Summary of Contents for InFocus MondoCenter
- Page 1 MondoCenter ユーザー ・ ガイド User’s Guide 用户指南 Benutzerhandbuch 用戶指南 Guida per l'utente Guide de l'utilisateur Hư ng D n S D ng Guía del usuario 사용 설명서 Panduan Pengguna Regulatory model: INF-MCENTER p/n: 009-1423-00...
-
Page 2: Table Of Contents
Setting up a Wireless Mouse and Keyboard ............................10 Wireless Mouse ..................................... 10 Wireless Keyboard ..................................10 Attaching the Antennas ..................................11 Optional Bracket Installation ................................11 Cable Connection ....................................12 Turning the MondoCenter On ................................13 Maintenance ......................................13 Troubleshooting ....................................14 Page 1... - Page 3 Page 2...
-
Page 4: Declaration Of Conformity
SRS Labs, Inc. TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc. InFocus, In Focus, and INFOCUS (stylized) are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries. All other trademarks are the property of their respective owners. Any other trademarks, service marks, personal names or product names are assumed to be the property of their respective owners and are used only for reference. - Page 5 003 du Canada. Energy Star As an ENERGY STAR Partner, InFocus Corporation has determined that this product meets the ENERGY STAR guidelines for energy efficiency. ENERGY STAR® is a joint program of the U.S. Environmental Protection Agency and the U.S. Department of Energy aimed at saving money and protecting the environment through energy efficient products and practices.
- Page 6 The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co- channel mobile satellite systems; The maximum antenna gain 2 dBi permitted (for devices in the band 5250 - 5350 MHz and 5470 - 5725 MHz ) to comply with the e.i.r.p.
-
Page 7: Safety Information
Safety Information Please read and follow all safety instructions provided below and on the MondoCenter computer module before connecting the com- puter module to a power source. Failure to comply with safety instructions may result in fire, electrical shock, or personal injury and may damage or impair protection provided by the equipment. -
Page 8: What's Included
Quick Setup Guide (not shown) *Keyboard and mouse not included in all countries. For setup purposes, a keyboard and mouse are recommended. Any standard wired or wireless mouse or keyboard, connected through the MondoCenter USB ports, is supported by MondoCenter. Page 7... -
Page 9: Connection Panel Identification
Connector Panel Identification Front Panel Connector Description Audio In connector Microphone In connector Audio Out connector SPDIF SPDIF Optical connector. eSATA eSATA connector. USB connector SuperSpeed USB 3.0 connector Wi-Fi LED. Displays solid green when Wi-Fi is on (Note: Does not signify that Wi-Fi is connected). Hard drive LED. -
Page 10: Back Panel
Back Panel Connection Description Antenna connectors DB9 RS232 connector. See RS232 command codes related to your display device. DVI-I connector RJ45 network connector DisplayPort connector HDMI HDMI connector Power adapter connector Page 9... -
Page 11: Setting Up A Wireless Mouse And Keyboard
Setting up a Wireless Mouse and Keyboard This section only applies to the InFocus mouse and keyboard which ships to some countries. Refer to the manufacturer's documenta- tion, if another mouse and keyboard are being used. Note: For initial setup and/or configuration, it may be easier to use a mouse and keyboard. Any standard wired or wireless mouse or keyboard, connected through the MondoCenter USB ports, is supported by MondoCenter. -
Page 12: Attaching The Antennas
Attach the antennas to the antenna connectors on the computer module by rotating each antenna clockwise until secure. Do not overtighten. Optional Bracket Installation If desired, the MondoCenter computer module can be installed on the back of a tablet or monitor. Refer to the tablet/monitor manufacturer user documentation for information on proper location and installation of the bracket. -
Page 13: Cable Connection
into the bracket. Cable Connection Connect one end of an HDMI cable to the computer module. NOTE: Connect the other end of the HDMI cable to the display device. Although the Mondopad software is optimized for use with a touch device, a mouse and keyboard can be used. Connect an audio cable (not provided) between the display device and the Audio Out connector on the computer module. -
Page 14: Turning The Mondocenter On
Connect the power cord to the power adapter. Connect the power adapter to the computer module. Connect the power cord to an AC outlet. Turning the MondoCenter On/Off • To turn the computer module on: Press the Power button on the computer module. Wait a few seconds. The LED will turn solid blue when it is completely powered on. -
Page 15: Troubleshooting
Verify the dongle is properly connected to the computer module. Verify the button on the bottom of the remote is turned to ON. Replace the mouse batteries, making sure the orientation of the batteries is correct. For additional troubleshooting support, please contact: InFocus Corporation Technical Support 6am-5pm PST 877-388-8385 www.infocus.com/support...
