Part Name：802.11b/g Wireless Module

Part No.：AWU50G-W

Version：V1.0

Table of Contents

Need help?

Do you have a question about the AWU50G-W and is the answer not in the manual?

Questions and answers

Summary of Contents for Allwins AWU50G-W

Page 1 AWU50G-W User’s Manual Part Name：802.11b/g Wireless Module Part No.：AWU50G-W Version：V1.0...
Page 2: Revision History
AWU50G-W User’s Manual Revision History Release Date Revision Initials 2009-6-24 Initial release Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...
Page 3: Table Of Contents
AWU50G-W User’s Manual Table of Contents 1. PRODUCT OVERVIEW 2. KEY FEATURE 3. SPECIFICATIONS 4. INSTALL THE DRIVER 5. CONNECT 6. MAKE INFRASTRUCTURE CONNECTION 7. HELP INFORMATION IN RAUI 8. MAKE AD-HOC MODE CONNECTION APPENDIX A: TERMINOLOGY APPENDIX B: IMPORTANT NOTICES Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China.
Page 4: Product Overview
AWU50G-W User’s Manual 1. Product Overview The AWU50G-W is a 802.11b/g wireless Network Adapter that is used to implement the USB2.0 interface on Notebook computers. It delivers incomparable wireless performance for your device. As a value added Wi-Fi USB2.0 card, it provides 64/128/256 WEP, WPA/WPA- PSK、WPA2/WPA2-PSK security as well.
Page 5: Install The Driver
AWU50G-W User’s Manual Europe(ETSI): 2.412 GHz ~ 2.472 GHz (CH1 ~ CH13) Japan(TELEC): 11b: 2.412 GHz ~ 2.484 GHz (CH1 ~ CH14) 11g:: 2.412 GHz ~ 2.472 GHz (CH1 ~ CH13) 802.11b :CCK,DQPSK, DBPSK Modulation 802.11g :OFDM 802.11b :11Mbps:≦-84dBm RX sensitivity 802.11g :54Mbps:≦-70dBm...
Page 6 AWU50G-W User’s Manual Step3 Choose Ralink Configuration Tool and click next to go on. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...
Page 7 AWU50G-W User’s Manual Step4 Choose Optimize for WiFi mode and click next to go on. Step5 Click Install to begin the setup. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...
Page 8: Connect
AWU50G-W User’s Manual Step6 Click Finish to end the setup. 5. connect Plug in your usb wireless LAN adapter, it will be recognized and auto installed. Just confirmed it like below: Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672...
Page 9: Make Infrastructure Connection
AWU50G-W User’s Manual 6. Make infrastructure connection  D ouble click the icon in red circle  Y ou will see: You can click the button Rescan to find which AP is in range, they will show on the window. Choice one you want to connect, and click the button connect to finish the connection.
Page 10: Help Information In Raui
AWU50G-W User’s Manual Note: please choose correct channel setting up to your law. For example, ch13 is permitted in your country, and you set your router at ch13, while you choose ch1- ch11 (default setting), you will never find the AP. So you should have to choose ch1- ch13 in Advanced page as below.
Page 11: Make Ad-Hoc Mode Connection
AWU50G-W User’s Manual 8. Make Ad-Hoc mode connection 8.1 Make an Ad-Hoc SSID Step1 Click the button Add to make the Ad-Hoc SSID: Step2 Choose the SSID and Network Type as blew,and click OK to go on. Step3 Clilk the PROF1 in the window，and you can see the information of Ad-Hoc SSID.
Page 12 AWU50G-W User’s Manual 8.2 Setup static IP address for the Ad-Hoc link Step1 At its property page, double click item Internet Protocol (TCP/IP) Step2 You will get: Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672...
Page 13 AWU50G-W User’s Manual Step3 Fill the IP address blank, example as below: Step4 Click OK to finish the setup. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...
Page 14 AWU50G-W User’s Manual 8.3 Ad-Hoc setup for one point completed. 8.4 Setup another Ad-Hoc point as step a,b,c,d. 8.5 Ad-Hoc mode link accomplished. And you can visit each other. Note: To make an Ad-Hoc mode link, we should choice the same channel. Its static IP address should be in the same subnet, and the SSID should be the same too.
Page 15: Appendix A: Terminology
AWU50G-W User’s Manual Appendix A: Terminology ad hoc network A network composed solely of stations within mutual communication range of each other via the wireless medium (WM). access point (AP) Any entity that has station functionality and provides access to the distribution ser-vices, via the wireless medium (WM) for associated stations.
Page 16 AWU50G-W User’s Manual Appendix B: Important Notices Federal Communications Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 17 AWU50G-W User’s Manual This device is intended only for OEM integrators under the following conditions: The antenna must be installed such that 20 cm is maintained between the antenna and users,and The transmitter module may not be co-located with any other transmitter or antenna.As long as 2 conditions above are met, further transmitter test...
