making Volume Sets Available To System

    If there is any RAID storage missed on the system start-up or plug-in on-lne, you can use the “Rescan Device” function. See chapter 4 on ARC-8050 user manual for information on cus- tomizing your RAID volumes using McRAID storage manager.

  • Page 27: Unmounting The Storage Volume

    The following steps show how to make any new disk arrays or independent disks accessible to Windows system. This procedure assumes that the ARC-8050 RAID storage hardware, driver, and Windows are installed and operational in your system. 1. Partition and format the new arrays or disks using “Disk Ad- ministrator”:...
  • Page 28 "Safely Remove Hardware and Eject Media" icon, and then, in the list of devices, click the Thunderbolt storage volume that you want to remove. Windows will display a notification telling you it's safe to remove the Thunderbolt storage volume.

  • Page 29: Summary Of The Installation

    "Reset" button 3 seconds to save energy. The RAID stor- age will maintain the daisy chain with other Thunderbolt devices even when the RAID storages have been powered down.
  • Page 30 Browser-Based Configuration” on ARC-8050 user manual. SNMP Manager Console Integration There are two ways to transport SNMP data on the ARC-8050 RAID storage: Out-of-Band built-in LAN interface or In-Band Thunderbolt interface. Enter the “SNMP Tarp IP Address“ option on the firm-...

  • Page 31: Hot-Plug Drive Replacement

    ARC-8050 RAID storage rebuild- ing will be processed automatically in the background. When a disk is hot swapped, ARC-8050 RAID storage may no longer be fault tolerant. Fault tolerance will be lost until the hot swap drive is sub- sequently replaced and the rebuild operation is completed.

  • Page 32: Archttp Configuration

    HTTP Port#: Value 1~65535. Display HTTP Connection Information To Console: Select “Yes" to show Http send bytes and receive bytes information in the console. Scanning PCI Device: Select “Yes” for ARC-8050 RAID storage unit. Scanning RS-232 Device: No. Scanning Inband Device: No.

  • Page 33: Mail (Alert By Mail) Configuration

    ArcHTTP Configuration • Mail (alert by Mail) Configuration: To enable the controller to send the email function, you need to configure the SMTP function on the ArcHttp software. To enable the RAID storage email sending function, click on the “Mail Con- figuration”...

  • Page 34: Snmp Traps Configuration

    ArcHTTP Configuration (2). Mail Address Configurations: Sender Name: Enter the sender name that will be shown in the outgoing mail. Ex: RaidController_1. Mail address: Enter the sender email that will be shown in the outgoing mail, but don’t type IP to replace domain name. Ex: RaidController_1@areca.com.tw.
  • Page 35 ArcHTTP Configuration When you open the SNMP traps configuration page, you will see the following settings: (1). SNMP Trap Configurations Enter the SNMP trap IP address. (2). SNMP System Configurations Community name acts as a password to screen accesses to the SNMP agent of a particular network device.

  • Page 36: Rescan Device Configuration

    ArcHTTP Configuration Note: Event Notification Table refer to Appendix D. After you confirm and submit configurations, you can use "Generate Test Event" feature to make sure these settings are correct. • Rescan Device Configuration: Let’s assume you’ve put all Areca RAID storages to a system. The Archttp scans the RAID storages on the system and create an individual RAID storage icon located on left column of the "Archttp Configurations"...

  • Page 37: Web Browser-Based Configuration

    WEB BROWSER-BASED CONFIGURATION 4. Web Browser-based Configuration If you need to use a RAID volume from ARC-8050 RAID storage unit, you must first create a RAID volume by using LCD or McRAID storage manager. This chapter shows you how to set up RAID volumes using the McRAID storage manager application on a computer with an ARC- 8050 RAID storage.

  • Page 38: Start-Up Mcraid Storage Manager From Local Administration (In-Of-Band)

    Name is “admin” and the Password is “0000”. • Start-up McRAID Storage Manager Through LAN Port (Out-of-Band) ARC-8050 RAID storage now offers an alternative means of com- munication for the Thunderbolt RAID storage – web browser- based McRAID storage manager program. User can access the...

