Solveil System Installation Guide
A step-by-step installation guide for the MicroPower Solveil™
Solar Powered, Wireless Surveillance System
SLV-C30S-1040-IR, SLV-C30S-1040, SLV-C306-1011-IR, SLV-C30S-1011 and SLV-H20HA
Version: 1.0
4350 Executive Drive, Suite 325
San Diego, CA 92121
+1-858-914-5198
www.micropower.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLV-C30S-1040-IR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MicroPower SLV-C30S-1040-IR

  • Page 1 Solveil System Installation Guide A step-by-step installation guide for the MicroPower Solveil™ Solar Powered, Wireless Surveillance System SLV-C30S-1040-IR, SLV-C30S-1040, SLV-C306-1011-IR, SLV-C30S-1011 and SLV-H20HA Version: 1.0 4350 Executive Drive, Suite 325 San Diego, CA 92121 +1-858-914-5198 www.micropower.com...
  • Page 2: How To Use This Guide

    Experienced MicroPower installers can install cameras and equipment quickly and efficiently, however due to the highly efficient nature of the camera system, the MicroPower equipment setup differs from conventional IP surveillance devices. To quickly help System Integrator / Installers familiarize themselves with the MicroPower product line best practices and troubleshooting, MicroPower offers a variety of training options.
  • Page 3: Table Of Contents

    MicroPower System Overview� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �...
  • Page 4: Package Contents

    Solveil Hub (SLV-H20HA) • Solveil Hub, Including power supply, mounting hardware, antenna cable, connection adapters and 15’ long antenna cable (longer cables may be purchased from MicroPower) • One Directional Antenna (2.4GHz), Including bracket with washers, etc. Solveil Solar Powered Camera SLV-C30S-1040-IR, SLV-C30S-1040, SLV-C306-1011-IR, SLV-C30S-1011 •...
  • Page 5: Micropower System Overview

    MicroPower Technologies has developed an extreme, low power, camera and radio architecture that has been designed from the ground up to be solar powered. When combined with the MicroPower Trust Linx™ wireless protocol, reliable long-range digital CCTV video can be transmitted while consuming less than 10% of the electrical power that most conventional wireless IP cameras consume.
  • Page 6: Hub Connection Method

    NOTE: When settign up a camera, you should enter the IP address of each Solveil camera at that time. Do not leave the field blank or use the same IP address that is assigned to the hub. VMS Display Monitor Antennas VMS Server Antennas MiniHub Ethernet Switch http://192.168.0.105 Antennas http://192.168.0.100 rtsp://192.168.1.101:554/h264/1/media.amp/trackID=1 rtsp://192.168.1.102:554/h264/1/media.amp/trackID=1 rtsp://192.168.1.103:554/h264/1/media.amp/trackID=1 MicroPower Technologies 1-877-536-0128 | micropower.com...
  • Page 7: Getting Started - First Steps

    Getting Started - First Steps Site Survey A well thought out plan for the location of the hub, hub antenna(s) and camera(s) is a crucial step to ensuring that the entire system will provide reliable long-term service, and integrate effectively with a new or preexisting video management system.
  • Page 8: Solar Considerations

    Note: As an installer, the best way to identify the charging rate, battery levels, and signal performance, is to use our the hub’s built-in HTML interface to determine if the system is performing well or not in a given installation. MicroPower Technologies 1-877-536-0128 | micropower.com...
  • Page 9: What You Will Need

    Method to Mount the Camera and Hub to Desired Location MicroPower supplies a camera bracket, a solar panel bracket, and an antenna bracket that can be mounted to a pole. Given the variety of mounting possibilities and locations, the hardware to attach these brackets to the desired surfaces are not included.
  • Page 10: Hub Installation

    Hub Installation At the center of the MicroPower camera system is the Helios Hub. This is the “brain” of the system that communicates with the video cameras, and produces the video data streams that the VMS system will record and display.
  • Page 12: Hub Antenna Assembly And Installation

