Summary of Contents for TECNA TE70
- Page 1 USER MANUAL From version 1.00 TECNA® S.p.A. Via Meucci 27 - 40024 Castel S. Pietro Terme – Bologna ITALY Tel. +39 0516954411 – Fax +39 0516954490 – http://www.tecna.net DOCUMENT DISTRIBUTOR: MAN xxxx NUMBER: EDITION: February 2016...
-
Page 2: Table Of Contents
TE70 IR-HEATER TABLE OF CONTENTS 1.0 INTRODUCTION ................... 3 2.0 MAIN MENU ....................4 2.1 STATUS BAR ..................... 7 3.0 MANUAL WORK MODE ................8 4.0 AUTOMATIC WORK MODE ................ 10 5.0 TEMPERATURE PROFILE WORK MODE ............. 13 5.1 SELECTING THE STEP OF THE PROFILE TO BE EDITED ....... 15 5.2 TEMPERATURE SETTING.............. -
Page 3: Introduction
TE70 IR-HEATER 1.0 INTRODUCTION This is a control unit for managing the infrared heating system used to remove the panels glued to the inside of a motor vehicle. Control unit equipped with color touch screen to facilitate the management of the heater's programming parameters. -
Page 4: Main Menu
TE70 IR-HEATER 2.0 MAIN MENU Allows the user to access the TE70 heater's manual work mode. This mode is used when a part needs to be heated through constant heat without the control unit having any limits on the temperature that the heated part can attain. - Page 5 TE70 IR-HEATER Allows the user to access the TE70 heater's automatic work mode. This mode is used when a part needs to be heated at a temperature defined by the user and when the user wants to prevent the temperature of the heated object from exceeding the set value, even in case of prolonged exposure to infrared radiation.
- Page 6 TE70 IR-HEATER Allows the user to load files from a USB pendrive that contains the pre- parameterized programs for the automatic and temperature profile work modes, simplifying parameter settings for the user. PAGE 6...
-
Page 7: Status Bar
2.1 STATUS BAR The status bar is located at the top of the screen and can be seen in each TE70 heater screen. When [USB] is shown, this means a pendrive was properly inserted and recognized. Indication [---] means the lack of or the non-recognition of the pendrive. -
Page 8: Manual Work Mode
TE70 IR-HEATER 3.0 MANUAL WORK MODE This work mode is used when you want to heat the object by providing a constant amount of heat to it, without any control on the maximum temperature the object will reach during the heat application time. The user can adjust the power delivered by the heating tool;... - Page 9 TE70 IR-HEATER Button to return to the main screen. Buttons to adjust the percentage of power that must be delivered by the heating tool. The heated surface's temperature is measured through the temperature sensor built-into the tool. The maximum temperature the sensor can measure is 240°C;...
-
Page 10: Automatic Work Mode
On reaching the temperature set on the TE70 heater, the control unit will begin to modulate the power delivered to the tool to maintain constant the temperature of the heated surface. - Page 11 TE70 IR-HEATER Temperature of heated surface Power to Temperature at deliver which to heat the surface Button to return to the main screen. PAGE 11...
- Page 12 TE70 IR-HEATER Buttons to adjust the power percentage that must be delivered by the heating tool. Buttons to adjust the temperature at which the object subjected to infrared radiation must be heated. The user manages the duration of the heating process through the start button on the heating tool handle.
-
Page 13: Temperature Profile Work Mode
The profile generated by the TE70 heater can contain up to 5 program steps: each step is characterized by power delivered by the heating tool, by a temperature value the heated surface must reach and by time duration. - Page 14 TE70 IR-HEATER Power to Temperature deliver (5.3) of heated surface Current step duration (5.4) Indicates Temperature at current step which to heat number (5.1) the surface (5.2) PAGE 14...
-
Page 15: Selecting The Step Of The Profile To Be Edited
TE70 IR-HEATER Button to return to the main screen. 5.1 SELECTING THE STEP OF THE PROFILE TO BE EDITED When you press the indication of the step number currently displayed, a numeric keypad will appear with which to select which of the 5 steps making up the temperature profile you want to view and/or edit. -
Page 16: Temperature Setting
When the heated surface reaches the temperature value set on the control unit, the TE70 heater will begin to modulate the power delivered to the heating tool to maintain the temperature of the heated surface at the same value set on the control unit. -
Page 17: Power Setting
TE70 IR-HEATER 5.3 POWER SETTING When you press the indication of the power to be delivered, a numeric keypad will appear with which to set the power that must be delivered by the heating tool during the profile's current step. -
Page 18: Setting The Step Duration
If you set a current step duration of 0, the TE70 heater will skip the execution of the current step and go to the next step, if present;... -
Page 19: Usb
When you connect a pendrive to the control unit, the [USB] indicator is activated in the status bar when it is properly recognized. On entering the USB management menu, the files containing the TE70 valid heating programs will be displayed in a scrollable list. - Page 20 TE70 IR-HEATER Buttons to scroll through the list of available programs in the pendrive. The pendrive can contain up to 100 different programs. Files with .TPM extension contain a parameterization for the temperature profile work mode. Files with .TAM extension contain a parameterization for the automatic work mode.
-
Page 21: Error Messages
TE70 IR-HEATER 7.0 ERROR MESSAGES Heating tool not connected to the inverter. Warns that the start button was pressed when powering-on the machine or right after connecting the heating tool. Release the start button to restore machine operation. Indicates, at the end of a machine use stage, not to disconnect the system from the power supply mains to allow the heating tool to cool down properly. -
Page 22: Heating Tool
TE70 IR-HEATER 8.0 HEATING TOOL Temperature START sensor button Place the heating tool on the surface to be heated and press and hold down the START button. There is a button on the handle's side to lock the START button in held-... -
Page 23: Temperature Sensor Calibration
TE70 IR-HEATER 9.0 TEMPERATURE SENSOR CALIBRATION The temperature reading of the surface to be heated, performed by the sensor built into the heating tool, is influenced by the finish and the color of the surface itself. Therefore, in order to have a correct reading of the surface temperature before starting work, you must calibrate the temperature sensor using the appropriate calibrator. - Page 24 TE70 IR-HEATER Calibrate the sensor using the appropriate calibrator on an area of the surface to be heated, possibly a flat area. Set the calibrator orthogonal to the surface on which the heating process will be performed. Press and hold down the “PUSH CALIB” button.
-
Page 25: Choosing Between °C And °F
TE70 IR-HEATER 10.0 CHOOSING BETWEEN °C AND °F You can select to display temperatures in °C or °F. In order to change the two views, press the area that displays the temperature of the heated surface within the automatic or temperature profile work screens. The switching between the two units of measure will take place immediately.