  • Page 39: Raid Storage Mcraid Storage Manager

    Thunderbolt RAID storage and web browser-based McRAID storage manager, please connect the Thunderbolt RAID storage LAN port to any LAN switch port. The RAID storage has embedded the TCP/IP & web browser- based McRAID storage manager in the firmware. User can remote...

  • Page 40: Main Menu

    WEB BROWSER-BASED CONFIGURATION be displayed. To display volume set information, move the mouse cursor to the desired volume set number, then click it. The vol- ume set information will be displayed. To display drive information, move the mouse cursor to the desired physical drive number, then click it.

  • Page 41: Raid Set Functions

    WEB BROWSER-BASED CONFIGURATION can change the Raid Level, Capacity, Initialization Mode, and Stripe Size. A hot spare option is also created, depending on the exist configuration. Click the “Confirm The Operation” check box and click on the “Submit” button in the “Quick Create” screen, the RAID set and volume set will start to initialize.

  • Page 42: Delete Raid Set

    WEB BROWSER-BASED CONFIGURATION mode if you plan to roam this raidset between SAS RAID control- ler and SATA RAID controller. Note: To create RAID 30/50/60 volume, you need create multiple RAID sets firstly with the same disk numbers on each RAID set.

  • Page 43: Expand Raid Set

    WEB BROWSER-BASED CONFIGURATION 4.5.3 Expand Raid Set Instead of deleting a RAID set and recreating it with additional disk drives, the “Expand Raid Set” function allows the users to add disk drives to the RAID set that have already been created. To expand a RAID set: Select the “Expand Raid Set”...

  • Page 44: Offline Raid Set

    WEB BROWSER-BASED CONFIGURATION 4.5.4 Offline Raid Set This function is for customer being able to unmount and remount a multi-disk volume. All Hdds of the selected RAID set will be put into offline state, spun down and fault LED in fast blinking mode. User can remove those Hdds and insert new Hdds on those empty slots without needing power down the controller.

  • Page 45: Create Hot Spare

    WEB BROWSER-BASED CONFIGURATION tion to active the RAID set. After the user completes this function, the Raid State will change to “Degraded Mode” and start to work. To activate the incomplete the RAID set, click on the “Activate Raid Set” link. A “Select The Raid Set To Activate” screen is dis- played showing all RAID sets existing on the current controller.

  • Page 46: Delete Hot Spare

    WEB BROWSER-BASED CONFIGURATION a specific RAID set or Enclosure. When a disk drive fails in the RAID set or enclosure with a dedicated hot spare is pre-set, data on the disk drive is rebuild automatically on the dedicated hot spare disk. 4.5.8 Delete Hot Spare Select the target hot spare disk to delete by clicking on the ap- propriate check box.

  • Page 47: Volume Set Functions

    WEB BROWSER-BASED CONFIGURATION Caution: Please contact us to make sure if you need to use rescue function. Improperly usage may cause configuration corruption. 4.6 Volume Set Functions A volume set is seen by the host system as a single logical device. It is organized in a RAID level with one or more physical disks.

  • Page 48: Volume Name

    WEB BROWSER-BASED CONFIGURATION • Volume Name The default volume name will always appear as “ARC-8050- VOL”. You can rename the volume set providing it does not exceed the 15 characters limit. • Volume Raid Level Set the Raid Level for the volume set. Highlight the desired RAID level and from the available levels option.

  • Page 49: Initialization Mode

    Cache Mode The RAID storage supports “Write Through” and “Write Back” cache. • Full Volume Encryption ARC-8050 have featured with controller based hardware encryp- tion function. Controller based hardware encryption describes the encryption of data occurring at the disk array controller...

  • Page 50: Tagged Command Queuing

    Areca Technology. With this scramble process, no one can see and access into the hidden volume data without access key. ARC-8050 support 128- and 256-bit encryption keys using AES(a key size of 128, or 256 bits), or password (a vari- able key size).

  • Page 51: Scsi Channel/Scsi Id/Scsi Lun

    WEB BROWSER-BASED CONFIGURATION performance under multi-tasking operating systems. The Command Tag (Drive Channel) function controls the SAS command tag queuing support for each drive channel. This function should normally remain “Enabled”. “Disabled” this function only when using SAS drives that do not support command tag queuing.