    If the antennas are not mounted identically, they will be polarized off-axis, and thus be prevented from effectively communicating with each other. Off-axis antennas, very poor communication. Antennas oriented (polarized) the same, good communication MicroPower Technologies 1-877-536-0128 | micropower.com...
  • Page 13: Hub System Setup

    Hub System Setup Accessing The Hub Default IP Address The hub has a default IP address of: 192.168.0.100. To initially communicate with the hub, connect an Ethernet cable directly from the hub to a laptop or desktop PC. A crossover cable may be required, however most modern computers have auto-sensing Ethernet ports that make this unnecessary.
  • Page 14: Changing Rf Channels

    Adding Cameras On MicroPower systems, individual cameras are never actually part of your computer network. Cameras are identified to the hub by the MAC address that is assigned to the camera. This MAC address can be located on a sticker that can be found on the exterior and the interior of the camera.
  • Page 15: Removing Cameras

    box next to it, and click “Remove”, then reboot the hub. On rare occasions, a test camera remains installed from the testing done during manufacturing. 2. To add a camera type the camera MAC address into the box provided. (If your camera is powered on, you may see it indicated as a choice in a pull down menu) 3.
  • Page 16: Camera Configuration

    For most security applications in areas such as parking lots, 5fps is quite sufficient. However some analytic packages, or just personal preference may dictate that the frame rate be set higher. MicroPower Technologies 1-877-536-0128 | micropower.com...
  • Page 17 Note: The above digram is from a (1) camera system. More or less cameras will display (scroll down) depending on your installation. Modulation: (This is the exact same setting that was on the previous tab. It’s inclusion here is just as a convenience.) Modulation is the speed of the communication that video is sent from the cameras to the hub.
  • Page 18: Vms Tab

    IMPORTANT: Be sure to click “Save” on this page after making any changes that you want to be preserved, alternatively if you made changes you do not want to keep, simply click “Cancel”, and the former values for these settings will return. MicroPower Technologies 1-877-536-0128 | micropower.com...
  • Page 19: System Status Tab

    Firmware Update: In the event that there is a firmware update available for your camera, it will be indicated here. Clicking the button will push the update out to the camera via the wireless link. (You do not have to visit the camera in person) Please call MicroPower Technologies with any questions prior to updating your cameras.
  • Page 20: System Administration

    System Logs Daily Sync: If the hub has internet access, checking this box will instruct the system to upload the log data nightly to the MicroPower offices. This is useful in the event of a problem, MPT will already have the previous nights logs on hand for review and analysis.
  • Page 21: Camera Kit Assembly & Installation

    Camera Kit Assembly & Installation Next we will cover how the cameras and camera components are assembled and installed. Some installers find it easier to do the assembly process on multiple cameras at the same time, and bring the cameras to the pole “ready to bolt on”.
  • Page 22: Solar Panel Assembly

    Assembly of the bracket, and the arrangement of the nuts, bolts, and washers. Solar bracket configured for mounting down, to a flat surface such as rooftop or ledge with the solar panel facing upward. MicroPower Technologies 1-877-536-0128 | micropower.com...
  • Page 23 Solar Bracket Mounting Configurations...
  • Page 24: Camera Antenna Assembly

    MicroPower Technologies 1-877-536-0128 | micropower.com...
  • Page 25: Camera System Installation / Mounting

    For the purposes of this document however, we will start at the top with the solar panel, and move our way down the pole. If the installer has any questions or concerns, feel free to snap some pictures, and call into MicroPower support for advice, we are always happy to assist. (877-536-0128)
  • Page 26: Antenna Mounting

    The antenna included in both the camera and receiver hub kit is an 8dBi 50 Ohm directional antenna with about a 90° Field of View. It should be mounted and oriented as the sticker on the back indicates, with the plastic front facing your desired target. MicroPower Technologies 1-877-536-0128 | micropower.com...
  • Page 27: Camera Mounting

