Summary of Contents for DuraComm 185LD
- Page 1 LED MONITOR USER’S MANUAL MODEL NO.:185LD Read this manual before operation...
-
Page 2: Table Of Contents
Features................1 Inside the box..............1 Connection of LED monitor to PC........1 Operation of monitor............2 How to use On Screen Display (OSD).......2 OSD shortcut key ............3 Menu ................4 Optimal screen resolution settings........5 Safety precautions............6 ........6 Operational climate requirements Cleaning and Maintenance of LED monitor......6 Troubleshooting...............7 Uniformity and related compliance........7 Installation disassembling wall mounting and adjusting the... -
Page 3: Features
Features The LED monitor provides a bright, clear and vivid color display and does not emit radiation as can be generated by common CRT monitors. Auto setting. Meets the energy saving standard of VESA DPMS. Allows user defined auto power off timer for additional energy savings. -
Page 4: Operation Of Monitor
The on screen display (OSD) function lets you adjust the display quality of the monitor according to your needs. (Remarks: Please ensure that the monitor is turned on and that the sync signal input cable is attached to your computer before making adjustments.) -
Page 5: Osd Shortcut Key
AUTO Auto adjustment Press the key with [AUTO] on the display panel. Auto adjustment will begin. OSD will be displayed automatically. It will complete the adjustment about 10 seconds later. Remarks: No effect will be available for the function adjustment under DVI mode since the digital signal is very standard. -
Page 6: Menu
Menu After press “ ” and“ ”button Sub-menu Function name Adjust the contrast of the picture. Contrast Brightness Adjust the brightness of the picture. Horizontal Screen picture can move left or right. position Vertical position Screen picture can move up or down. OSD horizontal Adjust the horizontal orientation of the menu. -
Page 7: Optimal Screen Resolution Settings
After press “ ” and “ ”button Sub-menu Function name Contrast Adjust the contrast of the picture. Brightness Adjust the brightness of the picture. Adjust display orientation to the left or right. Horizontal position Vertical position Adjust screen orientation up or down. English, Simplified Chinese, Korean, Turkish, French, Language German, Italian, Spanish, Russian, and Japanese. -
Page 8: Safety Precautions
Safety Precautions Please read the following instructions to avoid a fire or electric shock leading to injury or damage of property. Caution: Always operate the LED monitor with the designated power supply. To guarantee protection, we strongly recommend that you should install a surge protector device between the main power outlet and AC power supply or AC adapter. Remove the power plug in case of any abnormality (e.g. -
Page 9: Troubleshooting
Troubleshooting The following situations are normal and do not indicate a quality issue. 1.The graph shown may deviate depending on the PC type when you turn on the LED monitor for the first time. Please adjust it according to the operation instructions of LED monitor. 2 .The screen may flash when you turn on the LED monitor for the first time. -
Page 10: Installation Disassembling Wall Mounting And Adjusting The \ \ Viewing Angle
Installation disasembling wall mounting and adjusting the viewing angle ① ② ③ ① ② ③ Viewing angle Wall Mounting VESA Standard 75x75mm -8 -...