  • Page 52: Delete Volume Set

    WEB BROWSER-BASED CONFIGURATION The new create volume set attribute allows user to select the Vol- ume Name, Raid Level, Capacity, Greater Two TB Volume Support, Initialization Mode, Stripe Size, Cache Mode, Tagged Command Queuing, and SCSI Channel/SCSI ID/SCSI Lun. Please refer to above section for details description of each item.

  • Page 53: Volume Growth

    WEB BROWSER-BASED CONFIGURATION click the “Confirm The Operation” check box and click the “Sub- mit” button to complete the action. The user can only modify the last volume set capacity. 4.6.4.1 Volume Growth Use “Expand Raid Set" function to add disk to a RAID set. The additional capacity can be used to enlarge the last volume set size or to create another volume set.

  • Page 54: Volume Set Migration

    WEB BROWSER-BASED CONFIGURATION 4.6.4.2 Volume Set Migration Migrating occurs when a volume set is migrating from one RAID level to another, when a volume set strip size changes, or when a disk is added to a RAID set. Migration state is displayed in the volume state area of the “RAID Set Hierachy”...

  • Page 55: Schedule Volume Check

    WEB BROWSER-BASED CONFIGURATION 4.6.6 Schedule Volume Check A volume check is a process that verifies the integrity of redun- dant data. To verify RAID 3, 5, 6, 30, 50 or 60 redundancy, a volume check reads all associated data blocks, computes parity, reads parity, and verifies that the computed parity matches the read parity.

  • Page 56: Download Volume Key File

    6.6.8 Download Volume Key File Get the key file which was generated by CLI “vsf genkey” com- mand or API code for your ARC-8050. You can follow below steps to download volume key file. 1. To download volume key file into the firmware, move the mouse cursor to “Download Volume Key file”...

  • Page 57: Modify Pass-Through Disk

    WEB BROWSER-BASED CONFIGURATION 4.7.2 Modify Pass-Through Disk Use this option to modify the pass-through disk attribute. The user can modify the Cache Mode, Tagged Command Queuing, and SCSI Channel/ID/LUN on an existing pass-through disk. To modify the pass-through drive attribute from the pass-through drive pool, move the mouse cursor bar and click on the “Modify Pass-Through”...

  • Page 58: Clone Disk

    WEB BROWSER-BASED CONFIGURATION the check box for “Confirm The Operation” and click the “Submit” button to complete the delete action. 6.7.4 Clone Disk Instead of deleting a RAID set and recreating it with larger disk drives, the “Clone Disk” function allows the users to replace larger disk drives to the RAID set that have already been created.

  • Page 59: Clone And Replace

    WEB BROWSER-BASED CONFIGURATION 6.7.4.1 Clone And Replace You can enlarge your logical drives by copying and replacing all member drives with drives of higher capacity. The existing data in the logical drives is copied onto the new drives, and then the original members are marked as “Offlined”.

  • Page 60: Activate Failed Disk

    WEB BROWSER-BASED CONFIGURATION 4.7.7 Activate Failed Disk It forces the current “failed” disk in the system to be back online. “Activate Failed Disk” function has no effect on the removed disks, because a “removed” disk does not give the controller a chance to mark it as “failure”.

  • Page 61: System Controls

    WEB BROWSER-BASED CONFIGURATION 4.8 System Controls 4.8.1 System Config To set the RAID system function, move the cursor to the main menu and click the “System Controls” link. The “Raid System Function” menu will show all items, and then select the desired function.

  • Page 62: Jbod/Raid Configuration

    WEB BROWSER-BASED CONFIGURATION • JBOD/RAID Configuration JBOD is an acronym for “Just a Bunch Of Disk”. A group of hard disks in a RAID box are not set up as any type of RAID configuration. All drives are available to the operating system as an individual disk.

