Metawatch WDS111 User Manual

Bluetooth watch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Getting Started

Starting the Watches
Charge your watch. Attaching the clip may cause the watch to reset. This is only for Beta units.
It is due to the Reset pin used for 2-wire JTAG (embedded debugging) being turned ON by
default.
Resetting the watch causes pairing information to be deleted. This (pairing information) will be
stored in Flash memory in the next revision of software. If you reset while paired, be prepared
for a new pairing request.
If you are using a large grey charge clip that has an 18 pin ribbon connector on the back, you
should attach your clip to the watch BEFORE applying power via the micro USB socket.
If you are using the small black clip with only a micro USB socket, then you should be able to
attach to the watch however you like. It may be possible to short the power against the steel
case back; there are protections in place to limit any damage, but you may notice the clip
getting hot if this occurs. Try to verify that everything is seated correctly and that the watch is
charging.
Digital Watch
There are 6 buttons on the digital watch. When booted the digital watch has these functions
(mostly for demonstration and debug). The watch boots in a "radio mode".
MetaWatch.org
Bluetooth Watch User Manual Draft
Watch Firmware v0.7.15
Android APK v0.1.9b
User Manual Draft
Watch v0.7.15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WDS111 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Metawatch WDS111

Summary of Contents for Metawatch WDS111

  • Page 1: Getting Started

    Try to verify that everything is seated correctly and that the watch is charging. Digital Watch There are 6 buttons on the digital watch. When booted the digital watch has these functions (mostly for demonstration and debug). The watch boots in a “radio mode”. MetaWatch.org User Manual Draft Watch v0.7.15...

  • Page 2: Analog Watch

    Analog Watch There are 3 buttons on the Analog watch. When booted the analog watch has no UI functions. MetaWatch.org User Manual Draft Watch v0.7.15...

  • Page 3: Pairing And Connecting

    USB and then browsing for the file using a file manager application. We use Astro File Manager. Once installed, you should be able to open the app (named “MetaWatch”, press the Android Menu button and go to “Settings”. 1. Under the ‘Notifications’ title, you can check or uncheck the items you want pushed to the watch.

  • Page 4: How To Reset

    You may need to pull this down and press the ‘pairing request’ notification to get the dialog. When connected the logo for the MetaWatch serivice displays a tiny watch in the system bar. The MetaWatch App will remember the MAC address of the watch you selected permanently.

  • Page 5: Troubleshooting

    (turn off, pull battery, wait, put battery back in, boot). You may also want to delete the paired information from the Android Settings->Wireless->bluetooth and the MAC address from the MetaWatch App. Please report back. Phones Tested The list is still growing, but there are reports of issues with the Bluetooth functions of Samung Galaxy S and HTC Evo that need validation.
  • Page 6 Samsung Galaxy S HTC Evo Samsung Infuse Droid X Contact David Rosales drosales@fossil.com mobile:+1.214.704.4218 @davidro MetaWatch.org User Manual Draft Watch v0.7.15...

  • Page 7: Fcc Statement

    Product Information for WDS111 and WDS112 FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 8 1) l'appareil ne doit pas produire de brouillage, et 2) l'utilisateur de l'appareil doit accepter tout brouillage radiolectrique subi, mme si le brouillage est susceptible d'en compromettre le fonctionnement CE Declaration of Conformity for WDS111 and WDS112 We, Fossil Partners, L.P. of 2280 N. Greenville Ave.

  • Page 9: Bluetooth® Statement

    Bluetooth® Statement This product contains QDID B015490 and QDID B016770. The Bluetooth word mark and logos are registered ® trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Fossil Partners, L.P. under license. Other trademarks and trade names are those of their respective owners.