    Camera Mounting During the assembly process, you’ve already attached the rotating portion of the camera bracket to the camera housing. This leaves the lightweight camera arm bracket to be easily attached to the desired mounting surface. 1. Use the appropriate hardware to mount the bracket to your desired surface. This may require stainless steel hose clamps (easiest and quickest, particularly for large poles), screws (good for flat wood surfaces), or perhaps stainless steel “U”...
  • Page 28: Powering On The Camera

    Battery cables connect together to power on the camera. • Standard Non-IR cameras have (1) power connector. • Cameras equipped with IR Illuminators will have (2) power connectors, both of which must be connected for reliable long-term operation. MicroPower Technologies 1-877-536-0128 | micropower.com...
  • Page 29: Focusing And Adjusting The Camera

    Focusing and Adjusting The Camera The system uses common “CS-Mount” threaded, mega-pixel CCTV lenses. Standard MicroPower cameras come equipped with either a 2.8-11mm IR corrected lens, or a 10-40mm IR corrected lens. All the lenses are equipped with a manual iris control, that in most circumstances, should always be opened up completely to offer the best low light performance.
  • Page 30: Viewing Live Video At The Camera For Focus And Adjustment

    [Launch VLC player, select “Open Capture Device”, select “Direct Show”, and choose “MicroPower” as the camera] When the adjustments are made, carefully remove the cable and securely close the camera housing, and lock the camera latch.
  • Page 31 Remote Desktop Access (preferred): The second method often proves to be the most useful and versatile. It requires that you have a computer such as a laptop that is capable of communicating with the hub. This computer will also need an Internet connection, either from from the host network, or, via a wireless devices such as a cellular to WiFi “MyFi”...
  • Page 32: Vms Integration

    MicroPower Technologies 1-877-536-0128 | micropower.com...
  • Page 34: Trouble Shooting

    MicroPower Technologies 1-877-536-0128 | micropower.com...
  • Page 35: Reducing Rf Noise With Attenuators

    MicroPower’s customer support strategy is through a network of best-in-class business partners including OEMs, systems integrators and systems resellers. If your MicroPower product was purchased directly from a MicroPower business partner, that partner is the first point of contact for technical support. If the business partner cannot resolve a problem, then the partner will contact MicroPower.
  • Page 36 This End User Software License Agreement (this “EULA”) is a legal agreement between you, the individual or entity that has agreed to pay for the rights granted herein (“Licensee”), and MicroPower Technologies, Inc., a Delaware corporation (“MPT”). This EULA governs Licensee’s possession and use of the Software and the Documentation (each as defined below).
  • Page 37 EULA and continue in perpetuity. 10. LIMITED WARRANTY; DISCLAIMER; LIMITATION OF LIABILITY. 10.1. refer to micropower.com for current warranty information 11. U.S. GOVERNMENT RESTRICTED RIGHTS. 11.1. Commercial Software. The Software and the Documentation are deemed to be “commercial computer software” and “commercial computer software documentation,”...
  • Page 38 ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Should Licensee have any questions concerning this EULA, or if Licensee desires to contact MicroPower Technologies for any reason, please contact the company at: 4350 Executive Drive, Suite 325, San Diego, CA 92121, or send an email to MicroPower Technologies at help@micropower.com.
  • Page 39 SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. END OF TERMS AND CONDITIONS MicroPower Technologies and its logo are trademarks of MicroPower Technologies, Inc. All other trademarks are the property of their respective owners. FCC Compliance Statement (Part 15.19) Compliance Statement (Part 15.19)
  • Page 40: Installation Notes

    Hub IP Address:_______._______._______._______ WB Ch_______ NB CH_______ Camera 0, MAC Address: 48:17:4C:02:______:______, IP Address:_______._______._______._______ Camera 1, MAC Address: 48:17:4C:02:______:______, IP Address:_______._______._______._______ Camera 2, MAC Address: 48:17:4C:02:______:______, IP Address:_______._______._______._______ Camera 3, MAC Address: 48:17:4C:02:______:______, IP Address:_______._______._______._______ MicroPower Technologies 1-877-536-0128 | micropower.com...