  • Page 63: Empty Hdd Slot Led

    WEB BROWSER-BASED CONFIGURATION • Empty HDD Slot LED The firmware has added the "Empty HDD Slot LED" option to setup the fault LED light "ON "or "OFF" when there is no HDD installed. When each slot has a power LED for the HDD installed identify, user can set this option to "OFF".

  • Page 64: Disk Capacity Truncation Mode

    WEB BROWSER-BASED CONFIGURATION self re-inserted, it won’t trigger the degraded RAID array to re- build, and so that the administrator has a chance to identify this miss-behaving disk and replace it. “Always” – it is what it was before. Whenever a disk is inserted/ re-inserted whether new or previously existed, it always triggers a rebuilding for the Degraded RAID set/Volume.

  • Page 65: Smart Polling Interval

    WEB BROWSER-BASED CONFIGURATION “Alert Only”. The default is “Alert Only” “Failed The Drive”- controllers kill off the SMART fail drive imme- diately. “Failed The Drive If Hot Sapre Exist” – controllers kill off the SMART fail disk if hot sapre dive is existed. “Alert”...

  • Page 66: Timeout Setting

    WEB BROWSER-BASED CONFIGURATION is taking longer than time-out specifications allow. This prevents the RAID controller from dropping the drive from the array dur- ing this period. Default value is manufacture setting. You can select between 5, 6 and 7 second. This feature is used to setup the HDD internal timeout value.

  • Page 67: Number Of Av Stream

    WEB BROWSER-BASED CONFIGURATION however, thereby cutting down on the amount of I/O traffic to the disk. The Amount of Read Ahead defines how many data of reading at a time, making more efficient use of the RAID stor- age. This makes it possible to locate and re-issue the data with- out repetitive hard parsing activities.

  • Page 68: Read Performance Margin

    WEB BROWSER-BASED CONFIGURATION for read or write. The Mode 1, 2 and 3 are used to define the command sorting method. The default sorting method is helpful for normal applications, but not useful for AV applications, so we have defined three different sorting methods for these special applications.

  • Page 69: Stagger Power On Control

    WEB BROWSER-BASED CONFIGURATION • Stagger Power On Control In a PC system with only one or two drives, the power can sup ply enough power to spin up both drives simultaneously. But in systems with more than two drives, the startup current from spinning up the drives all at once can overload the power supply, causing damage to the power supply, disk drives and other sys- tem components.

  • Page 70: Sata Power Up In Standby

    WEB BROWSER-BASED CONFIGURATION • Time To Spin Down Idle HDD This function can automatically spin down the drive if it hasn’t been accessed for a certain amount of time. This value is used by the drive to determine how long to wait (with no disk activity, before turning off the spindle motor to save power).

  • Page 71: Dhcp Function

    WEB BROWSER-BASED CONFIGURATION • DHCP Function DHCP (Dynamic Host Configuration Protocol) is a protocol that lets network administrators manage centrally and automate the assignment of IP (Internet Protocol) configurations on a com- puter network. When using the internet’s set of protocols (TCP/ IP), in order for a computer system to communicate to another computer system, it needs a unique IP address.

  • Page 72: Telnet Port Number

    WEB BROWSER-BASED CONFIGURATION the default “HTTP Port Number” of the controller. • Telnet Port Number To manually configure the “Telnet Port Number” of the controller, move the cursor bar to “Telnet Port Number” item, then reassign the default “Telnet Port Number” of the controller. •...

  • Page 73: Snmp Configuration

    WEB BROWSER-BASED CONFIGURATION 4.8.6 SNMP Configuration Please refer to Appendix C of SNMP Operation & Installation. 4.8.7 NTP Configuration The Network Time Protocol (NTP) is used to synchronize the time of a computer client or server to another server or reference time source, such as a radio or satellite receiver or modem.

  • Page 74: Time Zone

    WEB BROWSER-BASED CONFIGURATION • Time Zone Time Zone conveniently runs in the system tray and allows you to easily view the date and time in various locations around the world. You can also quickly and easily add your own personal locations to customize time zone the way you want.

  • Page 75: Clear Events Buffer

    WEB BROWSER-BASED CONFIGURATION 4.8.10 Clear Events Buffer Use this feature to clear the entire events buffer information. 4.8.11 Modify Password To set or change the RAID storage password, select “System Con- trols” from the menu and click on the “Modify Password” link. The “Modify System Password”...

