- Page 1 HDMI to Scart converter User manual...
- Page 2 Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: ■ Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
- Page 3 Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. I. Introduction The MINI MHL/HDMI to SCART converter which will convert digital MHL/HDMI video and audio signal to composite video signal and the FL / FR stereo audio signal, while support DVI system sideline signals.
- Page 4 Support NTSC and PAL two standard TV formats output. Compatible with HDMI1.3，Converts HDMI to SCART(CVBS). Idel for TVs/Projectors/flat screen TVs with no HDMI input; Share your smart phone photos, music and movies on the TV. Lower Power consumption design, directly powered by 5V, 1 A USB charger. (Please use Branded 5V, 1A USB Chargers for enough power supply to avoid insufficient power issue.) III.
- Page 5 Dimensions(mm) 85(D)x58(W)x26(H) Weight (g) Input Resolution 640x480@60Hz,800x600@60Hz, 1024x768@60Hz, 1280x720@60Hz. 1280x1024@60Hz,1360x768@60Hz, 1600x1200@60Hz,1920x1080@60Hz 480i/60Hz,480p/60Hz,576i/60Hz,576p/60Hz,, 720p50/60Hz, 1080i50/60Hz,1080p23.97/24/25/50/59.94/60Hz SCART Port: CVBS output 720 x 576 @ 25fps (PAL); 720 x 480 @ 30FPS (NTSC). PAL, NTSC Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F Elative Humidity...
- Page 6 V. Operation controls and Functions Front Panel Rear Panel 1) PAL/NTSC Switch: Switch the CVBS output format. 2) HDMI Input: Connect the HDMI to your source equipment such like DVD/Game console. Connect the MHL >HDMI to your smart phone 3) LED indicator: When the DC5V power on, the indicator will be light. 4) Power: Plug the 5VDC power supply into the unit and connect the adapter to AC wall outlet.
- Page 7 VI. Application Example VII. Support MHL smart Phone series Samsung I9100,i9108,i9188,I977,Samsung Galaxy Note(i900) HTC sensation(HTC G14/G18/G19),HTC Flyer, HTC EVO 3D Z710,Z710e,Z710T LU6200, LG P940 SONY LT26I...
- Page 8 NOKIA Because of the different connecters, The Samsung smart phone Galaxy S3, S4 series (I9300,I9308,1939, Note2 N7100,I9500) need to add a micro USB 5pin to 11 pin connector.
-
Page 9: Before Troubleshooting
Before troubleshooting Please make sure that your PC/notebook Input Status is HDMI in, and output signals for TV/Monitor to SCART CVBS signals out. How to connect the device correctly? ■ Connect TV/Monitor with the device by qualified HDMI Cable. ■ Power On the device by using USB Power cable or 5V, 1A USB Charger. (Please use Branded 5V, 1A USB Chargers for enough power supply to avoid insufficient power issue.). - Page 10 ■ The Video signal is not out - Check TV/Monitor input channel is SCART CVBS. - Check SCART Cable is tightly connected with the device. - Check if you choose the right signal of NTSC / PAL. - Check the Power Supply is sufficient. Strongly suggest branded USB Charger, which supply real 5V, 1A power.
- Page 11 ■ The picture is not clearly when using. - Plug off the HDMI Cable from the connecting device, after 5 seconds TV will show colorful testing picture, and display NO SIGNAL. - If the colorful testing picture is clear, then the device is no problem, the input HDMI signal source has problem.
- Page 12 ■ After working several minutes, the device don’t work any more -- If you bought device is with USB power, please to use Branded 5V, 1A USB Chargers for enough power supply to avoid insufficient power issue. ■ HDMI to Scart device can’t show the correct video - Try to change another High quality HDMI Cable;...