  • Page 76: Update Firmware

    WEB BROWSER-BASED CONFIGURATION ing password will be cleared. Then, no password checking will occur when entering the main menu from the starting screen. Note: The manufacture default password is set to 0000. 4.8.12 Update Firmware Please refer to the appendix A “Upgrading Flash ROM Update Pro- cess”.

  • Page 77: Sas Chip Information

    Chip Information” link. The RAID storage “SAS Chip Information” screen appears. User can click on “controller: Areca ARC-8050” item on the “SAS Chip Information” screen. It will show statistic page for ports on the ROC controller. Click on the “Clear Error Log” to refresh the fully statistic page.

  • Page 78: Hardware Monitor

    WEB BROWSER-BASED CONFIGURATION 4.9.4 Hardware Monitor The hardware monitor information of the enclosure attached in this controller is also shown on this screen.

  • Page 79: Upgrading Flash Rom Update Process

    Appendix A Upgrading Flash ROM Update Process A-1 Overview Since the ARC-8050 Thunderbolt RAID storage features flash ROM firmware, it is not necessary to change the hardware flash chip in order to upgrade the RAID firmware. The user can simply re- program the old firmware through the In-Band Thunderbolt port or Out-of-Band Ethernet port McRAID Storage manager.
  • Page 80 The web browser-based McRAID storage manager can be accessed through the in-band Thunderbolt port or out-of-band LAN port. The in-band method uses the ArcHttp proxy server to launch the McRAID storage manager. The out-of-band method allows local or...
  • Page 81 APPENDIX Controller with onboard LAN port, you can directly plug an Ethernet cable to the controller LAN port. After network connected, you can find the current IP address in the LCD panel. From a remote pc, you can directly open a web browser and enter the IP address.

  • Page 82: Battery Backup Module (Arc-6120Bat021)

    APPENDIX Appendix B Battery Backup Module (ARC-6120BAT021) ARC-8050 RAID storage operates using cache memory. The Battery Backup Module is an add-on module that provides power to the RAID storage cache memory in the event of a power failure. The BBM monitors the write back cache on the RAID storage, and pro- vides power to the cache memory if it contains data not yet written to the hard drives when power failure occurs.

  • Page 83: Installation

    APPENDIX B-3 Installation 1. Make sure all power to the RAID storage is disconnected. 2. Install the “six eaves copper pillars” on the three mounting position (NH1, NH2 and NH3) and secures it using round head screws. 3. Connector J2 is available for the optional battery backup module.
  • Page 84 APPENDIX B-4 Battery Backup Capacity Battery backup capacity is defined as the maximum duration of a power failure for which data in the cache memory can be maintained by the battery. The BBM’s backup capacity varied with the memory chips that installed on the RAID storage. B-5 Operation 1.
  • Page 85 • Operating Temperature Temperature: 0 C to +40 Humidity: 45-85%, non-condensing • Storage Temperature Temperature: -40 C to 60 Humidity: 45-85%, non-condensing • Electrical Input Voltage +3.6VDC • On Board Battery Capacity 1880mAH (1 * 1880mAH) for ARC-8050 RAID storage...

  • Page 86: Snmp Operation & Installation

    APPENDIX Appendix C SNMP Operation & Installation C-1 Overview McRAID storage manager includes a firmware-embedded Simple Network Management Protocol (SNMP) agent and SNMP Extension Agent for the Areca RAID controller. An SNMP-based management application (also known as an SNMP manager) can monitor the disk array.
  • Page 87 APPENDIX Manager Application Managed Resource Definition Service Layer and Protocols Physical Managed Object C-3 SNMP Installation Perform the following steps to install the Areca RAID control- ler SNMP function into the SNMP manager. The installation of the SNMP manager is accomplished in several phases: Step 1.
  • Page 88 Step 3. SNMP Service Method With Areca series RAID controllers, there are 2 service methods to get SNMP: in-band Thunderbolt port and onboard NIC. (1). Service Method-1: Using in-band Thunderbolt port (ArcHttp proxy server) Pay attention to these: •...
  • Page 89 APPENDIX manager using the IP address assigned to the operating system, such as Net-SNMP manager, you can simply use the SNMP function on the ArcHttp proxy server utility. To enable the RAID controller SNMP traps sending function, configure the “SNMP Traps Configuration”...
  • Page 90 APPENDIX The firmware-embedded SNMP agent manager monitors all system events and the SNMP function becomes functional with no agent software required. When you open the "SNMP Configuration" link, you will see the following settings: (1). SNMP Trap Configurations Enter the SNMP Trap IP Address. (2).

  • Page 91: Event Notification Configurations

    APPENDIX Appendix D Event Notification Configurations The controller classifies disk array events into four levels depend- ing on their severity. These include level 1: Urgent, level 2: Serious, level 3: Warning and level 4: Information. The level 4 covers notifica- tion events such as initialization of the controller and initiation of the rebuilding process;...

  • Page 92: Volume Event

    APPENDIX PassThrough Disk Inform Pass Through Disk Created created PassThrough Disk Inform Pass Through Disk Modified modified PassThrough Disk Inform Pass Through Disk Deleted deleted B. Volume Event Event Level Meaning Action Start Initialize Warning Volume initialization has started Start Rebuilding Warning Volume rebuilding has started Start Migrating...

  • Page 93: Raid Set Event

    APPENDIX C. RAID Set Event Event Level Meaning Action Create RaidSet Warning New RAID set created Delete RaidSet Warning Raidset deleted Expand RaidSet Warning Raidset expanded Rebuild RaidSet Warning Raidset rebuilding RaidSet Urgent Raidset degraded Replace HDD Degraded D. Hardware Monitor Event Event Level Meaning...
  • Page 94 APPENDIX Telnet Log Serious a Telnet login detected InVT100 Log In Serious a VT100 login detected API Log In Serious a API login detected Lost Rebuilding/ Urgent Some rebuilding/ Reinserted the missing member MigrationLBA migration raidset disk back, controller will member disks continued the incompleted missing before power...

  • Page 95: Raid Concept

    APPENDIX Appendix E RAID Concept RAID Set A RAID set is a group of disks connected to a RAID controller. A RAID set contains one or more volume sets. The RAID set itself does not define the RAID level (0, 1, 1E, 3, 5, 6, 10, 30, 50 60, etc);...

  • Page 96: Ease Of Use Features

    APPENDIX In the illustration, volume 1 can be assigned a RAID level 5 of operation while volume 0 might be assigned a RAID level 1E of operation. Alternatively, the free space can be used to create vol- ume 2, which could then be set to use RAID level 5. Ease of Use Features Foreground Availability/Background Initialization •...
  • Page 97 APPENDIX on the existing volume sets (residing on the newly expanded RAID set) is redistributed evenly across all the disks. A contigu- ous block of unused capacity is made available on the RAID set. The unused capacity can be used to create additional volume sets.

  • Page 98: Online Raid Level And Stripe Size Migration

    APPENDIX • Online RAID Level and Stripe Size Migration For those who wish to later upgrade to any RAID capabilities, a system with online RAID level/stripe size migration allows a simplified upgrade to any supported RAID level without having to reinstall the operating system. The RAID controllers can migrate both the RAID level and stripe size of an existing volume set, while the server is online and the volume set is in use.

  • Page 99: Online Volume Expansion

    APPENDIX migration is completed, the volume set transitions to degraded mode. If a global hot spare is present, then it further transitions to rebuilding state. Online Volume Expansion • Performing a volume expansion on the controller is the process of growing only the size of the latest volume. A more flexible op- tion is for the array to concatenate an additional drive into the RAID set and then expand the volumes on the fly.

  • Page 100: Hot-Swap Disk Drive Support

    APPENDIX data previously located on the failed drive is reconstructed on the hot spare. Dedicated hot spare is assigned to serve one specified RAID set. Global hot spare is assigned to serve all RAID set on the RAID controller. Dedicated hot spare has higher priority than the global hot spare.

  • Page 101: Auto Rebuilding

    APPENDIX tomatically assigned as a hot spare if any hot spare disk was used to rebuild and without new installed drive replaced it. In this condition, the Auto Declare Hot-Spare status will be disap- peared if the RAID storage has since powered off/on. The Hot-Swap function can be used to rebuild disk drives in arrays with data redundancy such as RAID level 1, 1E, 3, 5, 6, 10, 30, 50 and 60.

  • Page 102: High Reliability

    APPENDIX RAID controller allows user to choose the task priority (Ultra Low (5%), Low (20%), Medium (50%), High (80%)) to balance volume set access and background tasks appropriately. For high array performance, specify an Ultra Low value. Like volume ini- tialization, after a volume rebuilds, it does not require a system reboot.

  • Page 103: Consistency Check

    APPENDIX and that location will be tested by the drive to be certain the location is not defective. If it is found to have a defect, data will be automatically relocated, and the defective location is mapped out to prevent future write attempts. In the event of an unrecoverable read error, the error will be reported to the host and the location will be flagged as being potentially defective.

  • Page 104: Recovery Rom

    RAID controller firmware is stored on the flash ROM and is ex- ecuted by the I/O processor. The firmware can also be updated through the RAID controllers Thunderbolt port or Ethernet port without the need to replace any hardware chips. During the...

  • Page 105: Understanding Raid

    APPENDIX Appendix F Understanding RAID RAID is an acronym for Redundant Array of Independent Disks. It is an array of multiple independent hard disk drives that provides high performance and fault tolerance. The RAID controller imple- ments several levels of the Berkeley RAID technology. An appro- priate RAID level is selected when the volume sets are defined or created.

  • Page 106: Raid 1

    APPENDIX RAID 1 RAID 1 is also known as “disk mirroring”; data written on one disk drive is simultaneously written to another disk drive. Read performance will be enhanced if the array controller can, in paral- lel, access both members of a mirrored pair. During writes, there will be a minor performance penalty when compared to writing to a single disk.

  • Page 107: Raid 10(1E)

    APPENDIX RAID 10(1E) RAID 10(1E) is a combination of RAID 0 and RAID 1, combining stripping with disk mirroring. RAID Level 10 combines the fast performance of Level 0 with the data redundancy of level 1. In this configuration, data is distributed across several disk drives, similar to Level 0, which are then duplicated to another set of drive for data protection.

  • Page 108: Raid 5

    APPENDIX RAID 5 RAID 5 is sometimes called striping with parity at byte level. In RAID 5, the parity information is written to all of the drives in the controllers rather than being concentrated on a dedicated parity disk. If one drive in the system fails, the parity information can be used to reconstruct the data from that drive.

  • Page 109: Raid 6

    APPENDIX RAID 6 RAID 6 provides the highest reliability. It is similar to RAID 5, but it performs two different parity computations or the same compu- tation on overlapping subsets of the data. RAID 6 can offer fault tolerance greater than RAID 1 or RAID 5 but only consumes the capacity of 2 disk drives for distributed parity data.

  • Page 110: Single Disk (Pass-Through Disk)

    APPENDIX Important RAID level 00, 100, 30, 50 and 60 can support up to eight RAID set. If volume is RAID level 00, 100, 30, 50, or 60, you can’t change the volume to another RAID level. If volume is RAID level 0, 1, 10(1E), 3, 5, or 6, you can’t change the vol- ume to RAID level 00, 100, 30, 50, or 60.

  • Page 111: Summary Of Raid Levels

    APPENDIX Summary of RAID Levels ARC-8050 Thunderbolt RAID storage supports RAID Level 0, 1, 10(1E), 3, 5, 6, 30, 50 and 60. The following table provides a summary of RAID levels. RAID Level Comparision RAID Description Disks Data Level Requirement...
  • Page 112 APPENDIX RAID 30 is a combination multiple Up to one disk RAID 3 volume sets with RAID 0 failure in each (striping) sub-volume RAID 50 is a combination multiple Up to one disk RAID 5 volume sets with RAID 0 failure in each (striping) sub-volume...

Table of Contents
